- Page 1 JA-2MECD JA-2HCD JA-2MCD HANDSFREE COLOR VIDEO INTERCOM JA-2MECD Master monitor station(with Picture memory) JA-2MCD Master monitor station JA-2HCD Sub monitor station INSTALLATION & OPERATION MANUAL 834571 1004 B...
-
Page 2: Package Contents
PACKAGE CONTENTS General Precautions JA-2MECD JA-2MCD JA-2HCD Package contents 1 JA-2MECD, JA-2MCD or JA-2HCD 2 Packet of screws 3 Optional function connector 4 Door release connector 5 Mounting bracket 6 INSTALLAITON & OPERATION MANUAL INSTALLATION Installation locations 1. - Page 3 JA-2MECD JA-2MCD JA-2HCD JA-DAC JA-DAC B1, B2 B1, B2 JA-2SD JA-2HCD JA-2MECD JA-2MCD JA-DAC B1, B2 JA-2HCD JA-2MECD JA-2MCD JA-DAC B1, B2 Wiring method Wire the inside stations in a station-to-station (daisy-chained) manner. (x2) JA-2MECD JA-2MCD JA-DAC JA-D Cable 1. Use 2-conductor, non-shielded cable. Vinyl-jacketed cable with PE(polyethylene) insulated wires is recommended.
- Page 4 PS-2420DIN 24V DC2A PS-2420 100V-240V~ 50/60Hz PS-2410DIN DC24V IN 230V~ 50/60Hz 24V DC1A DC 24V JA-2HCD JA-2MECD JA-2HCD JA-2HCD JA-2MECD JA-2HCD JA-2SD 230V AC IN 230V~ 50/60Hz 2A - + 24V DC 230V AC 1A - + JA-2SD SUB IN...
- Page 5 Wiring Insert the wire into the terminal securely. [1] Master monitor station JA-2MECD, JA-2MCD [2] Sub monitor station JA-2HCD or Sub master station JA-2SD (Audio only) [3] Video door station JA-DAC [4] Video or audio door station JA-DAC, JA-D [5] Power supply +, – (DC 24V) [6] OPTION Door release EL-9S (12V AC 0.35A) or equivalent...
- Page 6 TALK LIGHT VIDEO OUT OFF AUTO [14] [15] Names (JA-2MCD / JA-2HCD) [1] LCD (4 inch color) [2] POWER Switch [3] Speaker for chime & internal pre-tone/voice [4] Motion detect camera SET button (JA-2MCD only) [5] Mic. [6] Door call-in LED (red)
- Page 7 OPERATIONS Pan and tilt the door station camera The monitor station is equipped with Aiphone's exclusive Pan- and-Tilt control pad. When the video door station is on, press on each edge of pad to move the camera up down and right left.
- Page 8 Answering a door call (MANUAL Press to Talk mode) 1. Momentarily press CALL button. 2. Chime tone sounds, and the visitor’s voice is heard. The monitor turns on with caller’s image. Door call-in LED 1 or 2 is lit. 3. Depress and hold down TALK button for 1 second or more. 4.
-
Page 9: Picture Memory
PICTURE MEMORY 1 sec 9 sec 1 / JAN / 0 1 Automatic picture memory When video door station calls in, picture memory is automatically activated (JA-2MECD only). REC button is steadily lit to indicate. Put JA-2MECD in Surveillance-SET mode to receive image from Motion-detection camera. - Page 10 1 2 / O C T / 0 3 1 4 : 3 0 2 0 0 1 S E P 1 5 :3 0 JA-2MECD Erase While replaying Display the picture to be erased on monitor. Holding down SET button, press “REC”...
-
Page 11: Technical Precautions
AC 12V, 0.35A (dry closure contact L, L). Run a separate cable for audio/video signal and door release contact. 210H x 160W x 42D(mm). 8-1/4”H x 6-5/16”W x 1-5/8”D. 820g (1.81 lbs.) (aprox.) (JA-2MECD) 770g(1.70 lbs.) (approx.) (JA-2MCD) 730g (1.61 lbs.) (approx.) (JA-2HCD) - Page 12 This warranty does not cover batteries or damage caused by batteries used in connection with the unit. This warranty covers bench repairs only, and any repairs must be made at the shop or place designated in writing by Aiphone. Aiphone will not be responsible for any costs incurred involving on site service calls.
