DHP Ashby 4122429 Assembly Instructions Manual

Hide thumbs
Table of Contents

Advertisement

Available languages

Available languages

Quick Links

Download this manual
Weight Limit: 450 Lb /204 Kg
S.D.- 03/23/2017
Thank you for purchasing from DHP!
DO NOT RETURN TO THE STORE !
If parts are missing or damaged, we will gladly ship your
replacement parts free of charge.
Visit www.dhpfurniture.com/eng/support-home
or call Toll-Free 1-800-267-1739
Date of Purchase
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY
INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
4122429
Ashby Bed
Grey Linen
Lot Number
B34412242900 - 241643 -XL
Full
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Ashby 4122429 and is the answer not in the manual?

Questions and answers

Related Manuals for DHP Ashby 4122429

Summary of Contents for DHP Ashby 4122429

  • Page 1 Ashby Bed Full Grey Linen Weight Limit: 450 Lb /204 Kg Thank you for purchasing from DHP! DO NOT RETURN TO THE STORE ! If parts are missing or damaged, we will gladly ship your replacement parts free of charge.

  • Page 2: Warranty Information

    Warranty Information Read Before Beginning Assembly DHP warrants this product to be free from defects in material and workmanship and Call our toll free number if you need assistance. agrees to remedy any such defect. This warranty covers one year from the date of Work in a spacious area, preferably on a carpet, near where the unit will be original purchase.
  • Page 3 B34412242900...
  • Page 4 Parts Replacement Parts, visit www.dhpfurniture.com/eng/support-home All in 1 big box! There are inner box(es) that include components required to complete this assembly. Before you throw the package, please use the Headboard Footboard Side Panel Side Panel Fabric Back Panel Side Rail Check Box to identify the parts and ensure that T945990 T946000...

  • Page 5: Hardware Pack

    Hardware Pack Hardware Pack #: T4028319-01 1/4" X 3/4" X 44 1/4" X 1 3/8" 1/4" X 1 9/16" X 28 1/4" X 1 3/4" 5/16" X 2 1/4" 1/4" 5/16" Please do not completely tighten all the hardware, until the entire assembly is completed, unless otherwise indicated in the step-by-step instructions.
  • Page 6 Step 1 Attach F & H to C & D with BOLT Repeat the same step for remaining parts C & D . B34412242900...
  • Page 7 Step 2 Attach G x 2 to previous subassembly C & D with BOLT Repeat the same step for remaining subassembly C & D . B34412242900...
  • Page 8 Step 3 Attach S to D and T to C with BOLT Repeat the same step for the other subassembly C & D. B34412242900...
  • Page 9 Step 4 Stick A1 to the back of A with Velcro as illustrated. B34412242900...
  • Page 10 Step 5 Screw BOLTS into A & B and leave half of the bolts exposed. Do not completely tighten the BOLTS, leave half of length exposed. B34412242900...
  • Page 11 Step 6 Hang C & D on A & B as illustrated below, don't completely tighten the BOLT untill the STEP 10 is complete. B34412242900...
  • Page 12 Step 7 Push NUT into the hole of the leg Z, then attach Z to N with BOLT and NUT Repeat this step for all remaining legs Z. B34412242900...
  • Page 13 Step 8 8.1 Attach N x 4 to A,B,C & D with BOLT 8.2 Attach L x 2 to H with BOLT B34412242900...
  • Page 14 Step 9 Insert I x 2 & J into M x 2, then fix them with BOLT B34412242900...
  • Page 15 Step 10 Attach subassembly from previous STEP to A & B with BOLTS , then properly tighten all the bolts. B34412242900...
  • Page 16 Step 11 Attach K to F x 2 & J with BOLT B34412242900...
  • Page 17 Step 12 12.1 Insert P into X; 12.2 Then press X into F & G; 12.3 Insert both P into Y, then press Y into I & J as shown. B34412242900...

  • Page 18: Helpful Hints

    Helpful Hints Helpful Hints Weight Limit: 450 Lb /204 Kg people lifting and carrying the unit to its new location. reassembled to move. item. They are illustred on this page and available for replacement. WARNINGS: For safety reasons and to prevent injuries: This bed is not intended for use by childen under 4 years old.
  • Page 19 | www.pinterest.com/dhpfurniture para tener acceso a promociones de DHP. producto o simplemente ordenar otras partes, dirijase a: Gracias por comprar un producto DHP. Esperamos que este le proporcione muchos cs@dhpfurniture.com 1-800-267-1739 / Lunes - Viernes / 9:00 am - 5:00 pm (hora del este)
  • Page 20 Lea antes de comenzar a ensamblar Partes Piezas de reemplazo, visite www.dhpfurniture.com/spa/support-home Todo se incluye en 1 caja grande! (sin embargo es recomendable contar con ayuda adicional). Tiempo estimado de Hay 1 caja(s) interna(s) que incluyen los componentes necesarios para ensamble es 2 horas.
  • Page 21 Una la parte G x 2 con C & D con los PERNO . Repita el paso para las otras partes C & D. Sus muebles DHP se pueden desmontar y volver a ensamblar en caso de mudanza. Paso3 Una la parte S en D, T en C con PERNO .

  • Page 22: Garantie

    Scannez le code QR ou visitez-nous au www.dhpfurniture.com/eng/registrer au Canada. Suivez-nous sur: www.facebook.com/DorelHomeProducts www.twitter.com/DHPfurniture Contact www.pinterest.com/dhpfurniture les concours et les promotions de DHP. cs@dhpfurniture.com 1-800-267-1739 / Lundi - Vendredi / 9:00 am - 5:00 pm (Heure de l'Est) Remarque: concours. B34412242900 - 241643 -XL...

  • Page 23: Avant De Commencer L'assemblage

    Avant de commencer l'assemblage www.dhpfurniture/fre/support-home plancher et le produit. 2 (cependant il vaut l'assemblage. est de 2 heures. lors de l'assemblage. Support Gauche: T393080 (A1) Support Droite: T393090 Pied de Lit: T945980 capuchon simple: T926370 capuchon double: T926380 Pied: T946030 commercial.

  • Page 24: Conseils Utiles

    Instructions Limite de Poids: 450 Lb / 204 Kg Attacher F,H C,D avec BOULON C et D. Conseils utiles Attacher G C,D avec BOULON C et D. personnes pour soulever et transporter le mobilier vers son nouvel emplacement. Attacher S D, T C avec BOULON et D.
