- Page 1 OH 200 USER MANUAL...
- Page 2 What’s included? (A) Pole Stand x2 (B) Telescopic Pole x2 (D) 15mm rail x6 (C) Pole Connector x2 (G) Accessory Clamp x2 (E) Camera Connector (F) Camera Platform For more information please visit our website: www.glidegear.net...
- Page 3 Assembly Mount the end of Telescopic Pole (B) with the bigger diameter onto the Pole Stand (A) as shown in Fig. 1. Fig .1 Repeat the operation to assemble the 2 stands with the poles Fig .2 Slide the Pole Connector (C) onto the Telescopic pole (B) Slide two 15mm Rail (D) into the Pole Connector (C) Tighten all the screws on the Telescopic Pole (B) and the Pole Connector (C)
- Page 4 Assembly, Cont’d Slide one Accessory Clamp (G) onto the opened end of the 15mm Rails (D) Slide the Camera Connector (E) onto the opened end of the 15mm Rails (D) as shown in Fig. 4. Slide the second Accessory Clamp (G) onto the opened end Fig .4 of the 15mm Rails (D) as shown in Fig.
- Page 5 Adjustments Once assembled, your setup should look as below: Horizontal Adjustment: Add and remove rails to adjust the length of the OH 200 Vertical Adjustment: Loosen and tighten the clamps on both sides to adjust the overall height of the OH 200...
