INSTALLATION GUIDE
BATTERY ISOLATOR
SPECIFICATION
Size:
L = 60mm, W = 50mm.
Weight:
70g.
Battery negative terminal:
M6 stud.
Operational Voltage:
8v - 18v.
Current consumption:
50mA ON, 10mA OFF
Battery negative switching current:
450A cranking, 1500A surge
Positive power switching current:
10A.
Operating temperature:
-10°C - +100°C.
Storage temperature:
-40°C - +125°C
Manufactured in U.K.
For off-road use only
Advertisement
Table of Contents
Related Manuals for Cartek XClub CK-BXC-01
Summary of Contents for Cartek XClub CK-BXC-01
- Page 1 INSTALLATION GUIDE BATTERY ISOLATOR SPECIFICATION Size: L = 60mm, W = 50mm. Weight: 70g. Battery negative terminal: M6 stud. Operational Voltage: 8v - 18v. Current consumption: 50mA ON, 10mA OFF Battery negative switching current: 450A cranking, 1500A surge Positive power switching current: 10A.
- Page 2 Battery Isolator may occur. (This does not apply to cars without alternators) ● Do not use the CARTEK Internal ON/OFF pushbutton switch for any other application, it is designed specifically for use with CARTEK Battery Isolators only.
- Page 3 THIS PRODUCT IS DESIGNED FOR MOTORSPORT USE ONLY AND SHOULD NOT BE USED ON ROAD/STREET VEHICLES OR ON PUBLIC HIGHWAYS. NO WARRANTY IS MADE OR IMPLIED REGARDING ANY CARTEK PRODUCTS TO PROTECT USERS FROM INJURY OR DEATH. USER ASSUMES ALL RISKS.
- Page 4 Note that, when the Battery Isolator is in the OFF state the integrated LED will flash Blue very slowly to indicate that it is connected to the battery and receiving power. CARTEK AUTOMOTIVE ELECTRONICS LTD Unit 25, Mitchell Point Tel: +44 (0) 2380 457747 Ensign Way, Hamble Email: info@cartekmotorsport.com...
