WEATHER STATION
MODEL: BHB613
USER'S MANUAL
INTRODUCTION
Thank you for purchasing the Oregon Scientific weather station. This
weather station has been designed specifically with performance and ease
of use in mind. As with all Oregon Scientific products, this barometer is
made to the highest quality standards using precision electronic components
and should give you many years of trouble free use. Please note that the
accuracy of the weather forecasting is about 70 ~ 75 percent. When
monitoring changes in barometric pressure alone, therefore, we cannot be
held responsible for any trouble which may come up due to a wrong
forecast with this unit.
FEATURES & KEY CONFIGURATION
A
B
C
D
F
E
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Oregon Scientific BHB613
Summary of Contents for Oregon Scientific BHB613
- Page 1 Thank you for purchasing the Oregon Scientific weather station. This weather station has been designed specifically with performance and ease of use in mind. As with all Oregon Scientific products, this barometer is made to the highest quality standards using precision electronic components and should give you many years of trouble free use.
- Page 2 WEATHER FORECAST WINDOW Weather forecast indication shows sunny, slightly cloudy, cloudy and rainy. PRESSURE READING WINDOW Displays the current pressure reading. PRESSURE TREND CHART WINDOW [SET] button To set the altitude [UP] button Increases the value of setting by 10 [DOWN] button Decreases the value of setting by 10 [RESET] BUTTON...
- Page 3 BATTERY INSTALLATION The unit uses four UM-4 "AAA" size batteries. If the " " indicator appears, removes the exhausted batteries and follow these steps to replace the batteries: 1. Unscrew the battery door at the bottom of the unit. 2. Remove the battery cover and Insert the batteries as indicated by the polarity symbols (+ and -) marked inside the battery compartment.
- Page 4 2. The weather forecast symbols may not reflect the current weather condition. The symbols are forecasting the future. 3. A ' Sunny ' forecast covering the night-time reflects fine clear weather. HOW TO READ THE PRESSURE TREND CHART Stored memory of the barometric pressure changes are displayed on the chart, in 5 steps indicating the pressure 1,3,6,12 and 24 hours ago.
- Page 5 HOW TO SELECT THE BAR OR LINE CHART FOR THE PRESSURE TREND To get the line chart display, press the [RESET] button at the bottom of the unit while pressing and holding the [SET] key in the bar chart display. To get the bar chart display, press the [RESET] button once.
- Page 6 Connector: Use wall-mount connector to align with other wall-mount bracket if necessary. Wall Mount Connector CONNECTOR Wall Mount Bracket Un-install the brackets: MAINTENANCE When handled properly, this unit is engineered to give you years of satisfactory service. Here are a few product care instructions: 1.
- Page 7 SPECIFICATION Pressure measuring range 794 to 1050 hPa/mb (24.45 to 31.00 inHg) Altitude compensation for barometric pressure reading -100 to 2500 meters Pressure display resolution 1 hPa/mb (0.03inHg) Pressure sampling cycle 15 minutes Power source Four pcs. UM-4 or “AAA” size batteries Battery life 9 month Dimension...
