- Page 1 Easyflush Direct Installation Guide Please leave this booklet with the user for future reference.
- Page 2 The dual flush setting is a factory default but can be changed by the installer. Easyflush Direct Walkaway is activated when the user stands up or leaves the cubicle but it can also be activated by the user bringing their hand toward the sensor. The dual flush setting is a factory default but can be changed by the installer.
-
Page 3: Installation
2 The use of a specific type of WC bowl which has been tested and shown to incorporate the equivalent of a type AB air gap. 3 The use of a type DC pipe interrupter (supplied with all Cistermiser Direct Flushing products). A note about type DC pipe interrupters These devices have an integral air gap;... -
Page 4: Installation Schematic
Pipework diagram suggestion only X – Walkaway version only DMA55 power supply included with Easyflush Direct (Requires 1A If this distance is less than 12cm it is recommended fused spur) that the Hand Activation is disabled. Refer to Section 9. (ICU required; not supplied.) 4 | cistermiser.co.uk... - Page 5 300 – 400mm NOTE: NOTE: Sensor should be located outside body Sensor should be located inside shape for WAVE only. body shape for WALKAWAY only. Have a question? Call our customer support team on 0118 969 1611 cistermiser.co.uk | 5...
- Page 6 NOTE: *If wall thickness is under 32mm use packer to prevent screw causing damage to sensor 6 | cistermiser.co.uk Have a question? Call our customer support team on 0118 969 1611...
- Page 7 Easyflush Direct is supplied with a DC pipe interrupter. Fit the DC pipe interrupter to the valve outlet ensuring the rubber seal is in place. Rubber seal NOTE: To connect to supply pipework you will require 1” BSP connesction a 1" female BSP to 22mm or 28mm (copper) connection (not supplied).
-
Page 8: Power Connections
• Hygiene rinse on/off. The installer is able to switch the 12 hr hygiene rinse function on or off. • Clean mode. The Easyflush Direct can be disabled for a short period to allow for cleaning. • Siphonic trap refill mode. When activated this allows a small flush after every flush to refill the siphonic trap. - Page 9 2 bar. To comply with the water regulations the full flush volume must not exceed 6 litres. The Easyflush Direct is fitted with a 100 lpm flow regulator* that will limit the flow through the valve to 100 lpm.
- Page 10 5 bar NOTE: When using the Easyflush Direct valve from a mains water supply, the pressure may be higher than is suitable for the design of the bowl which can cause splashing to occur. In such cases fit a flow regulator (supplied) as indicated in Section 5.
- Page 12 8. Advanced settings guide Easyflush Direct Walkaway Carry out only if default settings need to be changed. Disconnect power, wait for 5 seconds and reconnect. Solid amber while ambient light detected. Place hand 4-6cm from sensor until When flashing amber.
- Page 13 Easyflush Direct Wave Carry out only if settings need to be changed. Disconnect power, wait for 5 seconds and reconnect. Solid amber while ambient light detected. Place hand 4-6cm from sensor until When flashing amber. constant green, then remove hand.
- Page 14 Number of flashes up to three seconds for the product to sense the ICU. Range (cm approx) The Easyflush Direct will return to normal operation if there are no button presses for 30 seconds. For Walkaway version Configuring sensor range...
- Page 15 Configuring the full flush duration Activating the dual flush function Point the ICU at the Easyflush Direct sensor and Point the ICU at the Easyflush Direct sensor and press the button (the sensor press the button (the sensor flush duration dual flush blinks green).
-
Page 16: Frequently Asked Questions
Ensure water pressure is min 0.5 bar. Flush any potential debris out No obvious indicator of the valve. Sensor is flashing red slowly Low or no power. Contact Cistermiser. 16 | cistermiser.co.uk Have a question? Call our customer support team on 0118 969 1611... - Page 17 Cistermiser directly on 0118 969 1611 or at Please make a note of the serial number and support@cistermiser.co.uk, with a take a photograph of the installation before you photograph and the serial number, to help leave site.
