MPL PIP4x User Manual

PACKED INDUSTRIAL PC with 8
The PIP4x is a low power, high performance and rugged industrial embedded computer. It can be operated in
standard or even in harsh environment. The PIP4x has been designed for 24/7 operation and uses extended
lifecycle series processors. It can be used for any PC application where a complete solution is needed. The
Open-Frame variant is particularly suitable during the customer evaluation phase or for seamless integration
into customers project. The PIP4x offers up to 3 displays simultaneously, USB and legacy I/O, NVMe mass
storage, PCI Express x16 (Gen3), ECC protected system memory, TPM 2.0 and Intel AMT support.
Furthermore, various extensions can be provided, such as MXM graphic cards, serial buses and even
customized circuits. The PIP4x has the option to be battery powered to prevent power failures in safety-relevant
environments or working as a mobile device.
Features:
8 th and 9 th Gen. Intel Coffee Lake H & HR SKU
●
25W and 45W CPU (cTDP, Configurable TDP)
●
Intel HD Graphics 630
●
Up to 64 GB DDR4 ECC RAM
●
CM246 Chipset
●
TPM2.0
●
iAMT12
●
1x Gigabit Ethernet
●
Displayport & DVI-D
●
8x USB 3.1 Ports and 4x USB2.0 Header
●
4x RS-232 or RS-485 Isolated (optional)
●
2023 by MPL AG
User Manual
th th
and 9 Generation INTEL CORE and XEON E
Processor Families
PCIe/104
●
m.2 Key-A (PCIe / USB2.0)
●
m.2 Key-B (USB3.0 / SATA / PCIe / Dual SIM)
●
m.2 Key-M (NVMe x4 / SATA)
●
2x mPCIe/mSATA (SIM Card Header)
●
2x SATA Ports
●
HW Watchdog
●
Intel HD Audio, SD-Card, SPI and I
●
PCIe and Display Header (eDP)
●
Load Dump and Reverse Polarity Protection
●
Ignition and Power Button Input
●
1
PIP4x
2 C Header
MEH-1088-001 Rev. D
