Page 1: User Manual
Copyright © 2007 Godex Europe GmbH All rights reserved C-680 LabelJet User Manual Godex Europe GmbH Arnzhäuschen 36 D-42929 Wermelskirchen Phone: +49 (0)2193–53396 0 Fax: +49 (0) 2193–53396 69 Email: info@godex.eu Web: www.godex.eu... - Page 2 Output Solutions C-680 LabelJet Printer 1. Edition, January 2006 2. Edition, August 2007 Copyright 2006 Godex Europe GmbH Notice The information in this user manual is subject to change without prior notice! Godex Europe does not offer any warranty: •...
-
Page 3: Table Of Contents
Pull-down Menu [1] ... 20 Which Label material do you use? [2]... 21 Do TOF after each Label [3]... 21 Cut/Tear Mode [4] ... 21 Tear/Cut Position Adjustment [5] ... 22 Save Settings and Load Profile [6]... 22 Output Solutions C-680 LabelJet Printer Page... - Page 4 VIII. Troubleshooting ... 27 Printer does not print... 27 Check printer-LEDs... 27 Despite pressing the power switch the printer remains switched off ... 28 Check printer cable connections ... 28 Printer still does not print... 28 Poor print quality ... 29 Document is misprinted...
-
Page 5: Scope Of Delivery Of Output Solutions C-680 Labeljet Printer
Scope of delivery of Output Solutions C-680 LabelJet Printer Your printer will be delivered in a carton with the following contents: Printer (Packed in a plastic bag and foam cushions) Accessories 1. Power supply unit (the appearance may differ from the... -
Page 6: Terms And Conventions
Terms and conventions The following terms and conventions are used in this user’s manual. Terms The Output Solutions C-680 LabelJet Printer is also specified as C-680 printer or simply as printer. Conventions • marks a listing marks instructions as shown on pictures ⇒... -
Page 7: Connectivity
The cable should not be longer than 3 meter. External Ethernet print server (optional) The printer can also be connected with a Ethernet print server to a network. Fast Ethernet print server should be connected to the parallel port of the printer and to the LAN. -
Page 8: Printer Overview
Printer overview 1 Power switch 2 Paper tear off sensor (only available with C-680 Standard) 3 Paper tear off edge 4 Button (no function) 5 Resume button and -LED 10 Label roll holder and label roll rod Print cartridge status symbol and -LED... -
Page 9: Power Switch [1]
Power switch [1] The printer can be switched on and off with the power switch. After pushing the button it will take a couple seconds until the printer is ready. The power- LED starts flashing when the computer processes data. -
Page 10: Print Cancel Button [7]
Print cancel button [7] Pressing the print cancel button cancels the current print job. The indicator of the Gap / Black Mark sensor position [9] Sensor lever for adjustment of the Gap/Black Mark-Position. -
Page 11: Installation
If you do not have administrator rights, the administrator has to install the driver software! Connect printer without label roll unit Position the printer at its allocated space. Connect the printer to the mains supply by connecting the low voltage plug with the printer. - Page 12 Connect the power supply with a 230V power socket. Press power switch. Check if printer is turned on. Open top cover. Unpack Tri-Color print cartridge and take off the protection tape. Lift the print cartridge latch. Caution!: Do not touch nozzles or electric contacts!
- Page 13 Connect the USB-cable to the USB-port of the printer and connect the printer to the computer, or Connect the parallel cable to the parallel port of the printer and connect the printer to the computer. Note: USB or Parallel cables are not part of the delivery! Note: Calibrate the print head after each cartridge exchange.
-
Page 14: Calibrate Print Heads
Calibrate print heads Slide paper guides [1] firmly against the paper and slide the DIN A4/letter sized paper sheet forward until got stuck [2]. Uplift the top cover and check if the paper is slided in properly [2]. - Page 15 Open START/PROGRAMS and open the program C-680 (XP screen).
- Page 16 The LABELPRINTER ADMINISTRATION TOOLBOX will be displayed. Select the printer driver C-680 LabelJet. Click on button PRINTER CONTROL. ⇒ The PRINTER CONTROL BOX opens. Click on button CALIBRATE PRINTHEADS ⇒ A calibration test page will be printed.
-
Page 17: Calibrate Printer To Label Size
Calibrate printer to label size In the PRINTER CONTROL BOX click on button CALIBRATE SENSOR. The driver calibrates the sensor to the label and the label carrier. After that the GAP-/BLACKMARK sensor is able to detect the gap between Measure the width of the label roll. -
Page 18: Install Roll Unit
Insert roll rod [1] into the core of the label roll until it is at its place [2]. Attach roll unit to the back of printer by sliding it into the slots positioned at both sides of the paper entry. - Page 19 Press the power and resume button at the same time or click on the button LOAD/UNLOAD in the PRINTER CONTROL BOX ⇒The label material will be Click on the CALIBRATE SENSOR button. ⇒ The CALIBRATE SENSOR window opens. Enter the height of your label in the box (reg. label terms see chapter X.
-
Page 20: Labelprinter Administration Tool
Labelprinter Administration Tool LABELPRINTER SETTINGS Pull-down Menu [1] Select the C-680 LabelJet printer driver. With the Labelprinter Administration Tool you can manage several C-680 printers. Confirm your selection by clicking on “SELECT” button. -
Page 21: Which Label Material Do You Use? [2]
The printer stops after the last printed label of the printjob. • Button: Tear/Cut after each label The printer will stop after each printed label and waits till the printed label is torn off. Then the printer starts printing the next label. •... -
Page 22: Tear/Cut Position Adjustment [5]
• Tear/Cut after each print job The printer will stop after each print job and is going to wait till the printed labels are torn off. • Select the time after Tear off This options defines the time the printer is going to wait before printing... -
Page 23: Labelprinter Control
Calibration [1] • Button: Calibrate Sensor After changing from GAP to BlackMark and vice versa you have to calibrate the printer. (see chapter V.Installation) • Button: Calibrate Printheads After changing the print cartidges it is recommended that you calibrate the print heads. This ensures that you always have excellent print quality. -
Page 24: Statistic/Diag [3]
Print a diagnosis pattern to check if all nozzles work properly • Button: Print Statistic Page Print a statistic page and get valuable information about your printer like serial number, total page count, firmware etc. Printer[4] Turn your printer ON with the toolbox Printer Control [5] •... -
Page 25: Ink Level Popup [6]
C-680 with metal housing and an installed cutter) • Button: Print Test Label Print a predefined label to check if the printer and the print head is working properly. Ink level Popup [6] Activate or deactivate the ink level popup which appears with every... -
Page 26: Quick Operating Guide
Quick Operating Guide Load labels Press the power and resume button at the same time or use the LOAD/UNLOAD function in the PRINTER CONTROL BOX. ⇒ The labels will be transported to the first print line. Print labels Find out the exact label size. -
Page 27: Troubleshooting
Please change cartridge that are low on ink. If no print cartridge is low on ink press the resume button. If the print cartidge status-LED is still flashing switch printer off and on again. If print cartridge status-LED is on and flashing... -
Page 28: Despite Pressing The Power Switch The Printer Remains Switched Off
All LEDs are flashing The printer may need a restart. Press power button to switch printer off and then to switch it on again. If LED is still flashing switch printer off. Disconnect the printer’s power cord out of the power outlet. -
Page 29: Poor Print Quality
• Parts of the document are missing or not centered: Open dialog box PRINTER PROPERTIES and confirm the following options: tab EFFECTS RESIZING OPTIONS: appropriate paper size SCALE TO FIT: activate this option that text and graphics will be adjusted to the paper format. -
Page 30: Photos Are Not Printed Correctly
If colors are still tinted or incorrect clean print cartride or change cartridges. • If colors are still tinted or incorrect, then open the dialog box PRINTER PROPERTIES, select the tab COLOR, then COLOR ATTRIBUTES and then do the following: If colors are too yellow move the slider towards cooler. -
Page 31: Printer Doesn't Feed Any Paper
ADMINISTRATION TOOL. Resume light is flashing • Paper tray may be empty or there may be a paper jam. After several print processes the printer start passing labels through without printing • The manual sensor setting GAP/BLACKMARK has been changed. -
Page 32: Disposal
If you still have problems after restarting your computer please contact the hotline at info@godex.eu or contact the Godex Europe customer support +49 (0)2193-53396 0 Disposal Please return your C-680 LJ to Godex Europe GmbH... -
