INTRODUCTION
Thank you for purchasing the Oregon Scientific weather station.
This weather station has been designed specifically with
performance and ease of use in mind. As with all Oregon
Scientific products, this barometer is made to the highest quality
standards using precision electronic components and should give
you many years of trouble free use. Please note that the accuracy
of the weather forecasting is about 70 ~ 75 percent.
FEATURES & KEY CONFIGURATION
A
B
D
WEATHER STATION
MODEL: BHB613
USER'S MANUAL
A.
WEATHER FORECAST WINDOW
Weather forecast indication shows sunny, slightly cloudy,
cloudy and rainy.
B.
PRESSURE READING WINDOW
Displays the current pressure reading.
C.
PRESSURE TREND CHART WINDOW
D.
[SET] button
To set the altitude
E.
[UP] button
Increases the value of setting by 10
F.
[DOWN] button
Decreases the value of setting by 10
G.
[RESET] BUTTON
Returns all settings to default value and erases all memories.
H.
[hPa/mb-inHg] Slide switch
Selects between hPa/mb or inHg display unit.
C
F
E
1
G
H
Advertisement
Related Manuals for Oregon Scientific BHB613
Summary of Contents for Oregon Scientific BHB613
- Page 1 INTRODUCTION Thank you for purchasing the Oregon Scientific weather station. This weather station has been designed specifically with performance and ease of use in mind. As with all Oregon Scientific products, this barometer is made to the highest quality standards using precision electronic components and should give you many years of trouble free use.
- Page 2 BATTERT INSTALLATION The unit uses four UM-4 "AAA" size batteries. If the " indicator appears, removes the exhausted batteries and follow these steps to replace the batteries: 1. Unscrew the battery door at the bottom of the unit. 2. Remove the battery cover and insert the batteries as indicated by the polarity symbols (+ and -) marked inside the battery compartment.
- Page 3 HOW TO SELECT THE BAR OR LINE CHART FOR THE PRESSURE TREND - To get the line chart display, press the [RESET] button at the bottom of the unit while pressing and holding the [SET] key in the bar chart display. - To get the bar chart display, press the [RESET] button once.
-
Page 4: Customer Assistance
SPECIFICATION Pressure measuring range 794 to 1050 hPa/mb ( 24.45 to 31.00 inHg) Altitude compensation for barometric pressure reading -100 to 2500 meters (-328 to 8223 feet) Pressure display resolution 1 hPa/mb (0.03inHg) Pressure sampling cycle 15 minutes Power source Four pcs.
