  • Page 1 ORDER NO. DSC1002013CE Digital Camera DMC-ZX3EB Model No. DMC-ZX3EE DMC-ZX3EF DMC-ZX3EG DMC-ZX3EP DMC-ZX3SG DMC-ZR3P DMC-ZR3PC DMC-ZR3PR DMC-ZR3PU DMC-ZR3GC DMC-ZR3GD DMC-ZR3GH DMC-ZR3GK DMC-ZR3GN DMC-ZR3GT Vol. 1 © Panasonic Corporation 2010 Unauthorized copy- ing and distribution is a violation of law.

  • Page 2: Table Of Contents

    Colour [ DMC-ZR3 ] (S)...Silver Type (except PC/PR/GT/GD) [ DMC-ZX3 ] (K)...Black Type (S)...Silver Type (except EF) (N)...Gold Type (only GC/GH/GT) (K)...Black Type (except SG) (R)...Red Type (except PC/PR/GD) (N)...Gold Type (only SG) (T)...Brown Type (only GD/GH/GN) (R)...Red Type (except EE) (A)...Blue Type (only P/PC/PU/GN) (T)...Brown Type (except EB/EE) (A)...Blue Type (except EF/SG)

  • Page 3: Safety Precautions

    1 Safety Precautions 1.1. General Guidelines 1.3. Leakage Current Hot Check 1. IMPORTANT SAFETY NOTICE (See Figure 1.) There are special components used in this equipment 1. Plug the AC cord directly into the AC outlet. Do not use which are important for safety. These parts are marked by an isolation transformer for this check.

  • Page 4: How To Discharge The Capacitor On E.capacitor P.c

    1.4. How to Discharge the Capacitor on E.Capacitor P.C.B. CAUTION: 1. Be sure to discharge the capacitor on E.Capacitor P.C.B.. 2. Be careful of the high voltage circuit on E.Capacitor P.C.B. when servicing. [Discharging Procedure] 1. Refer to the disassemble procedure and remove the necessary parts/unit. 2.

  • Page 5: Warning

    2 Warning 2.1. Prevention of Electrostatic Discharge (ESD) to Electrostatically Sensitive (ES) Devices Some semiconductor (solid state) devices can be damaged easily by static electricity. Such components commonly are called Elec- trostatically Sensitive (ES) Devices. The following techniques should be used to help reduce the incidence of component damage caused by electrostatic discharge (ESD).

  • Page 6: Caution For Ac Cord(For Eb/Gc

    A replacement fuse cover can be purchased from your local 2.3.2.3. How to Replace the Fuse Panasonic Dealer. 1. Remove the Fuse Cover with a screwdriver. If the fitted moulded plug is unsuitable for the socket outlet in your home then the fuse should be removed and the plug cut off and disposed of safety.

  • Page 7: How To Replace The Lithium Battery

    NOTE: This Lithium battery is a critical component. (Type No.: ML421 Manufactured by Energy Company, Panasonic Corporation.) It must never be subjected to excessive heat or discharge. It must therefore only be fitted in requirement designed specifically for its use.

  • Page 8: Service Navigation

    3 Service Navigation 3.1. Introduction This service manual contains technical information, which allow service personnel’s to understand and service this model. Please place orders using the parts list and not the drawing reference numbers. If the circuit is changed or modified, the information will be followed by service manual to be controlled with original service manual. 3.2.

  • Page 9: How To Define The Model Suffix (Ntsc Or Pal Model)

    3.4. How to Define the Model Suffix (NTSC or PAL model) There are nine kinds of DMC-ZX3/ZR3, regardless of the colours. • a) DMC-ZX3 (Japan domestic model), DMC-ZX3SG • b) DMC-ZR3P/PC • c) DMC-ZX3EB/EF/EG/EP • d) DMC-ZX3EE • e) DMC-ZR3GT •...
  • Page 10 3.4.2. INITIAL SETTINGS: After replacing the MAIN P.C.B., be sure to perform the initial settings after achieving the adjustment by ordering the following pro- cedure in accordance with model suffix of the unit. 1. IMPORTANT NOTICE: Before proceeding Initial settings, be sure to read the following CAUTIONS. 2.
  • Page 11 [CASE 1. After replacing MAIN P.C.B.] [Except “EG, EF, EB, PR and EP” models: (VEP56100A is used as a Main P.C.B.] When MAIN P.C.B. has just been replaced, all of the model suffix is displayed as follows. (Three pages in total) [Only “EG, EF, EB, PR and EP”...
  • Page 12 • Step 6. Set the model suffix in “INITIAL SETTINGS”: • Press the “[ RIGHT ] of Cursor buttons”. • The only set area is displayed, and then press the “[ RIGHT ] of Cursor buttons” after confirmation. (The unit is powered off automatically.) •...

  • Page 13: Specifications

    4 Specifications...

  • Page 14: Location Of Controls And Components

    22 Card/Battery door 23 Release lever 24 DC coupler cover When using an AC adaptor, ensure that the Panasonic DC coupler and AC adaptor are used. We recommend you use a battery with sufficient battery power or the AC adaptor when recording motion pictures.
  • Page 15 Selecting the [REC] Mode Turn the camera on. [REC]/[PLAYBACK] selector switch Mode dial Slide the [REC]/[PLAYBACK] selector switch to [ Switching the mode by rotating the mode dial. List of [REC] Modes Intelligent Auto Mode The subjects are recorded using settings automatically selected by the camera.
  • Page 16 Changing [REC MODE] and [REC QUALITY] Select [REC MODE] from the [MOTION PICTURE] Mode menu, and press Press to select the item and then press [MENU/SET]. Recording format Features Select this format to record HD (high definition) video for playback on your HDTV using an HDMI connection. It can be played back as is by inserting the card into a device [AVCHD Lite] compatible with AVCHD.
  • Page 17 The only batteries suitable for use with this unit are genuine Panasonic products and batteries manufactured by other companies and certified by Panasonic. (Batteries which do not support this function cannot be used). Panasonic cannot in any way guarantee the quality, performance or safety of batteries which have been manufactured by other companies and are not genuine Panasonic products.

  • Page 18: Service Mode

    6 Service Mode 6.1. Error Code Memory Function 1. General description This unit is equipped with history of error code memory function, and can be memorized 16 error codes in sequence from the latest. When the error is occurred more than 16, the oldest error is overwritten in sequence. The error code is not memorized when the power supply is shut down forcibly (i.e.,when the unit is powered on by the battery, the battery is pulled out) The error code is memorized to FLASH-ROM when the unit has just before powered off.
  • Page 19 • 3. Error Code List The error code consists of 8 bits data and it shows the following information.

  • Page 20: Ics (Indication Of Additional Camera Settings When Picture Was Taken) Function

    Important notice about "Error Code List" 1) About "*" indication: The third digit from the left is different as follows. - In case of 0 (example: 18001000) When the third digit from the left shows "0", this error occurred under the condition of INITIAL SETTINGS has been completed.
  • Page 21 3. How to read 4. How to exit: Simply, turn the power off. (Since ICS function is executed under the condition of temporary cancellation of "INITIAL SETTINGS", it wake up with normal condition when turn off the power.)

  • Page 22: Service Fixture & Tools

    7 Service Fixture & Tools 7.1. Service Fixture and Tools The following Service Fixture and tools are used for checking and servicing this unit.

  • Page 23: When Replacing The Main P.c.b

    7.2. When Replacing the Main P.C.B. After replacing the MAIN P.C.B., be sure to achieve adjustment. The adjustment instruction is available at “software download” on the “Support Information from NWBG/VDBG-AVC” web-site in “TSN system”, together with Maintenance software. 7.3. Service Position This Service Position is used for checking and replacing parts.

  • Page 24: Disassembly And Assembly Instructions

    8 Disassembly and Assembly Instructions 8.1. Disassembly Flow Chart This is a disassembling chart. When assembling, perform this chart conversely. 8.2. P.C.B. Location...

  • Page 25: Disassembly Procedure

    8.3. Disassembly Procedure 8.3.1. Removal of the Rear Case Unit Item Removal Rear Case Unit (Fig.D1) Card Battery 6 Screws (A) 1 Screw (B) FP9003(Flex) FP9501(Flex) Rear Case Unit LCD Unit (Fig.D2) 4 Locking tabs LCD Unit Front Case Unit (Fig.D3) 1 Screw (C) 3 Screws (D)
  • Page 26 8.3.2. Removal of the LCD Unit 8.3.4. Removal of the Top Operation Unit (Fig.D2) 8.3.3. Removal of the Front Case Unit (Fig.D4) 8.3.5. Removal of the E.Capacitor P.C.B. (Fig.D3) (Fig.D5)
  • Page 27 8.3.6. Removal of the Flash Top P.C.B. and Speaker (Fig.D7) (Fig.D6)
  • Page 28 8.3.7. Removal of the Lens Unit (Fig.D8) (Fig.D9)
  • Page 29 8.3.8. Removal of the Sub Operation 8.3.10. Removal of the Sub Operation FPC FPC(1) Unit (Fig.D12) (Fig.D10) 8.3.9. Removal of the Main P.C.B. (Fig.D11)
  • Page 30 8.3.11. Removal of the Battery Case Unit (Fig.D13) (Fig.D14)

  • Page 31: Lens Disassembly Procedure

    8.3.12. Removal of the Jack Door 8.4. Lens Disassembly Procedure Precaution: 1. Do not remove the CCD when disassembling or re- assembling the lens in order to maintain it clean. When remove it, refer to item "8.6.". 2. Keep dust or dirt away from the lens. 3.
  • Page 32 8.4.1. Removal of the Zoom Motor and 6. Unscrew the 1 screw (B). 7. Remove the photo sensor. Lens FPC Unit 8. Remove the 16 solders (C). 1. Remove the 7 solders (A). 9. Remove the 5 locks. 2. Remove the 1 lock. 10.
  • Page 33 2. Remove the master flange unit. 8.4.3. Removal of the 1st Lens Frame Unit/2nd Lens Frame Unit/Both Sides Cam Frame/2nd 3rd Direct Frame/3rd Lens Frame Unit 1. Push the both sides cam frame from the lens front side in the direction of arrow, and then remove the unit of 1st lens frame unit/2nd lens frame unit/both sides cam frame/ 2nd 3rd direct frame/3rd lens frame unit from the fixed frame unit/drive frame unit/penetration cam frame/1st...
  • Page 34 8.4.4. Removal of the 2nd Lens Frame 8.4.5. Removal of the 3rd Lens Frame Unit/Both Sides Cam Frame/2nd Unit 3rd Direct Frame/3rd Lens Frame 1. Remove the 3rd lens frame unit in the direction of the arrow. Unit 1. Turn the 2nd lens frame unit/both sides cam frame/2nd 3rd direct frame/3rd lens frame unit in the direction of the arrow (1) fully, and then remove them in the direction of the arrow (2).
  • Page 35 8.4.7. Removal of the 2nd Lens Frame 8.4.8. Removal of the 1st Direct Frame Unit Unit 1. Turn the 2nd lens frame unit in the direction of the arrow 1. Remove the 1st direct frame unit in the direction of the (1) a little, and then remove it in the direction of the arrow arrow.

  • Page 36: Assembly Procedure For The Lens

    8.5. Assembly Procedure for the 8.5.2. Phase alignment of the Drive Frame Unit/Penetration Cam Frame and Lens Fixed Frame Unit 8.5.1. Phase alignment of the Penetration Cam Frame and Drive Frame Unit...
  • Page 37 8.5.3. Phase alignment of the 2nd Lens 8.5.5. Phase alignment of the 3rd Lens Frame Unit and Both Sides Cam Frame Unit and 2nd Lens Frame Frame Unit/Both Sides Cam Frame/2nd 3rd Direct Frame 8.5.4. Phase alignment of the 2nd 3rd Direct Frame and 2nd Lens Frame Unit/Both Sides Cam Frame...
  • Page 38 8.5.6. Phase alignment of the 2nd Lens 8.5.7. Phase alignment of the 1st Lens Frame Unit/Both Sides Cam Frame/ Frame Unit/2nd Lens Frame Unit/ 2nd 3rd Direct Frame/3rd Lens Both Sides Cam Frame/2nd 3rd Frame Unit and 1st Lens Frame Direct Frame/3rd Lens Frame Unit Unit and 1st Direct Frame Unit...
  • Page 39 8.5.8. Phase alignment of the 1st Direct 8.5.9. Install of the Master Flange Unit Frame Unit/1st Lens Frame Unit/ 2nd Lens Frame Unit/Both Sides Cam Frame/2nd 3rd Direct Frame/ 3rd Lens Frame Unit and Fixed Frame Unit/Drive Frame Unit/Pene- tration Cam Frame...

  • Page 40: Removal Of The Ccd Unit

    8.5.10. Install of the Lens FPC Unit and 8.6. Removal of the CCD Unit Zoom Motor To prevent the CCD unit from catching the dust and dirt, do not remove the CCD unit except for replacing.

  • Page 41: Removal Of The Focus Motor

    8.7. Removal of the Focus Motor 8.8. Application Grease Method The grease application parts of lens unit are as follows. Apply grease additionally in the specified position if necessary. When the grease is applied, use a toothpick and apply thinly. •...

  • Page 42: Measurements And Adjustments

    9 Measurements and Adjustments 9.1. Introduction When servicing this unit, make sure to perform the adjustments necessary based on the part(s) replaced. Before disassembling the unit, it is recommended to back up the camera data stored in flash-rom as a data file. IMPORTANT NOTICE (After replacing the MAIN P.C.B.) After replacing the MAIN P.C.B., it is necessary to use the “DIAS”...
  • Page 43 9.2.2. Flash-Rom Data Backup When trouble occurs, it is recommended to backup the Flash-rom data before disassembling the unit. There are two kinds of Flash-rom data backup methods: [ ROM_BACKUP (Method of Non-PC backup) ] 1. Insert the SD-card into the camera. 2.

  • Page 44: Details Of Electrical Adjustment

    9.3. Details of Electrical Adjustment 9.3.1. How to execute the Electrical Adjustment It is not necessary to connect the camera to a PC to perform adjustments. “Flag reset operation” and “Initial setting operation” are required when carrying out the alignment, follow the procedure below. 9.3.1.1.
  • Page 45 9.3.1.3. Execute Adjustment (In case of “OIS Adjustment”) 1. Perform step “9.3.1.1.” to “9.3.1.2.”, to reset the OIS flag status “F” (Set) to “0” (Reset) 2. Press [ DISPLAY ] button after Flag reset. OIS Adjustment screen is displayed on the LCD panel. (Refer to Fig.3-4) 3.
  • Page 46 9.3.2. Adjustment Specifications The following matrix table shows the relation between the replaced part and the Necessary Adjustment. When a part is replaced, make sure to perform the necessary adjustment(s) in the order indicated. The table below shows all the information necessary to perform each adjustment.

  • Page 47: After Adjustment

    9.4. After Adjustment 9.4.1. Initial Setting Since the initial setting has been released to execute the built-in adjustment software, it should be set up again before shipping the camera to the customer. Refer to the procedure described in “3.4.2. INITIAL SETTINGS” for details. [ IMPORTANT ] 1.

  • Page 48: Maintenance

    10 Maintenance 10.1. Cleaning Lens and LCD Panel Do not touch the surface of lens and LCD Panel with your hand. When cleaning the lens, use air-Blower to blow off the dust. When cleaning the LCD Panel, dampen the lens cleaning paper with lens cleaner, and the gently wipe the its surface. Note: The Lens Cleaning KIT ;...
  • Page 49 DSC1002013CE S1. About Indication of The Schematic Diagram Service Manual S1.1. Important Safety Notice COMPONENTS IDENTIFIED WITH THE MARK HAVE THE SPECIAL CHARACTERISTICS FOR SAFETY. WHEN REPLACING ANY OF THESE COMPONENTS USE ONLY THE SAME TYPE. Diagrams and Replacement 1.Although reference number of the parts is indicated on the P.C.B. drawing and/or Parts List schematic diagrams, it is NOT mounted on the P.C.B.

  • Page 50: S2. Voltage Chart

    S2. Voltage Chart Note) Indicated voltage values are the standard values for the unit measured by the DC electronic circuit tester (high-impedance) with the chassis taken as standard. Therefore, there may exist some errors in the voltage values, depending on the internal impedance of the DC circuit tester. S2.1.

  • Page 51: S3. Block Diagram

    S3. Block Diagram S3.1. Overall Block Diagram (25mm ~ 200mm) IC3001 CCD SIGNAL PROCESSOR X6001 (24MHz) 1/2.33" 14 MEGA PIX CDS, AGC, A/D, TG, CCD DRIVER ZOOM OIS UNIT IRIS SHUTTER FOCUS CARD IC3002,3003 REGULATOR MICROPHONE IC9101 SYSTEM IC IC9101 SYSTEM IC SPEAKER MOTOR DRIVE,...

  • Page 52: S4. Schematic Diagram

    S4. Schematic Diagram S4.1. Interconnection Diagram TL8502 RL8004 ET8001 M8001 FLASH TOP P.C.B. TL8501 RL8005 MICROPHONE (COMPONENT SIDE) P8002 : (FOIL SIDE) E.CAPACITOR P.C.B. ET8002 (FOIL SIDE) SPEAKER BATTERY LCD UNIT MAIN P.C.B. (FOIL SIDE) : ( COMPONENT SIDE) FT9501 FP9501 FP9001 FP9003...

  • Page 53: S4.2. Flash Top Schematic Diagram

    S4.2. Flash Top Schematic Diagram GYRO_X(YAW) CL7304 CAUTION: FOR CONTINUED PROTECTION AGAINST FIRE HAZARD, REPLACE ONLY WITH THE SAME TYPE 1.5A 32V FUSE. ATTENTION: POUR UNE PROTECTION CONTINUE LES RISQUES 1.5A 32V D' INCENDIE N' UTILISERQUE DES FUSIBLE DE MÉME TYPE 1.5A 32V. N.C.

  • Page 54: S4.3. Ccd Flex Schematic Diagram

    S4.3. CCD Flex Schematic Diagram FT3101 CON_CHK CCD_GND CCD_GND CCD_GND 31 30 CCD_OUT V11B MSUBSW CCD_GND CCD_GND V11B [29] MSUBSW IC3101 R3107 CCD_GND MN34570PBH-V 1300 [10] [20] SUBSW2 SUBSW1 SUBSW1 SUBSW2 12 13 14 15 R3101 R3108 R3102 2200 V11B V11B V11A V11A...

  • Page 55: S4.4. Lens Flex Schematic Diagram

    S4.4. Lens Flex Schematic Diagram POSITIVE VOLTAGE LINE FZHP LED K PHOTO CO. BARREL ENCODER SENSOR FZHP (FULL RETRACT) FZHP VCC XHO+ HALL SENSOR (X) XHO- YDR- DRIVE COIL (Y) YDR+ OIS UNIT YHO- HALL SENSOR (Y) YHO+ XDR- DRIVE COIL (X) XDR+ DC SOLENOID TO MAIN...

  • Page 56: S5. Print Circuit Board

    S5. Print Circuit Board S5.1. Flash Top P.C.B. ET8011 CL7304 RL8004 34 30 TL8007 TL8004 CL7303 CL8011 PS8001 CL8010 R8013 Q8001 C8007 CL8003 CL8004 CL8006 L8001 RL8003 CL8005 CL8008 CL8201 CL8202 D8001 RL8001 (Component Side) R8010 R8009 R8011 R8008 S8002 CL7301 CL7302 RL8005...

  • Page 57: S5.2. Ccd Flex P.c.b

    S5.2. CCD Flex P.C.B. (Component Side) R3101 6 5 4 IC3101 Q3101 R3108 (Foil Side) DMC-ZX3/ZR3 CCD Flex P.C.B.

  • Page 58: S5.3. Lens Flex P.c.b

    S5.3. Lens Flex P.C.B. CO. BARREL ENCODER (FULL RETRACT) OIS UNIT B9 B8 B7 B12 B11B10 B1 B2 B3 SHUTTER UNIT C4 C3 Pin 1 ZOOM MOTOR UNIT ZOOM ENCODER 2 ZOOM ENCODER 1 Pin 41 FOCUS MOTOR UNIT DMC-ZX3/ZR3 LENS FLEX P.C.B. S-10...

  • Page 59: S6. Replacement Parts List

    ELECTROSTATIC DISCHARGE (ESD) TO ELECTROSTATICALLY SENSITIVE (ES) DEVICES section. Definition of Parts supplier: 1. Parts marked with [ENERGY] in the remarks column are supplied from Panasonic Corporation Energy Company. 2. Parts marked with [PAVCSG] in the remarks column are supplied from PAVCSG.
  • Page 60 DMC-ZX3EG-S vol.1 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks VEK0P96 CCD UNIT E.S.D. VEP56100B MAIN P.C.B. 1 EG,EP,EF,EB,PR (RTL) E.S.D. C3101 F1H1C105A097 C.CAPACITOR CH 16V VEP56100A MAIN P.C.B. 1 EE,SG,P,PC,PU,GC,GH,GT, GK,GN,GD (RTL) E.S.D. Q3101 UP05C8B00L TRANSISTOR...
  • Page 61 DMC-ZX3EG-S vol.1 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks VXW1134 LENS UNIT (W/O CCD) VEP56100B MAIN P.C.B. 1 EG,EP,EF,EB,PR VEK0P96 CCD UNIT 1 E.S.D. (RTL) E.S.D. L6DAACGC0002 ZOOM MOTOR VEP56100A MAIN P.C.B. 1 EE,SG,P,PC,PU,GC,GH,GT, VEK0P53 LENS FPC UNIT...
  • Page 62 DMC-ZX3EG-S vol.1 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks VPF1301 CAMERA BAG 1 P,PC [PAVCSG] DE-A65BA BATTERY CHARGER 1 P,PC ----- BATTERY 1 P,PC K1HA08AD0002 USB CABLE W/PLUG 1 P,PC K1HA08CD0028 AV CABLE W/PLUG 1 P,PC VFC4297 HAND STRAP...
  • Page 63 DMC-ZX3EG-S vol.1 Ref.No. Part No. Part Name & Description Remarks Ref.No. Part No. Part Name & Description Remarks VQT2L88 O/I SOFTWARE 1 SG,GC,GH VPF1301 CAMERA BAG 1 (EXCEPT P,PC) [PAVCSG] (ENGLISH/ DE-A66AA BATTERY CHARGER 1 EG,EP,EF,EB,GN CHINESE(TRADITIONAL)/ DE-A66BB BATTERY CHARGER 1 EE,GC,GH,GK,GD ARABIC/PERSIAN) DE-A66EA...

  • Page 64: S7. Exploded View

    S7. Exploded View S7.1. Frame and Casing Section 76-2 76-1 51-2 51-1 B101 B102 B103 B108 B106 104-1 B107 B109 112-3 B110 B104 B111 53-1 B105 112-2 53-2 112-1 S-16...

  • Page 65: S7.2. Packing Parts And Accessories Section (1

    S7.2. Packing Parts and Accessories Section (1) S-17...

  • Page 66: S7.3. Packing Parts And Accessories Section (2

    S7.3. Packing Parts and Accessories Section (2) (DMC-ZR3PR) (DMC-ZX3EG/EP/EF/EE DMC-ZR3GC/GD) (DMC-ZX3EB DMC-ZR3GC/GH) (DMC-ZX3SG DMC-ZR3GK/GT) (DMC-ZR3GN) S-18...
