Elan HWRTR100 Quick Install Manual

Application:

Provides a preconfigured router for use with the HC Series of System Controllers. The router can also
be reconfigured as a wireless access point only.
Router Configuration:
The router is comple tely configured when it arrives.

Login Information:

IP Address: 192.168.0.1
User Name: Admin
Password: (none)
WAN Port is set to DHCP

Wireless Security:

Security Mode: Router will auto select WPA or WPA2
Cipher Type: Router will auto select TKIP or AES
Pre – Shared Key: 5555555555
Ports 2198 and 2199 are forwarded to 192.168.0.2
The HC series of controllers are set at the factory to DHCP.
Use G! Connect Pro to reset the HC controller's IP address to 192.168.0.2 when used with a factory configured router.
8.00"
HWRTR100 Quick Install Guide
P/N 9901179 REV A
