Page 1: Table Of Contents
English Table of Contents Usage Notice Precautions ... 3 Introduction About the Product ... 4 Package Overview ... 5 Installation Product Overview ... 6 Start Your Installation ... 8 User Controls User Control Overview ... 10 Function Descriptions ... 13 Appendices Troubleshooting ... -
Page 2: Usage Notice
Usage Notice Do not look into the lens. The bright light may hurt your eyes. Warning- To reduce the risk of fire or electric shock, do not expose this Warning- product to rain or moisture. Please do not open or disassemble the product as this may cause Warning- electric shock. -
Page 3: Introduction
English Introduction About the Product This product is a SVGA data/video portable projection display. The outstanding features of it are listed as follows: 9.25 lbs (4.2 kg) lightweight compact design Single panel 6.4” TFT LCD projection system 800 x 600 SVGA addressable pixels Compression for 1024 x 768 XGA computer image 16.7M (24-bit) displayable colors XGA/ SVGA/ VGA/ VESA/ Mac/ NEC PC-98/ Fujitsu FM Towns compatible... -
Page 4: Package Overview
Package Overview This projection display comes with all the items shown below. Check to make sure your unit is complete. Contact your dealer immediately if anything is missing. LCD Projection Display User’s Manual S-Video Cable Carrying Case Remote Control Battery x 2 Warranty Card Composite Video Cable VGA Cable... -
Page 5: Installation
English Installation Product Overview Main Unit Panel Control Buttons Keystone Correction Lens Latch Lamp Door Carrying Handle Elevator Foot Lamp Latch Power Switch Power Connector Fuse Lens Rear Connection Ports Audio Outputs S-Video Connector Composite Video Connector Audio Inputs for Video Monitor Loop- through Connector Computer Input... -
Page 6: Remote Control
Remote Control Power on/Standby Curtain/Color functions Tracking Contrast/Brightness Directional select keys On-Screen menus Notice: For more detailed information, please refer to “Function descriptions” on page 13. Reset POWER ON RESET FREEZE STANDBY Freeze CURTAIN ZOOM ZOOM COL/TIN Zoom in/Zoom out CON/BRI TRACK SOURCE... -
Page 7: Start Your Installation
English Start Your Installation Connecting the projection display Power Cord Audio Cable S-Video Cable Composite Video Cable Notice: To ensure the projection display works well with your computer, please config-ure the display mode of your graphic card to make it less than or equal to 800 600 resolution and make sure timing of the display mode is compatible with the projection display. - Page 8 Setting up the projection display Positioning the projection display Projection 5 ft. Distance (1.5 m) 40" Image Size (1.01m) (diagonal) (min.) (projection distance and image size) Slide the lens latch and pop-up the projection lens. Switch on the power and press “Power on/Standby”...
-
Page 9: User Controls
English User Controls User Control Overview We have two ways for you to control the functions: panel control and remote control. Panel control POWER ON STANDBY MENU 4 Directional Keys Remote control Power on/Standby Curtain/Color functions Tracking Contrast/Brightness Directional select keys On-Screen menus RESET ENTER... -
Page 10: Osd Menus
OSD Menus The OSD (On-Screen Display) menus will allow you to easily adjust the display functions. Press the “MENU” button for the OSD menu options. When in computer sources, the OSD will be: Language Contrast Tracking Frequency Custom Memory Audio Source Rear Projection Ceiling Projection... -
Page 11: Function Descriptions
English Function Descriptions Basic Functions: Power On/Standby Menu Reset Enter Four Directional Select Keys Language Audio Source Rear Projection Press the “Power On/Standby” button to turn on the projection lamp. Press “Menu” button to pop up the OSD menu. Press “Reset” to return the display parameters of the current mode to its factory default settings. - Page 12 Ceiling Projection Choose this funtion from OSD menu for a ceiling mounted projection. Exit Choose “Exit” item to leave OSD menu. Presentation Functions - computer source Pointer Press the “Pointer” button to show a hand shape pointer. Use , , or button to move pointer around the projected image.
- Page 13 English Tracking Frequency Custom Memory Language Contrast Tracking Frequency Custom Memory Audio Source Rear Projection Ceiling Projection Auto Image Exit Auto Image Choose “Tracking” item to synchronize the signal timing of the display to that of the graphic card. When you experience an unstable or flickering image, use this function to correct it.
- Page 14 Presentation Functions -- video source Contrast/Brightness To adjust the contrast or brightness of the image, select “Contrast/Brightness” from OSD menus. Color/Tint To adjust the color or tint of the image, select “Color/ Tint” from OSD menus. Freeze Press the “Freeze” button to still the screen image. English...
-
Page 15: Appendices Troubleshooting
English Appendices Troubleshooting If you are experiencing trouble with the projection display, refer to the follows. If the problem persists, please contact your local dealer or our service center. Problem: No image appears on screen. Press “Power on/Standby” button. Ensure all the cables and power connections are correctly and securely connected as described in the “Installation”... - Page 16 6. Under “Manufacturers”, select “Standard monitor types” 7. Verify that the resolution setting of the monitor display is less than or equal to 800x600. If you are using a Notebook PC: 1. You are required to implement above steps of resolution setting of computer first.
-
Page 17: The Apple Macintosh Connections
English The Apple Macintosh Connections w Connecting a Macintosh Desktop Computer For 640 x 480 Resolution: 1. Connect the supplied 15-pin VGA signal cable to the unit. 2. Connect the supplied MAC (VGA) adapter between the VGA signal cable and the signal output of your computer. -
Page 18: Maintenance
Maintenance w Changing the lamp Make sure the projection display has cooled for at least 30 minutes before changing the lamp. After you slide the lamp latch and open the lamp door, you will see two lamps inside; one is in “usage” position, the other is in “spare” position. Refer to the lamp changing directions below. -
Page 19: Changing The Fuse
English w Changing the fuse Fuse Holder Switch off the power and unplug the power cord. Pull out the fuse holder. Remove the blown fuse and then insert a new fuse. Put the fuse holder back in position. the Blown Fuse... -
Page 20: Specifications
Specifications LCD panel - active matrix TFT color LCD - 6.4” panel x 1 - tr=30ms, tf=50ms response time - 150:1 contrast ratio Lamp - 400 watt halogen Display Resolution - 800 pixels(H) x 600 lines(V) Displayable Color - 16.7M colors Image Size - 40”... -
Page 21: Compatibility Modes
English Compatibility Modes Mode IBM & VESA VGA IBM & VESA VGA IBM & VESA VGA IBM & VESA VGA IBM & VESA VGA IBM & VESA VGA IBM & VESA VGA IBM & VESA VGA IBM & VESA VGA IBM &...
