Dorel Home Products 4189029WE Instruction Booklet
  1. Manuals
  2. Brands
  3. Dorel Home Products Manuals
  4. Indoor Furnishing
  5. 4189029WE
  6. Instruction booklet

Dorel Home Products 4189029WE Instruction Booklet

Metal loft bed
Hide thumbs
Table of Contents

Advertisement

Available languages

Available languages

Quick Links

Download this manual
TM
Weight Limit:
Bed: 200 Lb / 91 Kg
Shelves: 50 Lb / 23 Kg
J.Z. - 2018/5/9
2014 Dorel Home Products All Rights Reserved
Thank you for purchasing from DHP!
DO NOT RETURN TO THE STORE !
If parts are missing or damaged, we will gladly ship your
replacement parts free of charge.
Visit www.dhpfurniture.com/eng/replacement-parts
or call Toll-Free 1-800-267-1739
Date of Purchase
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY
INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
4189029WE
Metal Loft Bed
Lot Number
B344189029WE00 - 10125-M
Twin
Black
1
