- Page 1 Professional Cinema Fixed Frame Screen Set-up Guide...
-
Page 2: Product Content
Product Content The following items are included with your fixed framescreen. Verify all items are present and prepare a clean working environment to begin assembly. Part Description Frame (Long Bar) Frame (Short Bar) Screen (Glass Beeded) Screen Rod (Long Rod) Screen Rod (Short Rod) Frame Edge Protector (Long) Frame Edge Protector (Short) - Page 3 Fixed-Frame Screen Set-up Instruction Precaution: 1) Attempt to assemble the fixed frame screen in a clean environment. 2) Professional mounting techniques should be observed. Manufacturer cannot be liable for substandard/faulty installations. Layout the frame (the long and short bars). Parts Used: Frame (Part #1&2) Insert the spring hook on one horizontal &...
- Page 4 Insert the locking screws on one horizontal and vertical side into the screen frame as shown below. (Long side:7 locking screws,short side: 5 locking screws) Parts used: Locking Screws (part #9) Insert bolts of M6*0 screw into the screen frame as shown below Parts used: M6*20 nuts (part #13) Bolts...
- Page 5 Left Right Insert the elbow connectors into the open ends of the frame to connect the sides together. Parts used: Elbow connectors (part #4), frame Elbow connector Fixed-Frame Set-Up Guide | 5...
- Page 6 With the four sides of the frame connected, insert four M4*1 screws to each corner of the screen as allowed Parts used: M4*12 screws (part #12), elbow connectors, frame Un-roll the glass beaded screen, with the viewing side down Parts used: Screen (part #3) 6 | Fixed-Frame Set-Up Guide...
- Page 7 Thread the long rod into the horizontal edge of the screen. Then thread the short rod into the vertical edge of the screen. Parts used: Screen rod (part #4/5), screen With the rod threaded screen, connect the spring hooks (Fig. 8-A) to each of the openings of one horizontal side and one vertical side.
- Page 8 Connect the locking screw (Fig.8-B) to each of the openings of one horizontal side and one vertical side. Parts used: Locking screws, screen, screen rod Fig 8-B Tighten locking screw with Philip screw driver (Fig. 8-C) Parts used: Philip Screw Driver Fig 8-C 8 | Fixed-Frame Set-Up Guide...
- Page 9 Install the frame edge protector to the frame as shown below. Parts used: Frame edge protector (part #6/7). Install screen hangers on to the top corners of the frame. Using M6*0 screw and bolt. Parts used: Hanging plate (part #8), M6*20 Screw (part #13) Fixed-Frame Set-Up Guide | 9...
- Page 10 Milpitas, CA 95035, USA Tel: 408-383-3700 Fax: 408-383-3702 www.optomausa.com Optoma Technology, Inc. 715 Sycamore Drive, Milpitas CA 95035 Tel: 408-383-3700 • Fax: 408-383-3702 For more information, please visit www.Optoma.com. Specifications subject to change without notice. Copyright 2006 Optoma Technology, Inc.
