Full weather station with radio controlled clock, projection and am/fm radio

Advertisement

Full Weather Station with Radio Controlled Clock,
Projection and AM/FM Radio
(Model #: PS-L06 / PS-L06U)
User Manual
PS-L06_GB-final.p65
1
8/8/03, 12:02 PM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Starck PS-L06 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Oregon Scientific Starck PS-L06

  • Page 1 Full Weather Station with Radio Controlled Clock, Projection and AM/FM Radio (Model #: PS-L06 / PS-L06U) User Manual PS-L06_GB-final.p65 8/8/03, 12:02 PM...
  • Page 2 PS-L06_GB-final.p65 8/8/03, 12:02 PM...
  • Page 3: Table Of Contents

    TABLE OF CONTENTS About this guide ... 2 Product overview ... 3 Getting started ... 8 Batteries ... 8 AC power adapter ... 8 Switch between modes ... 9 Change settings ... 9 Remote unit setup ... 9 Clock ... 10 Alarm ...
  • Page 4: About This Guide

    Congratulations on your selection of the Philippe Starck with Oregon Scientific Full Weather Station with Radio-Controlled Projection Clock and AM/FM Radio (PS-L06 / PS-L06U). This powerful device bundles time keeping, alarm, indoor and wireless outdoor tempera- ture and humidity monitoring, weather forecasting, projection, and digital AM/FM radio into a single tool you can use from the convenience of your home.
  • Page 5: Product Overview

    PRODUCT OVERVIEW TOP VIEW PS-L06_GB-final.p65 DESCRIPTIONS Snooze / Light button (→ 12, 19) Light sensor (→ 19) Projection lens (→ 20) 8/8/03, 12:02 PM...
  • Page 6: Lcd Display

    LCD DISPLAY PS-L06_GB-final.p65 DESCRIPTIONS Low batteries icon (→ 8) Clock (→ 10) Barometer (→ 13) Weather forecast (→ 15) Moon phase (→ 13) Calendar (→ 12) Temperature and humidity (→ 15) Alarm (→ 11) Radio (→ 18) 8/8/03, 12:02 PM...
  • Page 7: Back View

    BACK VIEW PS-L06_GB-final.p65 BUTTON DESCRIPTIONS Focus – focus projector (→ 20) Select – switch modes / change settings Rotation – rotate projector (→ 20) Up – increase setting / activate auto-synch (→ 11) Down – decrease setting / deactivate auto-synch (→ 11) Alarm –activate / deactivate alarm (→...
  • Page 8: Bottom View

    BOTTOM VIEW PS-L06_GB-final.p65 DESCRIPTIONS Battery compartment (→ 8) Light sensitivity knob (→ 20) Reset button (→ 8, 21) Antenna (→ 18) Headphone jack (→ 19) DC power input jack (→ 8) Backlight switch (→ 19) NOTE AC power adapter not shown. 8/8/03, 12:02 PM...
  • Page 9: Remote Unit

    REMOTE UNIT PS-L06_GB-final.p65 DESCRIPTIONS Temperature / Trend display Low battery icon Humidity / Trend / Comfort Level display °C / °F switches Channel switches Reset button Battery compartment Wall-mount hole Battery compartment lid 8/8/03, 12:02 PM...
  • Page 10: Getting Started

    GETTING STARTED BATTERIES Batteries for the remote and main units are supplied with this product. Replace them whenever the low battery signal ( ) displays. Remove the battery compartment lid on the bottom of the main unit, and insert the batteries. Use a small Phillips screwdriver to remove the remote unit compartment lid.
  • Page 11: Switch Between Modes

    SWITCH BETWEEN MODES Press SELECT. The select mode will flash. The display will stop flashing if no key is pressed within 5 seconds. CHANGE SETTINGS Press and hold SELECT for 2 seconds. Then, press UP or DOWN to change each setting. Press SELECT to switch options.
  • Page 12: Clock

    This product can automatically synchronize the date and time with official time-keeping organizations in Frankfurt, Germany (PS-L06) or Rugby, England (PS-L06U). When the unit is within 1500 km (932 miles) of a RF signal, the reception icon will blink during reception.
  • Page 13: Set Alarm

    TO DISABLE OR ENABLE AUTO- SYNCHRONIZATION In Clock mode, Press DOWN for 2 seconds to disable the auto-synchronization. The unit will not respond to radio signals until you reactivate the synchronization. To enable auto-reception, press UP for 2 seconds. SET OR CHANGE THE CLOCK Press SELECT to switch to the Clock Mode.
  • Page 14: Calendar

    SELECT to confirm. If you choose , also select the melody (1 – 7) and volume level (Lo or Hi). If you choose , use the radio control buttons to select the AM/FM band, radio station and volume level (→ 18). Press SELECT again when you are finished.
  • Page 15: Moon Phase

    Select the year, month, date, and language. Press UP or DOWN to change the setting. Press SELECT to confirm. NOTE The language options are (E) English, (F) French, (D) German, (I) Italian, and (S) Spanish. MOON PHASE Press SELECT until the Calendar Area flashes. Then, press UP or DOWN to change the date and view the corresponding moon phase.
  • Page 16: Barometric Trend

    BAROMETRIC TREND The barometric trend arrow for the last 30 minutes is always displayed. Trend Description Pressure change (mb/hPa) 1 hr 6 hr Rising Steady Steady Steady Failing PS-L06_GB-final.p65 VIEW THE LAST 24 HOURS Press SELECT 2 times until the Barometer Area flashes.
  • Page 17: Weather Forecast

    WEATHER FORECAST This product forecasts the next 12 to 24 hours of weather within a 30 to 50 km (19 - 31 mile) radius with 70 to 75 percent accuracy. The weather forecast is always displayed. Partly Clear Rainy Cloudy Cloudy PS-L06_GB-final.p65 TEMPERATURE AND HUMIDITY...
  • Page 18: Select Remote Unit Channel

    clears the previous measurements from the memory. SELECT REMOTE UNIT CHANNEL While in the Temperature / Humidity Mode, press CHANNEL to switch between CH 1, 2, or 3, or press and hold CHANNEL for 2 seconds to enter Auto scan mode.
  • Page 19: Comfort Zone

    COMFORT ZONE The indoor and outdoor comfort zones are shown for the following conditions. Zone Temperature Temperature Relative Humidity >70% <40% 20 – 25 ° C 40 – 70% (68 - 77 ° F) Comfort PS-L06_GB-final.p65 TRENDS The trend arrow for the last 30 minutes always displays. Indoor and outdoor temperature and humidity trends are shown separately.
  • Page 20: Radio

    SET UNIT While in Temperature / Humidity Mode, press SELECT for 2 seconds. Press UP or DOWN to switch between °C and °F. Press SELECT to confirm. RADIO You can listen to PLL digital radio broadcasts with this product. ANTENNA The antenna wire is located in the battery compartment.
  • Page 21: Sleep Timer

    STORE STATION TO MEMORY Press STATION for 2 seconds. The assigned number (1 – 8) will show in the Radio Area. SLEEP TIMER Press SLEEP. To change the timer length (0 – 120 minutes in increments of 10) press UP or DOWN. The radio automatically turns off when the timer reaches 0.
  • Page 22: Projector

    The Light Sensitivity knob is located in the battery compartment. Rotate to adjust. When activated, the continuous backlight will be half as bright as usual. To achieve full brightness, press SNOOZE/LIGHT. PROJECTOR This product has a built-in projector for viewing time and alarm status at night.
  • Page 23: Continuous Projection

    CONTINUOUS PROJECTION The AC power adapter must be plugged in to use this feature (→ 8). Press and hold SNOOZE/LIGHT for 2 seconds. when the projection is on. When activated, the time and alarm status will project continuously. Press and hold SNOOZE/LIGHT for 2 seconds again to deactivate.
  • Page 24: Warnings

    WARNINGS This product is designed to give you years of service if handled properly. Observe the following guidelines: • Never immerse the unit in water. This can cause electrical shock and damage the unit. • Do not subject the main unit to extreme force, shock, or fluctuations in temperature or humidity.
  • Page 25 Problem Symptom Remedy No continuous Projector Plug in AC power backlight or adapter projection (→ 8, 21) No continuous Backlight Plug in AC power backlight or adapter projection (→ 8, 19) Reception is Select radio format Radio poor / static (→...
  • Page 26: Specifications

    Problem Symptom Remedy 4. Place clock near window / away from electrical devices, and wait 10 – 20 minutes. If it still fails, you may be too far from a signal. Disable auto- Cannot change synchronization clock (→ 11) Set altitude / unit Strange Baro (→...
  • Page 27 Remote Unit: -20 ˚C to 60 ˚C (-4 ˚F to 140 ˚F) 0.1 °C (0.2° F) Resolution 20 °C to 25 °C (68 °F to 77 °F) Comfort (see also, Relative humidity) Memory Minimum / maximum Trend +/- 0.5 ˚C (+/- 0.9 ˚F) change Relative humidity Range Main &...
  • Page 28 Channel No. 1, 2, or 3 °C or °F Unit Radio-controlled clock Synchronization Auto or disabled Clock display HH:MM:SS Hour format 12hr AM/PM (MSF format) 24hr (DCF format) Calendar DD/MMM; weekday selection in 5 languages (E, D, F, I, S) Moon phase High, medium, and low tide Alarm...
  • Page 29: Additional Resources

    Power Main unit 4 x UM-3 (AA) 1.5V alkaline batteries (back-up) AC/DC 7.5V power adapter (for normal operation and continuous backlight and projector) Remote unit 2 x UM-4 (AAA) 1.5V alkaline batteries ADDITIONAL RESOURCES Visit our website (www.oregonscientific.com) to learn more about your new product and other Oregon Scientific products such as digital cameras, hand-held organizers, health and fitness gear, and weather...
  • Page 30: Ec Declaration Of Conformity

    R&TTE Directive 1999/5/EC (appendix II) and carries the respective CE marking. VS-Villingen / Germany August 2003 Gerhard Preis R&TTE Representative of manufacturer RTT&E Compliant Countries: All EC Countries, Switzerland CH , and Norway © 2003 Oregon Scientific. All rights reserved. 8/8/03, 12:03 PM...
