  • Page 1 ZVR-530 USER MANUAL ZVR-530 DC Variable Speed Telemetry Receiver Issue 17...
  • Page 2 ZVR-530 User Manual Issue 17 Page 1 of 58...

  • Page 3: Table Of Contents

    Contents SAFETY PRECAUTIONS .............................. 2 INTRODUCTION ................................3 ZVR-530 OVERVIEW ..............................4 TELEMETRY DATA NETWORK ........................... 4 CAMERA HEAD PRE-ASSEMBLY AND TESTING ..................... 6 TELEMETRY SETUP ..............................9 CONFIGURING THE ZVR-530 ............................ 12 ZVR-530 LOGIN ................................16 MAIN MENU ................................. 16 DISPLAY SETUP MENU .............................

  • Page 4: Safety Precautions

    ZVR-530 User Manual Issue 17 Page 2 of 58 Safety Precautions 1. Carefully read this Product Manual prior to commencing installation and configuration. 2. Before working on this product, power it down and remove the power leads. Removing the module or PCB’s from their environmental enclosure may cause damage to the product and present an electric shock and fire hazard.

  • Page 5: Introduction

    Thank you for purchasing this product. The following instructions will guide you through the installation and configuration of your ZoneVu ZVR-530 telemetry receiver. Please carefully read the rest of this manual before attempting to operate this product. This will ensure that the best performance is obtained.

  • Page 6: Zvr-530 Overview

    Telemetry Data Network The ZoneVu telemetry data network can be either RS422 or RS485 and either Simplex or Half-Duplex. Depending on which type of network you have or intend to have will determine how the receivers will be connected. For an RS485 network, the...
  • Page 7 ‘dirty’ earth at one end only! VICTA-ZoneVu ‘down the coax’ telemetry, is not directly supported by the ZVR-530. If you want to be able to control the ZVR-530 via VICTA (which may be the case if you are using a ZVM-328 matrix) you will require a ZVD-V42-ZV VICTA to RS422 ZoneVu driver module, which should be located at the receiver end.

  • Page 8: Camera Head Pre-Assembly And Testing

    ZVR-530 User Manual Issue 17 Page 6 of 58 Camera Head Pre-assembly and Testing It is important to consider the time and expense that can be saved by pre-assembling and testing the ZVR-530, pan and tilt head, lens and camera prior to installation on-site. Pre-assembly normally involves the following tasks (in no particular order): 1.

  • Page 9: Installation Menus

    Once all the cabling has been connected to the ZVR-530, head, lens and camera it can be tested using the self-test which allows the receiver to be exercised without the need for it to be connected to a ZoneVu controller.
  • Page 10 ZVR-530 User Manual Issue 17 Page 8 of 58 To exercise each function manually cycle through the menu until the option you require is flashing. Now select the function. The ZVR-530 will exercise the function until you select FINISH. To change the speed, highlight it in the normal way and then select it. You can now step through the speed range of 1-32. When the speed reaches 32 it will loop back to 1 at the next step.

  • Page 11: Telemetry Setup

    Press the button to return to the previous menu. Telemetry Setup Before the ZVR-530 can be connected to a ZoneVu controller (see Telemetry Data Network) some basic network configuration needs to be carried out. The simplest way to do this is on the bench with a monitor connected the video output of the ZVR-530.

  • Page 12: Network Settings

    Network Protocol The ZVR-530 can use five different Network protocols; these are ZoneVu, Old ZoneVu, Pelco P, Pelco D and Forward Vision (subject to change). Please refer to “ZVR-530 Supported Receiver Protocols” for further information. Selecting the Serial Camera Interface The ZVR-530 supports a serial interface to specified camera types.
  • Page 13 ALL configured data is lost, including the receiver address. When you load factory defaults over the network, IE when the ZVR-530 is connected to a ZoneVu network the receiver address is not restored to its default value. This may save you a trip out to the...

  • Page 14: Configuring The Zvr-530

    To configure the advanced features of the ZVR-530 you will require access to a System keyboard such as the ZVK-007 or ZVK-77 connected either directly to the receiver or via a ZoneVu controller such as the ZSC-1000 or ZVM-328. When connected via a video matrix make sure to first select the receiver to a monitor within your view as configuration is via on screen menus.
  • Page 15 ZVR-530 User Manual Issue 17 Page 13 of 58 ZVK-77 SCREEN (Menu B) Engineer ZVR Config Last Restart Menu config Left Select Down Right Menu Option Description Engineer The name of the current user logged onto the ZVK-77 ZVR Config. The current menu Last Menu Select to display the last ZVR-530 configuration menu (or exit)
  • Page 16 ZVR-530 User Manual Issue 17 Page 14 of 58 Configuration using a ZVK-007 To configure the ZVR-530 using a ZVK-007 system keyboard you will first need to access the ZVR Config. Menu . To do this you will need to log onto the keyboard at the Supervisor Level, which permits access to programming functions such as ZVR Config.
  • Page 17 ZVR-530 User Manual Issue 17 Page 15 of 58 Selecting a menu displays different options, selecting an option allows it to be changed. Options, which require text or numeric input, will clear ready for input when selected. Otherwise the option toggles through the choices each time it is selected.

  • Page 18: Zvr-530 Login

    ZVR-530 can be retained for up to ten years without loss! The latest generation of ZoneVu ZSC products allow the full ZVR-530 database to be downloaded to a PC using Mpower, a PC application which allows you to configure, backup and restore ZoneVu system data. Once downloaded the database can be archived for future use by service and maintenance personnel.
  • Page 19 Caption Display controls the fixed caption, which is setup using the Edit Caption option above. Alarm Display controls captions triggered by the alarm inputs, loss of video or approaching endstops. Command Display controls the display of camera commands as they are received from the ZoneVu controller as confirmation of the operator action.
  • Page 20 ZVR-530 User Manual Issue 17 Page 18 of 58 Each caption type can be switched On or Off using the Display option. For example to stop the receiver showing confirmations of any commands received, switch the Command Display to Off. To position a caption on the screen first choose left or right Alignment.

  • Page 21: Alarm Setup Menu

    ZVR-530 User Manual Issue 17 Page 19 of 58 Character Colour allows you to adjust the greyscale level of the DISPLAY COLOUR MENU captioning including all text on the screen. Character Border adjusts the greyscale level of the fringing around the edges of each character, or the background block if enabled.

  • Page 22: Alarm Setup Menu

    Alarms can be managed locally, centrally or both when the ZVR-530 is connected to a ZSC-500 or ZSC-1000 ZoneVu Site Controller. For example certain alarm inputs may require the action of two cameras to provide full coverage of the incident.

  • Page 23: Motor Control Menu

    ZVR-530 User Manual Issue 17 Page 21 of 58 Motor Control Menu The Motor setup menu provides comprehensive configuration facilities to drive the pan and tilt head and lens. The reasons behind this are that every pan and tilt head, even when of the same type and from the same manufacturer, have different characteristics, due for example to motors being under-wound / over-wound and mechanical differences due to tolerances in manufacture.
  • Page 24 ZVR-530 User Manual Issue 17 Page 22 of 58 Sensitivity - Some heads are more sensitive than others over the full LENS SETUP MENU drive voltage range. This option provides three preset settings of Low, Medium and High. Choose the setting which works best with your head. Axis : Zoom The lens can also be configured.
  • Page 25 ZVR-530 User Manual Issue 17 Page 23 of 58 Test Drive the Head Test drive - The test drive facility allows us to check the effect of the parameters as you change them without having to leave ZVR-530 configuration. 202: S18 484: When we select Test drive the menu to the right 871:...
  • Page 26 ZVR-530 User Manual Issue 17 Page 24 of 58 task though and should only be attempted by an accomplished CCTV engineer. If you do get into a total mess using the Customise option you can always Load Factory Defaults! Before you start to use the Custom Motor Setup Menu you need CUSTOM MOTOR SETUP MENU to understand how it works and how to navigate it.
  • Page 27 ZVR-530 User Manual Issue 17 Page 25 of 58 Setting the Acceleration Values ACCEL. VALUES MENU Dwell 1 : 15 Dwell 2 : 16 Press Select key and using the numeric keypad enter a value in the range Dwell 3 : 17 0 -15.

  • Page 28: Feedback Setup Menu

    ZVR-530 User Manual Issue 17 Page 26 of 58 Feedback Setup Menu FEEDACK SETUP MENU Feedback refers to the potentiometers or similar devices fitted to Pan and Tilt heads and Lenses that give the head preset capability. The Voltage feedback is processed and mapped by the ZVR-530 to provide Axis : Pan 64 preset positions of PTZF.
  • Page 29 ZVR-530 User Manual Issue 17 Page 27 of 58 Endstops Non-continuous rotation heads incorporate mechanical endstops to ensure the head does not get over-panned or over-tilted. They are also often set by the installer to limit the pan travel when attached, for instance to a wall where you would only have access to 180 deg.
  • Page 30 ZVR-530 User Manual Issue 17 Page 28 of 58 Preset Curve The preset curve menu options allow you to tailor the ZVR-530 to a heads PTZF preset characteristics. There are many different types of P&T head and lens now available from different manufacturers. Pan and tilt heads are also available with different speed ranges.

  • Page 31: Automated Functions Menu

    ZVR-530 User Manual Issue 17 Page 29 of 58 Automated Functions Menu AUTOMATED FUNCTIONS Auto Park Relay Functions Presets Ordered Patrols Random Patrols Mimic Patrols Auto Park Historically Auto Park returned the camera to a Preset, normally Home, after a pre-defined period of non-use I.E. no camera control signals received.
  • Page 32 Protection Enable this option to prevent the preset position from being overwritten by direct command from either a ZoneVu or Fusion controller. Disable to allow direct access to re-program the preset. Relay Using the Select key, cycle through and set the option you require from None, Wash, Iris mode, Aux 1, Aux 2, Aux 3, Wipe or Lamp.
  • Page 33 ZVR-530 User Manual Issue 17 Page 31 of 58 Position the camera using the keyboard joystick to set the view you require in pan, tilt, zoom and focus planes. To save the Preset press 1 on the numeric keypad. To exit the menu without saving the preset press 2.
  • Page 34 ZVR-530 User Manual Issue 17 Page 32 of 58 Text - A unique label can be assigned to each patrol by selecting this option. Using the alphanumeric keypad program your caption and select DONE to save it. Caption: Patrol 1_ A B C D E F G H I J K L M N O P Q R S T U...
  • Page 35 ZVR-530 User Manual Issue 17 Page 33 of 58 Mimic Patrols The Mimic patrol is a new type patrol bringing new levels of performance and flexibility. To the criminal the camera actually looks, as though an operator is manually controlling it, it is that good! Up to two mimic patrols can be configured for the ZVR- 530.
  • Page 36 ZVR-530 User Manual Issue 17 Page 34 of 58 Move the camera manually taking in the particular views you require. You can stop and dwell at any point and it will still be recorded. In fact every PTZF movement is recorded. To stop the recording of a mimic patrol press 1 on the keyboard keypad.

  • Page 37: Advanced Functions Menu

    ZVR-530 User Manual Issue 17 Page 35 of 58 Advanced Functions Menu The ZVR-530 incorporates a number of advanced features as standard. Dynamic captions, which automatically update as you move the camera head, are relaying information to the operator relating to the scene being viewed. Privacy zones are used to guarantee privacy where cameras have views over private property such as residential areas.
  • Page 38 ZVR-530 User Manual Issue 17 Page 36 of 58    Re-mark Position Mark Position ZOOM IN CALIBRATION  1-Done 2-Cancel 1-Done 2-Cancel    ZOOM MID-POINT Mark Position Re-mark Position CALIBRATION  1-Done 2-Cancel 1-Done 2-Cancel Privacy Zones Up to fifty 3D dynamic privacy zones can be configured on the ZVR-530 from the menu below.
  • Page 39 ZVR-530 User Manual Issue 17 Page 37 of 58 Caption: Mimic 1_ Using the alphanumeric keypad, program a caption and select DONE to save it. A B C D E F G H I J K L M N To insert a space, highlight the SPACE option and press Select. O P Q R S T U To switch between uppercase and lowercase, highlight the LOWER V W X Y Z 0 1...
  • Page 40 ZVR-530 User Manual Issue 17 Page 38 of 58 Transparency: This setting allows privacy zones to be made to have a certain degree of transparency, allowing the underlying scene to be partially visible. The degree of transparency Level (16) can be configured to fit the requirement. Adjust the level of the transparency by panning left or right or by pressing the left and right buttons on the keyboard.
  • Page 41 ZVR-530 User Manual Issue 17 Page 39 of 58 Dynamic Captions Before attempting to setup Dynamic captions for the first time, ensure that the 3D calibration routine has been performed. Up to 20 caption zones / sectors may be setup. ...

  • Page 42: Installation Menu

    Selection of this option will take you to the installation menu that can also be selected with the self-test button. INSTALLATION MENU Auto Test Test Facilities Address: Network Settings Network Protocol : ZoneVu Serial Camera Factory Settings FINISH See the section Camera Head Pre-assembly and Testing for details.

  • Page 43: Extended Functions

    ZVR-530 User Manual Issue 17 Page 41 of 58 Extended Functions Auto Wash/Wipe : Preset 89 The Auto wash and wipe sequence is intended to simplify the operators task on cameras where operation of the washer requires a fixed position. The position required by the washer is setup by storing preset number 89.

  • Page 44: Iris Interface

    ZVR-530 User Manual Issue 17 Page 42 of 58 Iris Interface The ZVR-530 provides a drive output for controlling auto / manual iris. On selecting the Manual Iris command form a suitable control point (keyboard), relay 2 (iris auto / manual) will energise and the keyboard will be able to send manual iris commands.
  • Page 45 ZVR-530 User Manual Issue 17 Page 43 of 58 Issue Change Date 12-02-01 1 2 3 Pan Drive A Pan Drive B Tilt Drive A Tilt Drive B Zoom Drive A Zoom Drive B Focus Drive A Focus Drive B Iris Drive A CN13 Iris Drive B...

  • Page 46: Auditing Menu

    ZVR-530 User Manual Issue 17 Page 44 of 58 Auditing Menu AUDIT MENU Change Pin Number : Select this option to enter a new PIN. Change Pin Number System Info. : This option displays information about the System Info ZVR-530. Change PIN Number The ZVR-530 can be programmed with a PIN to protect it from unauthorised Configuration.

  • Page 47: Approvals And Standards

    Greenside Way Manchester M24 1UN Tel: +44 (0)161 643 7956 Fax: +44 (0)161 643 3992 Email: zonevu- support@meyertech.co.uk http://www.meyertech.co.uk EC DECLARATION OF CONFORMITY ACCORDING TO ARTICLE 10 OF COUNCIL DIRECTIVE 89/336/EEC MEYERTECH LIMITED DECLARE UNDER OUR SOLE RESPONSIBILITY THAT THE PRODUCT TO WHICH THIS...

  • Page 48: Specification

    Alarm Inputs Video loss. Sync. monitoring Diagnostic LED’s +5V and CPU (heartbeat), ZoneVu Network Communications Tx and Rx, Serial Integration Ports 1 – 2 Tx and Rx Camera captions – Dynamic text – Privacy zones – Configuration Menus – Alarm captions – command captions – position captions Two columns of 14 characters per column.
  • Page 49 ZVR-530 User Manual Issue 17 Page 47 of 58 Features Independent Pan Variable speed - Tilt Variable speed - Zoom Variable speed - Focus Variable speed - Iris Variable speed - Slow speed range - Aux 1 to Aux - Self –test - Presets (PTZF) - Patrol Random - Patrol Ordered - Patrol Boundary - Patrol Mimic - Pan and Tilt Softstop - Electronic Pan and Tilt endstops - Privacy Zones - Anti- Tamper alarm - Camera fail alarm - Alarm inputs –...

  • Page 50: Factory Settings

    Factory Settings Alarms – 1 to 6 Trigger state Closed Trigger time 50ms Text Alarm x Network settings Display Enabled Protocol ZoneVu Action Preset x Address Alarms – Video loss Mode RS485 Trigger state Enabled Termination Trigger time 50ms Baud rate...
  • Page 51 ZVR-530 User Manual Issue 17 Page 49 of 58 12V Power Command Auxiliary 3 On text Camera On Off text Camera Off Timeout Repeat time Presets – All Position none Text Preset x Protection Disabled Relay command none Camera mode none Ordered Patrols –...

  • Page 52: Connection Diagram

    TITLE: DRAWING NUMBER: DESCRIPTION: MEYERTECH LIMITED ZVR-530 CONNECTION DIAGRAM CHANGE : ISSUE DATE Connection diagram for the ZoneVu ZVR-530 telemetry receiver. Office Block One Production release ZVR-530-A 22-11-2000 Southlink Business Park Assigned 2-part connector numbers 12-02-2001 Oldham Corrected Relay 3 / 4 pin assignments. Added function terminology...

  • Page 53: Mounting Template

    ZVR-530 User Manual Issue 17 Page 51 of 58 Mounting Template Use this template to mark and drill the mounting holes for the universal mounting bracket. The bracket can be mounted horizontally; drill the three holes on the left side of the template, or vertically, drill the four holes on the right side of the template.

  • Page 55: Servicing And Support

    ZVR-530 User Manual Issue 17 Page 53 of 58 Servicing and Support Servicing The ZVR-530 requires no Planned Preventive Maintenance periods (PPM’s) as it is mainly solid state in design. However, the performance of the ZVR-530 may change over time due to changes in the equipment it is connected too. An example of this is a pan and tilt head.
  • Page 56 ZVR-530 User Manual Issue 17 Page 54 of 58 Support Meyertech support can be accessed a number of different ways depending on whether you are a Meyertech Certified Partner (MCP), a Non-MCP with a current Support Menu or a customer who has just purchased a new product.

  • Page 57: Warranty

    ZVR-530 User Manual Issue 17 Page 55 of 58 Disposal There are no additional requirements beyond safe working practice in the decommissioning of the Meyertech ZVR-530. However the ZVR-530 contains printed circuit boards populated with electronic components. The whole unit must be returned to Meyertech Service Centre for final disposal.
  • Page 58 ZVR-530 User Manual Issue 17 Page 56 of 58 6. In respect of all Goods supplied to the Seller by a Third Party Supplier the Seller will on request pass on to the Buyer (in so far as reasonably possible) the benefit of any warranty given to the Seller by such Third Party Supplier and will (on request) supply to the Buyer details of the terms and conditions of such warranty and copies of any relevant product information sheets, technical data sheets or product leaflets issued by such Third Party Supplier and the Buyer shall be solely responsible to the entire exclusion of the Seller for...
