Summary of Contents for DOREMIDI MCV-10
- Page 2 The MCV-10 is used for MIDI control of analog synthesizers, Eurorack modules, and more. The MCV-10 has USB MIDI and MIDI IN interfaces, which can be connected to a computer or MIDI devices. MCV-10 supports V/Oct, Hz/V, 1.2V/Oct, S-Trig, V-Trig, and also supports various MIDI CC controllers and auxiliary outputs for parameters.
- Page 3 Note: The external load will affect the output voltage to a certain extent. Output Mode Support 0/5V, 0/15V, S-Trigger. Default 0/5V. After enabling, When the Gate is open, if a new Note is generated, the MCV-10 Re-Trigger will close the Gate, then open the Gate.
- Page 4 Use a mono 3.5mm TRS cable to connect to the synth's CV input via "CV". Connect the AUX: AUX is the auxiliary output. Use a mono 3.5mm TRS cable to connect to the auxiliary input interface of the synthesizer through "AUX". MCV-10 factory default parameter table Name Description MIDI channel Responds to all MIDI channels by default.
- Page 5 XCOM V2.6 software download link: www.doremidi.cn Software environment: Windows7 or above Connect the MCV-10 to the computer, open XCOM V2.6, and configure the language you need, as shown in the figure: Configure the XCOM software, as shown in the figure:...
- Page 6 As shown in the figure. As shown in the figure: Send the parameters that need to be configured, refer to "MCV-10 Parameter Configuration Table", after configuration, XCOM will receive the same configuration parameters (RX: F0...F7) to indicate...
- Page 7 MCV-10 configuration parameter table Note: Configure parameters through xx, yy, each parameter is hexadecimal (HEX Code). For MCV-10, Gate/CV/AUX numbers are all 0. Name MIDI Type HEX Code Description Defaults yy: MIDI channel. 0~15: MIDI channel 1~16. MIDI Channel...
- Page 8 xx: The CV port number. yy: CV voltage coarse adjustment/transposition, adjust the Note Coarse Tune/ corresponding to CV SysEx F0 00 21 5E 17 xx yy F7 yy = 0 Transpose voltage. 1~12: move down 1~12 semitones. 13~24: move up 1~12 semitones.
- Page 9 xx: The AUX port number. yy: The frequency division of the MIDI clock. It is valid MIDI Clock SysEx F0 00 21 5E 22 xx yy F7 when AUX Type is set to yy = 0 Divider MIDI Clock. 2~24: 2~24 frequency division.
- Page 10 Question: The output voltage is not accurate. Answer: Please follow the steps below: According to the product parameters of MCV-10, check whether the external load exceeds the requirements of MCV-10. Please adjust the output voltage by means of coarse adjustment/fine adjustment.
