  • Page 1 DST 50 USER MANUAL...
  • Page 2 What’s included? Telescopic Arm (C) Camera Platform (F) Main Hinge (E) Main Telescopic Pole (A) Locking Screw (D) Table Clamp (B) For more information please visit our website: www.glidegear.net...
  • Page 3 Assembly The DST 50 can be mounted into 2 different configurations: Mount onto a C-Stand. The DST 50 does not come with a C-Stand. • Mount onto a table/desk using the supplied Table Clamp (B) • Table/Desk configuration: Mount the Table Clamp (B) to the table or desk you would like to use by •...
  • Page 4 Assembly, Cont’d C-Stand configuration: Slide the Main Telescopic Pole (A) onto your C-Stand as in Fig. 3. • Using the Locking Screw (D), secure the Main Telescopic Pole (A) to • the C-Stand. Fig.3 Adjust the height of the Main Telescopic (A) by loosening and tightening the pole clamp connecting the 2 telescopic poles as shown in Fig.
  • Page 5 Assembly, Cont’d Connect the Telescopic Arm (C) via the Main Hinge (E) as in shown in Fig. 4. Adjust the angle of the Telescopic Arm (C) by loosening and tightening the Main Hinge (E) . Make sure the Main Hinge (E) is fully locked before moving Fig.4 to the next step.
  • Page 6 Vertical Adjustment: Adjust the camera angle by loosening and tightening Loosen and tighten the pole clamp the hinge at the base of the Camera Platform to adjust the height of the DST 50 For more information please visit our website: www.glidegear.net...
