Elan 8840 Integration Note

Manufacturer:
Model Number(s):
Models Tested:
Minimum Core Module Version:
Document Revision Date:
This integration note can be applied to several different Aprilaire Wi-Fi thermostat models. We will be using an "Aprilaire
8820 Thermostat" as our example.
Note: Your configuration steps may be different depending on your thermostat model. The official Aprilaire documentation
for your thermostat can be found at the following link.
O S
VERVIEW AND UPPORTED
T W F T
HE I I HERMOSTATS SUPPORT THE FOLLOWING FEATURES
Temperature Control: Temperature control can be managed by schedules tied to house modes or by manual control
based on time (Timed Temporary Hold, Temporary Hold and Permanent Hold). Temperature can be shown as either
Fahrenheit or Celsius on the viewer interface.
Mode Control: The climate system can be set to run in the following heating and cooling modes: Heat only, Cool only,
Auto Heat Cool, Emergency Heat or Off.
Fan Mode Control: Systems that have a fan can be set to run in Automatic, Continuous or Circulate mode.
History View: The history view shows the inside temperature, outside temperature, unit run and fan run times, and
cooling and heating set points.
Schedule Control: Multiple schedules can be set using the Viewer software and configured using the configurator. Up to
10 schedules can be created and are tied to the system mode.
Outside Air Temperature: The outside air temperature can be obtained from the weather information on the web, a
sensor connected to the thermostat, or monitored using an 8081 or 8082 Support Module. The outside air temperatures
can be displayed in real-time or tracked in history for each thermostat in the Viewer.
Humidistat: The 8800 series can be configured as fully functioning humidistat. The driver should automatically detect the
configuration and the UI should show the appropriate controls for humidity.
Celsius and Fahrenheit: Aprilaire Thermostats support displaying Temperatures in C or F both at the stat and in the
ELAN system. The system operates in half degree increments in Celsius, and Full degree increments in Fahrenheit.
Remote Room Temp Sensor connected directly to 8800 Thermostat: The 8800 can be configured to utilize a remote
temperature sensor in place of its on board sensor. The sensor connects directly to its T1 & T2 terminals. When properly
connected and configured this sensor will override the onboard sensor and the thermostat then reports the remote sensor
value to the system controller as its room temperature value. Please refer to the Aprilaire documentation for setup
information.
T 8800 T
HE HERMOSTATS DO
Auto Thermostat Detection: Thermostat need to be added individually. (see below)
ELAN | SpeakerCraft
1800 South McDowell Blvd., Petaluma CA 94954 • Toll Free: 800.472.5555 • Fax: 707.283.5901
Aprilaire
WiFi Thermostats: 8840, 8830, 8820, 8810
8820 rev 1.04
ELAN 7.3
5/17/17
F
EATURES
NOT
SUPPORT THE FOLLOWING FEATURES
Any feature not specifically noted as "supported" is not supported.
| Gefen | Furman | Niles | Panamax | Sunfire | BlueBOLT | Proficient |
Official Aprilaire Documentation
:
:
Integration Note
Xantech
