  • Page 1 REVO 50 USER MANUAL...
  • Page 2 What’s included? Camera Pole (G) Center Shaft (B) Camera Clamp (F) Clamps x2 (E) Top plate (J) Long Rails x2 (C) Backdrop clamp (H) Backdrop (I) Base Plate (A) Short Rails x 4 (D) Counterweights (K) For more information please visit our website: www.glidegear.net...
  • Page 3 Assembly Put the Center Shaft (B) onto the Base Plate (A) and secure the two together using the thumb screw on the side of the Center Shaft (B). See Fig. 1. Insert the Long Rails (C) inside their tracks on the Center Shaft (B) Fig.
  • Page 4 Assembly Slide and secure onto the Long Rails (C) one of the Clamps (E) in order to prevent the rails from twisting. Slide and secure on the long rails (C) the Camera Clamp (D). Insert and secure the Camera Pole (F) into the Camera Clamp (D).
  • Page 5 Assembly Place the Top Plate (J) on the Center Shaft (B). Mount the Backdrop (I) to the Backdrop Clamp (H) and position the Backdrop as close as possible to the Top Plate (J). Mount your camera onto the Camera Pole (G). Add Counterweight (K) onto the Clamp (E) behind the backdrop to bal- ance the rig.
  • Page 6 Additional information Mounting Options: The Center Shaft (B) can be mounted directly • onto a C-Stand as shown in Fig. 5. The Base Plate (A) features 4 holes for mounting • purposes. Screws are not included Available Adjustments: Height of the camera via the Camera Pole (G) •...
