MAIN BODY ASSEMBLY

Base
1. Unscrew the base screw from the outer pole.
Insert the outer pole into the base plate.
2.
3. Secure by placing the base crew underneath the base plate and
inserting and tightly screwing the base screw into the outer pole.
4. Place the completed base assembly on a dry, flat surface.
Main Body
Caution: The height adjustment screw must be fully secure prior
to attaching the fan body to the inner pole. Failure to do so
could result in the risk of injury.
Turn the height adjustment screw counterclockwise to loosen.
1.
Adjust the inner pole to the desired height.
2.
3. Turn the height adjustment screw clockwise to secure.
4. Insert the fan body onto the inner pole and turn the fan body
securing screw clockwise to secure.
08 | English
2
3
4
2
1 & 3
