- Page 1 OPERATION MANUAL DAIKIN ROOM AIR CONDITIONER MODELS FTKM09WV2S FTKM12WV2S FTKM15WV2S FTKM18WV2S FTKM24WV2S...
-
Page 3: Table Of Contents
CONTENTS READ BEFORE OPERATION Safety Precautions ............ 2 Names of Parts ............5 Preparation Before Operation ........8 OPERATION COOL/DRY/FAN ONLY Operation ......9 Adjusting the Airflow Rate ........10 Adjusting the Airflow Direction ........ 11 POWERFUL Operation ........... 12 COMFORT AIRFLOW Operation ...... -
Page 4: Read Before Operation
READ BEFORE OPERATION Safety Precautions Read the precautions in this manual This appliance is filled with R32. carefully before operating the unit. • After reading, keep this manual in a convenient place so that you can refer to it whenever necessary. If the equipment is transferred to a new user, be sure also to hand over the manual. - Page 5 READ BEFORE OPERATION • Do not attempt to install the air conditioner by yourself. Incorrect work will result in water leakage, electric shocks or fire. For installation, consult the dealer or a qualified technician. • In order to avoid electric shock, fire or injury, if you detect any abnormality such as smell of fire, stop the operation and turn off the breaker.
- Page 6 READ BEFORE OPERATION Safety Precautions • Do not put objects on the panel, or otherwise production malfunctioning may result. • Do not use an unstable stand at the time of operating or maintaining the air conditioner, or otherwise you may topple over or injury yourself. •...
-
Page 7: Names Of Parts
READ BEFORE OPERATION Names of Parts „ Indoor Unit FTKM09/12/15/18*/24* * Appearance of indoor units may differ from some model Air inlet Front panel Room temperature sensor and Room humidity sensor Air filter • Sense the air temperature and humidity around the unit. Air quality filter (enzyme blue Streamer air inlet... - Page 8 READ BEFORE OPERATION Names of Parts „ Open the front panel Backside of the front panel Fixing tab Panel support plate Streamer unit (inside) Prevents mold and allergens with the decomposition power of the streamer discharge. Page 18 „ Outdoor Unit „...
- Page 9 READ BEFORE OPERATION „ Remote Controller Signal transmitter: • It sends signals to the indoor unit. MODE selector button: Display (LCD): • It selects the operation mode • Displays the current settings. (COOL/DRY/FAN ONLY). (In this illustration, each section Page 9 is shown with all its displays ON for the purpose of explanation.) TEMPERATURE adjustment...
-
Page 10: Preparation Before Operation
READ BEFORE OPERATION Preparation Before Operation „ To set the batteries Position correctly! Slide the back cover to Set two dry batteries Set the back cover as take it off. before. AAA.LR03 (alkaline). „ To operate the remote controller • To use the remote controller, aim the transmitter at the indoor unit. -
Page 11: Operation
OPERATION COOL/DRY/FAN ONLY Operation The air conditioner operates in the user selected operation mode. „ To start operation Press button of your desired operation mode. • COOL operation • Press . “ ” appears on the LCD DRY operation • Press . -
Page 12: Adjusting The Airflow Rate
OPERATION Adjusting the Airflow Rate You can adjust the airflow rate to increase your comfort. „ To adjust the airflow rate setting Press • • Each pressing of change the airflow rate setting in sequence shown below. Auto Indoor unit quiet High •... -
Page 13: Adjusting The Airflow Direction
OPERATION Adjusting the Airflow Direction You can adjust the airflow direction to increase your comfort. ATTENTION • Always use a remote controller to adjust the angles of the flaps and louvres. • - If you attempt to move it forcibly with hand when it is swinging, the mechanism may be broken. -
Page 14: Powerful Operation
OPERATION POWERFUL Operation POWERFUL operation quickly maximizes the cooling effect in any operation mode. You can get the maximum capacity. „ To start Press during operation. • POWERFUL operation ends in 20 minutes. Then the system automatically operates again with the previous settings which were used before POWERFUL operation. -
Page 15: Comfort Airflow Operation
OPERATION COMFORT AIRFLOW Operation The flow of air will be in the upward direction while in COOL operation, which will provide a comfortable wind that will not come in direct contact with people. „ To start Press • “ ” appears on the LCD. COOL operation DRY operation Flaps direction... -
Page 16: Intelligent Eye Operation
OPERATION INTELLIGENT EYE Operation “INTELLIGENT EYE” is the infrared sensor which detects the human movement. If no one is in the room for more than 20 minute, the operation automatically changes to energy saving operation. CAUTION • • Do not place large objects near the INTELLIGENT EYE sensor. Also keep heating units or humidifiers outside the sensor’s detection area. -
Page 17: Econo Operation
OPERATION ECONO Operation ECONO operation is a function which enables efficient operation by limiting the maximum power consumption value. This function is useful for cases in which attention should be paid to ensure a circuit breaker will not trip when the product runs alongside other appliances. •... -
Page 18: Mold Proof Operation
OPERATION MOLD PROOF Operation MOLD PROOF operation is a function which reduces the spread of mold by using FAN operation to lower the humidity inside the indoor unit. [To operate automatically] • „ To set Press and hold the button for 2 seconds. •... - Page 19 OPERATION [Flow of function] MOLD PROOF operation MOLD PROOF setting Stop with streamer Heat exchanger is dried for about 60 mins. Automatic During operation, flaps start every time open and air flows. Automatic stop Set function After stop during COOL or DRY MOLD PROOF setting MOLD PROOF operation with streamer...
-
Page 20: Flash Streamer Air Cleaning Operation
OPERATION FLASH STREAMER AIR CLEANING Operation The streamer generates a high-speed electron stream with a high oxidizing power, reducing bad odours and viruses. Together with the air quality filter (enzyme blue with PM2.5) and the air filters, this function cleans the air in the room. „... -
Page 21: Outdoor Unit Quiet Operation
OPERATION OUTDOOR UNIT QUIET Operation OUTDOOR UNIT QUIET operation lowers the noise level of the outdoor unit by changing the frequency and fan speed on the outdoor unit. This function is convenient during night. „ To start • Press • “ ”... -
Page 22: Child Lock Operation
OPERATION CHILD LOCK operation To prevent mishandling by children Setting the CHILD LOCK disables all the buttons except the CHILD LOCK button. This function prevents children from operating the remote controller by mistake. „ To start • Press for about 2 seconds. •... -
Page 23: Timer Operation
OPERATION TIMER Operation Timer functions are useful for automatically switching the air conditioner on or off at night or in the morning. You can also use OFF TIMER and ON TIMER in combination. [OFF TIMER operation] • „ To set 1. - Page 24 OPERATION TIMER Operation [ON TIMER operation] „ To set 1. Press • • “ ” appears on the LCD. 2. Press until the time setting reaches the point you like. • Each pressing of button increases the time setting by 1 hour. •...
-
Page 25: Care
CARE Care and Cleaning CAUTION • Before cleaning, be sure to stop operation and turn the breaker OFF. • When opening and closing the front panel, use a robust and stable stool and watch your step carefully. • After cleaning, make sure that the front panel is securely fixed. Units Wipe them with a dry soft cloth. - Page 26 CARE Care and Cleaning CAUTION • Do not touch the aluminum fins by bare hand at the time of dismounting or mounting the filter. „ Air filter 1. Pull out the air filters. • Open the front panel. Page 23 •...
- Page 27 CARE „ Filter (small) * For the applicable filter type, please refer to NOTE on Page 26 1. Open the front panel and pull out the air filter. Page 23, 24 2. Take off the filters. (small) • Hold the recessed parts of the frame and unhook the 4 claws. •...
- Page 28 CARE Care and Cleaning NOTE • Operation with dirty filters: 1) cannot deodorize the air. 2) cannot clean the air. 3) results in poor cooling. 4) may cause odour. • Dispose of old filters as non-flammable waste. • To purchase the filters (Table 1) or to purchase the another type, contact the dealer where you bought the air conditioner.
-
Page 29: Troubleshooting
TROUBLESHOOTING Troubleshooting These cases are not troubles. The following cases are not air conditioner troubles but have some reasons. You may just continue using it. Case Description / what to check Operation does not start soon. • This is to protect the air conditioner. •... - Page 30 TROUBLESHOOTING Troubleshooting Case Description / what to check The sound of streamer discharge • If the airflow becomes weak, the streamer discharge stops. can no longer be heard. The room temperature does • If the air coming out of the air conditioner is blowing against a not reach the set temperature.
- Page 31 TROUBLESHOOTING Check again. Please check again before calling a repair person. Case Description / what to check The air conditioner does not operate. OPERATION lamp is off. • Hasn’t a breaker turned OFF or a fuse blown? • Isn’t it a power failure? •...
- Page 32 TROUBLESHOOTING Troubleshooting Call the service shop immediately. WARNING „ When an abnormality (such as a burning smell) occurs, stop operation and turn the breaker OFF. • Continued operation in an abnormal condition may result in troubles, electric shocks or fire. •...
- Page 33 TROUBLESHOOTING „ Fault diagnosis by remote controller • In case the air conditioner is malfunctioning, you can check the error code via the remote controller before consulting with service personnel and informing them of the malfunction code. 1. When is held down for about 5 seconds, “...
-
Page 34: Specifications
Specifications Specifications Air conditioner Indoor unit model name FTKM09WV2S FTKM12WV2S FTKM15WV2S Outdoor unit model name RKM09WV2S RKM12WV2S RKM15WV2S Cooling capacity kW(kcal/h) 2.7(2320) 3.6(3100) 4.4(3780) Running current Power consumption 1020 1120 H (mm) Dimensions W (mm) Indoor unit D (mm) Net weight H (mm) Dimensions W (mm) - Page 36 SIAM DAIKIN SALES CO.,LTD. 3P658678-5A_WEB...
