Optoma EP747 Command List

Optoma EP747 Silent mode RS232 Command Table
Baud Rate : 9600
Parity: None
Flow Control : None
SEND to projector
232 Code Function
IDooIR101 Power ON
IDooIR100 Power OFF
IDooIR001 Eco. mode on
IDooIR002 Eco. mode off
IDooIR003 Resync.
IDooIR004 Freeze
IDooIR005 Unfreeze
IDooIR006 Source lock on
IDooIR007 Source lock off
IDooIR008 A/V mute on
IDooIR009 A/V mute off
IDooIR010 zoom plus
IDooIR011 zoom minus
IDooIR012 up
IDooIR013 down ( Pan under zoom)
IDooIR014 left
IDooIR015 right ( Pan under zoom)
IDooIR016 reset
IDooIR020 Source select
IDooIR021
IDooIR022
IDooIR023
IDooIR024
IDooIR030 Display format
IDooIR031
IDooIR032
IDooIR033
IDooIR040 Color temp.
IDooIR041
IDooIR042
IDooIR043
IDooIR050 Display mode
IDooIR051
IDooIR052
IDooIR053
IDooIR054
IDooIR055
IDooIR060 Projection way
IDooIR061
IDooIR062
IDooIR063
IDooIR080nn brightness
IDooIR081nn contrast
IDooIR082nn volume
IDooIR083nn white intensity
IDooIR084nn sharpness
IDooIR085nn phase
IDooIR086nn degamma
IDooIR087nn vert. shift(16:9 only)
IDooIR088nn color (red)
IDooIR089nn color (green)
IDooIR090nn color (blue)
IDooIR091nn color (yellow)
IDooIR092nn color (cyan)
IDooIR093nn color (magenta)
IDooIR094nn keystone
IDooIR095nn auto power off
IDooIR096nn sleep timer
READ from projector
232 Code Function
IDooIR099 LampHour
ID00IR999 Protocol Confirm
Data Bits: 8
Stop Bits: 1
UART16550 FIFO: Disable
Description
oo=01-99, projector's ID, oo=00 is for all projectors.
( Pan under zoom)
( Pan under zoom)
"
D-sub1 (VGA1)
"
D-sub2 (VGA2)
"
S-video
"
Composite Video
16:9
"
4:3
"
window
"
letterbox (option, EP747 without this)
low
"
medium
"
high
"
sRGB
"
"
Video
"
Cinema
"
sRGB
"
User
"
front + ceiling
"
rear
"
rear + ceiling
nn=00-99 , 99 will achieve maximum value even osd value is not 0~100.
nn=00-99
nn=00-99
nn=00-99
nn=00-99
nn=00-99
nn=00-99
nn=00-99
nn=00-99 , caution! corresponding OSD value : -10 ...... 0 ...... +10
nn=00-99 ,
nn=00-99 ,
nn=00-99 ,
nn=00-99 ,
nn=00-99 ,
nn=00-99 , caution! corresponding OSD value : -40 ...... 0 ...... +40
nn=00-99 , caution! maximum is 180 min.
nn=00-99 , caution! maximum is 180 min.
Return
nnnn (4 digits)
PROTOCOLA
"
"
"
"
"
Description
Returns Lamp Hour
protocol A
EP747 RS232 Version 1.0
Page 1 of 1
