Summary of Contents for Oregon Scientific PSM02A
- Page 1 Full Weather Station with Radio Controlled Clock and Projection (Model #: PS-M02 / PS-M02U) User Manual PS M02 English Cover R7 op 7/24/03, 11:57 AM Black...
-
Page 2: Table Of Contents
TABLE OF CONTENTS About this guide ... 2 Product overview ... 3 Getting started ... 8 Batteries ... 8 AC power adapter ... 8 Switch between modes ... 8 Change settings ... 9 Remote unit setup ... 9 Clock ... 10 Alarm ... -
Page 3: About This Guide
ABOUT THIS GUIDE Congratulations on your selection of the Philippe Starck with Oregon Scientific Full Weather Station with Radio Controlled Clock and Projection (PS-M02 / PS-M02U). This powerful device bundles time keeping, alarm, indoor and wireless outdoor temperature and humidity... -
Page 4: Product Overview
PRODUCT OVERVIEW TOP VIEW PS M02 English R18 op Black DESCRIPTIONS Snooze / Light button Light sensor Projection lens 7/24/03, 11:56 AM... -
Page 5: Lcd Display
LCD DISPLAY PS M02 English R18 op Black DESCRIPTIONS Low battery icon Clock Barometer Weather forecast Moon phase Calendar Temperature and humidity Alarm 7/24/03, 11:56 AM... -
Page 6: Back View
BACK VIEW PS M02 English R18 op Black BUTTON DESCRIPTIONS Select - switch modes / change settings Focus - focus projector Up - increase setting / activate auto-synch Down - decrease setting / deactivate auto-synch Rotation - rotate projector Alarm -activate / deactivate alarm Channel - switch remote unit 7/24/03, 11:56 AM... - Page 7 BOTTOM AND SIDE VIEW PS M02 English R18 op Black DESCRIPTIONS Battery compartment Backlight switch Reset button Light sensitivity knob DC power input jack NOTE AC power adapter not shown. 7/24/03, 11:56 AM...
-
Page 8: Remote Unit
REMOTE UNIT PS M02 English R18 op Black DESCRIPTIONS Temperature / Trend display Low battery icon Humidity / Trend / Comfort Level display °C/°F switch Channel switch Reset button Battery compartment Wall-mount hole Battery compartment lid 7/24/03, 11:56 AM... -
Page 9: Black
GETTING STARTED BATTERIES Batteries for the remote and main units are supplied with this product. Replace them whenever the low battery signal ( ) displays. Remove the battery compartment lid on the bottom of the main unit, and insert the batteries. You will need a small Phillips screwdriver to remove the remote unit compartment lid. -
Page 10: Change Settings
CHANGE SETTINGS Press and hold SELECT for 2 seconds. Then, press UP or DOWN to change each setting. Press SELECT to switch options. REMOTE UNIT SET UP Up to 3 remote units can be used with this product to monitor outdoor temperature and humidity. The measurement unit (°C or °F) and channel number (1, 2, or 3) switches are located in the battery compartment, and should be set prior to installation. -
Page 11: Clock
CLOCK This product can automatically synchronize the date and time with official time-keeping organizations in Frankfurt, Germany (PS-M02) or Rugby, England (PS-M02U). When the unit is within 1500 km (932 miles) of a RF signal, the reception icon will blink during reception. -
Page 12: Set Alarm
SET OR CHANGE THE CLOCK Press SELECT to switch to the Clock Mode. The time will flash. Press and hold SELECT for 2 seconds to enter the setting mode. Select the 12/24-hour format, hour, and minute. Press UP or DOWN to change the setting. Press SELECT to confirm. -
Page 13: Calendar
TO TURN THE ALARM OFF OR ON Press any button to stop the alarm. To turn the alarm off completely (deactivate it for the next day), press ALARM. CALENDAR SET DATE Clock auto-synchronization must be deactivated before you manually set the date. ( Press SELECT several times until the calendar area flashes. -
Page 14: Barometer
BAROMETER This product tracks barometric pressure changes over the past 24 hours to provide the weather forecast 14) and a trend line showing the direction of barometric change. Barometric changes are measured by the main (indoor) unit. BAROMETRIC TREND The barometric trend arrow for the last 30 minutes is always displayed. -
Page 15: Black
SET UNIT AND ALTITUDE You can set the unit of measurement (mb/hPa or inHg) and altitude. Setting the altitude allows the product to take more accurate barometric measurements. Press SELECT 2 times until the Barometer Area flashes. Press and hold SELECT for 2 seconds. Select altitude (-100 meters to 2500 meters in increments of 10) and the unit of measurement (mb/hPa or inHg). -
Page 16: Clear Min / Max Records
Temperature is given at the top; humidity is below. VIEW MIN / MAX / CURRENT MEASUREMENTS Press SELECT 3 times until the Temperature and Humidity Areas flash. Press UP or DOWN to scan the readings. CLEAR MIN / MAX RECORDS While viewing Min/Max records, press and hold UP or DOWN for 2 seconds until a beep sounds. -
Page 17: Comfort Zone
NOTE Signals from household electrical appliances such as doorbells and home security systems can cause temporary reception failures between the indoor and outdoor units. This is normal and does not affect the general performance of the product. Reception will automatically resume once the interference ends. -
Page 18: Backlight
TRENDS The trend arrow for the last 30 minutes always displays. Indoor and outdoor temperature and humidity trends are shown separately. Trend Temperature Relative Humidity + 0.5 °C Steady Steady -0.5 °C PS M02 English R18 op Black SET UNIT While in Temperature / Humidity Mode, press SELECT for 2 seconds. -
Page 19: Projector
Move it to the “AUTO” position to enable continuous backlight controlled by light intensity. When activated, the backlight will be on whenever the unit perceives that the room is dark. The Light Sensitivity knob switch is located in the battery compartment. Rotate to adjust. LIGHT SENSOR LIGHT ON OFF... -
Page 20: Focus Image
FOCUS IMAGE The FOCUS switch is located on the back of the unit. Rotate to adjust. CONTINUOUS PROJECTION The AC power adapter must be plugged in to use this feature ( Press and hold SNOOZE/LIGHT for 2 seconds when the projection is on. When activated, the time and alarm status will project continuously. -
Page 21: Safety And Care
SAFETY AND CARE Wash the unit with a slightly damp cloth and mild detergent. Avoid dropping the unit or placing it in a location where the AC power adapter will be stepped on. WARNINGS This product is designed to give you years of service if handled properly. -
Page 22: Troubleshooting
TROUBLESHOOTING Check here before contacting our customer service department. Problem Symptom Remedy Temp Shows “LLL” or Temperature is out- “HHH” of-range. Strange date / Calendar Change language month Backlight No continuous Plug in AC power backlight adapter. Check the BACKLIGHT switch. 8, 17) Projector Plug in AC power... -
Page 23: Specifications
Problem Symptom Remedy 4. Place clock near window / away from electrical devices, and wait 10 - 20 minutes. If it still fails, you may be too far from a signal. Cannot Disable auto- change synchronization clock Baro Strange reading Set altitude / unit PS M02 English R18 op Black... - Page 24 Remote Unit: -20 °C to 60 °C (-4 °F to 140 °F) 0.1 °C (0.2 °F) Resolution 20 °C to 25 °C (68 °F to 77 °F) Comfort (see also, Relative humidity) Memory Minimum / maximum + /- 0.5 °C ( + /- 0.9 °F) change Trend Relative humidity Range...
- Page 25 Radio-controlled clock Synchronization Auto or disabled Clock display HH:MM:SS Hour format 12hr AM/PM (MSF format) 24hr (DCF format) Calendar DD/MMM; weekday selection in 5 languages (E, D, F, I, S) Moon phase High, medium, and low tide Alarm 7 melody; 2 minute crescendo Snooze 8 minutes Projector...
-
Page 26: Additional Resources
ADDITIONAL RESOURCES Visit our website (www.oregonscientific.com) to learn more about your new product and other Oregon Scientific products such as digital cameras, hand-held organizers, health and fitness gear, and weather stations. The website also includes contact information for our customer service department, in case you need to reach us. -
Page 27: Ec Declaration Of Conformity
R&TTE Directive 1999/5/EC (appendix II) and carries the respective CE marking. VS-Villingen / Germany August 2003 Gerhard Preis R&TTE Representative of manufacturer RTT&E Compliant Countries: All EC Countries, Switzerland and Norway ©2003 Oregon Scientific. All rights reserved. 7/24/03, 11:57 AM...
