Summary of Contents for Plusmed OxyCheck II
- Page 1 OxyCheck II Model: Instruction Manual Mode Rêbera Bikaranînê www.plusmed-health.com...
- Page 3 Warning: The Pulse Oximeter is not for diagnostic or therapeutic use. This device is intended only as an adjunct in patient assessment. It must be used in conjunction with other methods of assessing clinical signs and symptoms. Never use the Pulse Oximeter during MR or CT environment, in an explosive atmosphere, or on infant or neonatal patients.
-
Page 4: Product Operation Scope
disposal regulations. Clean the Pulse Oximeter and accessories according to local requirements. Turn off the Pulse Oximeter before cleaning. Do not sterilize, autoclave, or immerse this device in liquid. Do not pour or spray any liquids onto the device. ... -
Page 5: Measurement Principle
Then measured signal can be obtained by a photosensitive element, information acquired through which will be shown on two groups of LED through process in electronic circuits and microprocessor. 4．Appearance introduction Model No. OxyCheck II Button Display screen SPO2... - Page 6 6.2.2 OxyCheck II button operating instructions: 6.2.2.1 Put into two AAA batteries according to the instructions, the OxyCheck II will turn on automatically and display interface 1; then put into finger for measuring, if there is finger for detection and without...
-
Page 7: Product Classification
6.2.2.4 Short Press the button during the measurement; it can turn to settings menu interface. 6.3 Low power prompt When the battery power appears low, the battery power indicate for empty on screen, reminding the user to replace the battery; (the battery capacity indicates symbol of “ ”... -
Page 8: Power Specification
Classification according to the disinfection and As recommended by manufacturer sterilization methods recommended by the manufacturer Classification by electromagnetic compatibility Group I Class B equipment. 8. Power Specification Table 2 Power Specification Parameter Specification d.c. 3V AAA(×2) Battery When the battery is almost exhausted, the pulse oximeter will automatically shut down 9.Technical Specification Table 3 Pulse oximeter specification... -
Page 9: Physical Specification
The oxygen volume map of the pulse oximeter has been normalized. 10.Physical Specification The physical specifications of the host are shown in Table 4. Table 4 The physical specification of the host OxyCheck II Parameter 63×41×31 Size(mm) 11. Environment Specification The environmental specifications of the pulse oximeter are shown in Table 5. - Page 10 Storage and transportation -20℃ ～ +55℃ Temperature Relative humidity in operation 15%~80%, Non-condensing Relative humidity during storage 10%~93%, Non-condensing and transportation 59kPa ～ 107.4kPa Operating atmospheric pressure Atmospheric pressure during 22kPa ～ 107.4kPa storage and transportation 12．Logo Description Signs Notes on the signs CE mark Signal inadequacy indicator Protected against solid foreign objects of 12.5mm and greater...
-
Page 11: Troubleshooting
The goods is fragile, please handle with care Keep moisture off the packing carton 5 5℃ Temperature limitations -2 0℃ Humidity limitations Atmospheric pressure limitations Compliance to WEEE standard 13．Troubleshooting Trouble Possible Reason Solution 1. The finger is not places inside The SpO2 and 1. - Page 12 14．Accessory AAA battery------------------------2 pcs (optional) Hang String-------------------------1 pcs (optional) User Manual -----------------------1 pcs 15．Maintenance and clean If there is dust or dirt on surface, 75% density of medical alcohol can be used to clean the surface. Pls use dry fabric with little alcohol to avoid alcohol permeates into the device. 1.
- Page 13 Emission test Compliance RF emissions CISPR 11 Group 1, Group B Table 2: Electromagnetic Immunity Guidance and Declaration - Electromagnetic Emissions Immunity test Compliance ±8kV contact Electrostatic Discharge (ESD) ±15kV air IEC 61000-4-2 Power Frequency (50/60 Hz) Magnetic Field 30 A/m IEC 61000-4-8 80MHz- 2.7GHz 10 V/m...
- Page 14 0123 www.plusmed-health.com...
