Bluetooth in operation
1. Rotating the ON/OFF-Volume Rotary Knob
to turn on the appliance. Power indicator will
illuminate.
2. Rotate the Function Selector to "BT" position
to select the Bluetooth mode.
3. The Power indicator will illuminate blue and
flash to indicate that the speaker is under
Bluetooth pairing mode.
4. Turn on your Bluetooth audio device to go into
pairing mode to search for Bluetooth device
automatically. Navigate to your Bluetooth
device's setup screen, find "MAT10A-SP" and
follow up the on-screen instruction to setup
the connection (see the user manual of the
Bluetooth device on how to enable Bluetooth).
5. When the speaker is connected to your
Bluetooth device successfully, the blue
indicator will stop flashing and turn solid.
6. Play music from your Bluetooth device after it
is connected successfully. Adjust the ON/OFF-
Volume Rotary Knob to the desired listening
level.
Note: If your Bluetooth device is not able
to pair to the appliance, disconnect the
Bluetooth to break the previous Bluetooth
connections and try again.
The maximum operational range between the
appliance and Bluetooth device is 10 meters.
The distance may be different in different
environment or with different Bluetooth device.
The music streaming may be interrupted by
obstacles between the appliance and Bluetooth
device, such as wall, metallic casing that covers
the device, or other devices nearby that operate
in the same frequency.
Care and Cleaning
1. Always turn the appliance off and remove
the AC/DC adaptor from the outlet before
cleaning.
2. Never spray or pour liquids directly onto the
appliance, and clean with a dry towel only.
3. Do not clean the unit with strong chemical
agents or abrasive cleaners.
4. Clean the cabinet and buttons with a slightly
dampened soft cloth only.
5. Do not use a coarse cloth, abrasive materials,
or chemical cleaners such as alcohol,
benzene, etc.
6. Do not allow residue or liquids to enter into
any part of the appliance as this may cause
risk of electrocution.
7. Never allow any water or other liquids to get
inside the unit while cleaning.
Specifications
General
Power supply (AC/DC adaptor):
Input: 100-240V~50/60Hz
Output: DC 9V 1.3A
Turntable
Motor: DC servo motor
Drive system: Belt drive
Speed: 33 rpm, 45 rpm and 78 rpm
Cartridge type: Ceramic stereo cartridge
Speaker
Impedance: 4 ohm
Output power: 10W
As the result of continual improvements,
the design and specifications of the
product within may differ slightly to the
unit illustrated on the packing.
7
