IMPORTANT SAFETY INSTRUCTIONS
Basic safety precautions,including the following should
always be followed.
Close supervision is necessary when any motorized screen
is used by or near children,do not leave motorized screen
unattended while in use.
Do not operate motorized screen with damaged cord or if the
motorized screen has been dropped or damaged,until it has
been examined by a qualified service technician.
Position the cord so that it will not be tripped over,pulled or in
contact with not surgaces.
Never yank cord to pull plug form outlet.aways grasp plug bu
head and pull to disconnect.
Let appliance cool completely before putting away.Loop cord
loosely around appliance when stoing.
To reduce the risk of electric shock,do not immerse this motor-
ized screen in water or other liquids.
To reduce the risk of electric shock,do not disassemble this
appliance,only a qualifid service technician may service or
repair motorized screen.Incorrect reassemble can cause
electric shock when the motorized screen is used.
Only use accessory attachment recommended by the
manufacturer.Use of non-manufacturer recommended
accessory attachments,may viod the screens warranty
and release Panoview of all liability.
Basic electrical safety precautions should always be
observed.
In the event,the above mentioned safety precautions are not
observed.The warranty may be viod and Panoview released
of all liability.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Optoma PanoView DE-GWII9092E
Summary of Contents for Optoma PanoView DE-GWII9092E
-
Page 1: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Basic safety precautions,including the following should always be followed. Close supervision is necessary when any motorized screen is used by or near children,do not leave motorized screen unattended while in use. Do not operate motorized screen with damaged cord or if the motorized screen has been dropped or damaged,until it has been examined by a qualified service technician. - Page 2 Thank you for choosing Panoview screens. All screens have passed the strict quality inspection before delivery. Read this manual carefully to ensure proper usage. Important Attention: the installation of the screen, the electric wire connection, the setting of the limit switches must be made by a trained engineer only Motorized screen with IR remote control, switch control &...
- Page 3 Unpack screen carefully, be sure screen is in good condition, and check that all accessories are included inside carton. Care in mounting and care in correct operation will mean a long and satisfactory life for your Panoview screen. Locate the screen where the audience can best see it and where other furnishings in the room permit.
- Page 4 ELECTRIC CONNECTION Internal wiring has been completed at the factory.No additional wiring is necessary. Note:all wiring related to the screen,may only be serviced by a manufacturer approved trained electrical technician.Tampering with electrical wiring may void warranty and release Panoview of liability.
- Page 5 OPERATING INSTRUCTION: Remove two pulling locks on the bottom bar first before any operation. this is important to prevent motor damage. Plug in power supply. For Switch control: Plug in Switch into switch jack. Press button to Up position, screen goes up. Press button to stop position, screen stops.
- Page 6 SCREEN ADJUSTMENT Note: Adjustments to screen limit positions, can only be performed by a trained technician. Screen travel is stopped automatically in the down and up positions by limit switches that are preset in the factory. If it is necessary to adjust for more or less, please follow the steps below for adjustment.
- Page 7 SETTING THE DOWN LIMIT POSITION To reduce screen drop: Make sure middle fasten screw (F) is loosened,then loosen small right fasten screw (FR) .Turn right screw (RS) counterclockwise to decrease the amount of screen drop.Run the screen down to test the stop position.If the screen drops too far,adjust the limit switch again.Repeat until the desired position is set.When complete,fasten middle fasten screw (F) and small right fasten screw (FR).
- Page 8 Screen does not travel far enough into case: Make sure middle fasten screw (F) loosened,then loosen small left fasten screw (FL) .Turn left screw (LS) counterclockwise to increase the amount of up travel.Run the screen up to test the stop position.If more travel ie desired,adjust the limit switch again.Repeat until the desired position is set.When complete fasten middle fasten screw (F) and small left fasten screw (FR).
