- Page 1 TELEMETRY RECEIVER USERS MANUAL ZVR-110 SECURITY with VISION...
-
Page 2: Table Of Contents
MEYERTECH DIVISION ISSUE 01 CONTENTS 1. ZVR-110 WELCOME 2. FEATURES 3. INSTALLATION 3.1 RELAY LINK SETTINGS 3.2 CONNECTING THE ZVR-110 3.3 CAMERA NUMBER ASSIGNMENT 4. SELF TEST DIAGNOSTICS 5. SPECIFICATIONS 5.1 ELECTRICAL 5.2 PHYSICAL 6. CONNECTION DIAGRAM 7. TROUBLE SHOOTING GUIDE 8. -
Page 3: Zvr-110 Welcome
The ZVR-110 is a powerful, low cost telemetry receiver offering an economical Wash/Wipe solution. With the ability to operate over coax or twisted pair RS-422, the ZVR-110 is compact enough to be mounted easily inside the smallest of camera housing and on board self-test and diagnostic facilities minimize installation and commissioning time. -
Page 4: Relay Link Settings
4. AVOID looming cables of differing characteristics together E.G. Video cables with cables carrying mains power. 5. If the ZVR-110 is to be operated over twisted pair cable ensure the screen is connected to 0V. 6. The maximum cable run for Twisted Pair is typically 2Km. -
Page 5: Camera Number Assignment
9. The cable used to wire the secondary of the transformer should be a minimum of 0-5mm 3.3 CAMERA NUMBER ASSIGNMENT When operating the ZVR-110 using RS-422 telemetry, a receiver address must be set up which corresponds to the connected matrix output. If operating the ZVR-110 over Meyertech VICTA coax telemetry, no receiver address is necessary. -
Page 6: Self Test Diagnostics
MEYERTECH DIVISION ISSUE 01 SELF TEST DIAGNOSTICS The ZVR-110 features a set of diagnostics to test the function of both relays Select the function required for testing by turning the Program Switch to the position in shown in the table below. - Page 7 VICTA™ coax telemetry. RS422 twisted pair (Telemetry / Network Communications) ZoneVu commands and data are transmitted in PACKETS. Each Packet has a unique HEADER to identify its destination and a common TERMINATOR to identify the end of the data Packet.
-
Page 8: Connection Diagram
MEYERTECH DIVISION ISSUE 01 CONNECTION DIAGRAM 12V AC SUPPLY 4 LOCATION (PCB ONLY) HOLES 4mm dia. spaced 67mm by 59.5mm apart POWER CONFIGURATION LINKS ZVR-110 PROGRAM SWITCH PROG Rx LED TEST/ ENTER SWITCH Rx+ Rx- SCREEN RS-422 TAMPER TELEMETRY VIDEO FROM... -
Page 9: Trouble Shooting Guide
ISSUE 01 TROUBLE SHOOTING GUIDE This Trouble Shooting Guide should be used in the first instance of encountering any problems with the ZVR-110. If problems persist, contact MEYERTECH on the Technical Help line numbers given on page 15. Symptom Solution... -
Page 10: Declaration Of Conformity
MEYERTECH Division Office Block One Southlink Business Park Oldham OL4 1DE declares, that the product(s): Product Name : ZVR-110 Telemetry Receiver Model(s) : Product Options : conforms to the following Product Specifications : EN55022 CLASS B EN50093 Supplementary Information :... -
Page 11: Product Warranty
MEYERTECH DIVISION ISSUE 01 PRODUCT WARRANTY MEYERTECH DIVISION warrants that at the time of shipment the products manufactured by Meyertech will be free from defects in material and workmanship. Should any defects appear within twelve months from date of shipment, Meyertech Division shall at it’s sole discretion repair or replace the defective material. -
Page 12: Document History
MEYERTECH DIVISION ISSUE 01 DOCUMENT HISTORY ZVR-110 Telemetry Receiver Users Manual : MAN-110 ISSUE DATE CHANGE RECORD 16 Sept 1997 First Issue Page 12... - Page 13 MEYERTECH DIVISION ISSUE 01 NOTES Page 13...
- Page 14 MEYERTECH DIVISION ISSUE 01 NOTES Page 14...
- Page 15 MEYERTECH DIVISION ISSUE 01 MEYERTECH DIVISION SECURITY with VISION Office Block One Southlink Business Park Oldham England OL4 1DE Sales Support Technical Support +44 (161) 628 8406 Oldham +44 (161) 628 8406 Kirton +44 (1652) 640740 +44 (161) 628 9811 Email : technical@meyertech.co.uk Email : sales@meyertech.co.uk Page 15...
