Dear Customer,
Thank you for purchasing the ATC9K by Oregon Scientific.
At Oregon Scientific, we understand that
adventure sports enthusiasts as well as everyday enthusiasts
take great pride and satisfaction in recording and viewing
first person footage captured by our hands free action cam.
For this reason, the ATC9K was designed and engineered with
extreme precision, in order to allow you to take the adventure
home with you. Review the following pages for technical
information, tips and troubleshooting which will allow you to
maximize your experience with the ATC9K.
PLAY HARD, RECORD EVERYTHING!
OREGON SCIENTIFIC and associated trademarks and trade dress are owned by
OREGON SCIENTIFIC, Inc.
© 2010 OREGON SCIENTIFIC, Inc. All Rights Reserved.
Advertisement
Table of Contents
Related Manuals for Oregon Scientific ATC9K
Summary of Contents for Oregon Scientific ATC9K
- Page 1 For this reason, the ATC9K was designed and engineered with extreme precision, in order to allow you to take the adventure home with you.
-
Page 2: Table Of Contents
Oregon Scientific ATC9K I . Quick Start ... 1 II . Camera Precautions ... 1 III . Technical Specifications ... 3 IV . Computer System Requirements ... 3 V . Package Contents ... 4 VI . Product Appearance ... 5 VII . -
Page 3: Quick Start
Shooting Photos 1. Aim the ATC9K at what you would like to take a picture. 2. Press the Photo capture button 3. The LCD display will be frozen for a while, indicates that the scene had been captured. -
Page 4: Waterproof Feature
Users assume all responsibility in the event that copyrights are violated by the use of this camera. Waterproof Feature The ATC9K camera is waterproof up to 20m (60ft). Oregon Scientific will not assume any responsibility for camera malfunction caused by liquid entering the camera as a result of misuse by the user. -
Page 5: Technical Specifications
III) Technical Specifications • Sensor resolution 5M pixels CMOS. • Supports Micro SD/SDHC Class 4 card or above and compatible up to 32GB (not included). • Movie storage: 1080p = 1920x1080 pixels (16:9), 30 fps, ~12 Mbit/s data rate, approximately 9 minutes of video per 1G Byte 720p = 1280x720 pixels (16:9), 60 fps, ~12 Mbit/s data rate, approximately 10 minutes of video per 1G Byte... -
Page 6: Package Contents
V) Package Contents Thank you for purchasing the ATC9K Action Camera, this package should contain the: 1. Main Camera Unit with Camera Grip 2. Carrying Bag 3. Software Installation CD 4. Remote Control 5. Rechargeable Battery 6. Long Silicon Strap 7. -
Page 7: Product Appearance
VI) Product Appearance Main Unit Play/Pause button Left button Menu button Right button Power On-Off Movie Shutter button Photo Capture button USB Connection HDMI Connection microSD card slot Battery Compartment GPS Module slot Remote Control Unit Play/Pause/Confirm Left Settings menu Right Power on/off unit Record start/stop... -
Page 8: Camera Operations
VII) Camera Operations Turning the Camera On Press the On/Off button on the LCD screen. Turning on for the first time 1. The system will ask you to set the Date/Time/Timezone when the camera is turned on for the first time or the rechargeable battery is reinstalled. -
Page 9: Using The Remote Control
3. During video playback, press “Play/Pause” press “Left” and “Right” button forward and fast reverse. 4. To exit the playback mode, press “Movie shutter” button or “Photo Capture” button Delete a Video or Photo 1. Press the “Menu” button select the video or file you want to delete with “Left” and “Right”... -
Page 10: Camera Settings
Display the video resolution setting. Display the photo resolution setting. Display the EV value. Display the quality setting of the videos & photos. Indicate that there is no microSD card inserted. The red line will disappear when a microSD card is inserted. Privacy Mode is on. -
Page 11: Video Settings
Video Settings 1. Resolution You can set your video resolution here. Full HD/30 HD/60 HD/30 WVGA 2. Quality You can select Fine, Good or Normal. 3. EV The Exposure values range from +2.0 to -2.0. You can set the appropriate value to suit your shooting environment. -
Page 12: General Settings
5. White B. (White Balance) According to different environment, you can select Auto, Daylight, Cloudy, Fluorescent and Tungsten to adapt a correct color tone of the photo. 6. Contrast According to your preference, you can adjust contrast level with Standard, Soft, Hard. -
Page 13: Firmware Update
Restore back to the factory default settings. 14. Version Display the current system version. Firmware update 1. Visit Oregon Scientific website atc.oregonscientific.com/ to download the latest firmware. 2. Unzip the package and copy the unzipped file to the root folder of the microSD card. -
Page 14: Power Supply
XI) Power Supply Battery Replacement 1. Unlock the rear of the unit by lifting the latch. 2. Insert the rechargeable battery into the battery slot as indicated until it clicks in place. 3. If you want to release the rechargeable battery, turn the battery hinge downwards until it comes out from the slot. -
Page 15: Microsd Card Insertion / Removal
XIII) Connecting to a Computer You can upload your recorded video footages and photos to a PC by connecting the ATC9K to your PC using the PC Application. You may download the latest version in atc.oregonscientific.com. 1. Turn the ATC9K on. - Page 16 User Profile 1. To start, choose your own account to login with your password or simply create a new account if you are using the PC application for the first time. You can always access your profile information by clicking the top-right icon after you login to the application.
- Page 17 Video and Photo Viewer 1. The Viewer will display both videos and photos. 2. When the viewer is showing video files, the following screen will be shown: A video player II. A video timeline with a dragger which you can manually drag the position o reveal certain instances of the video.
- Page 18 3. When the viewer is operated for photo files, the following will be shown: I. A photo viewer II. The name of the photo. III. An information icon when it has been clicked. Users are able to edit the title and description of the photo.
-
Page 19: File Management
File Management 1. Within the File Management, videos and photos are displayed separately into 2 lists. 2. All videos and photos imported will be displayed within the “Library” tab. 3. The videos and photos that were imported last time (no matter the files are assigned to album or not) are displayed in the “Last Import”... - Page 20 V. Album With options: all, library and albums that the user created. VI. Date With options: anytime, past 24 hours, past week, past month, past year, specific date (if user is not choosing a specific date, the second and third pulldown menu won’t be shown.) 9.
- Page 21 IV. Details of the photos. V. An edit info icon to edit the title and descriptions of photos. VI. A trash icon to delete files or remove tags. VII. Multiple item selections are allowed by ctrl-click or shift-click. VIII. You can drag and drop from lists to albums on the left hand side. Data Graphs 1.
-
Page 22: Connecting To A Monitor
HDMI cable provided. 1. Turn the ATC9K and the monitor off. 2. Connect your ATC9K to your monitor using the HDMI cable. 3. Turn the monitor and ATC9K on. Playback 1. Select the video or photo you want to play by pressing “Left” and “Right”... - Page 23 Delete Video or Photo 1. Press “Menu” button submenu. 2. Select “Delete”. 3. Confirm the deletion by pressing “Play/Pause” button Switch between Video and Photo 1. Press “Menu” button 2. Select “View Videos” or “View Photos” by press the “Right” button 3.
-
Page 24: Troubleshooting
• Does the rechargeable battery properly installed? • Does the rechargeable battery need replacing? After the ATC9K is connected to my PC, it cannot find the new drive the ‘My Computer’ folder • Ensure each end of the ATC9K USB cable is properly and firmly connected. - Page 25 Macintosh, Mac OS and iMovie are trademarks or registered trademarks of Apple Inc.. Intel and Pentium are trademarks or registered trademarks of Intel Corporation. SDHC and SDHC logo are trademarks of SD-3C, LLC. Oregon Scientific (UK) Ltd. Unit 1, Switchback, Gardner Road, Maidenhead, Berkshire SL6 7RJ. Hotline number: 0871 222 1966 E-mail: Technical@oregonuk.com...
- Page 26 WARNING: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. CAUTION LASER RADIATION WHEN OPEN DO NOT STARE INTO BEAM OR VIEW DIRECTLY WITH OPTICAL INSTRUMENTS INFORMATION FOR USERS In accordance with European Directives 2002/95/CE, 2002/96/CE and 2003/108/CE on the restriction of the use of dangerous substances in electric and electronic...
