Weight Limit: 600 lbs / 272 kgs
WARNING
• This futon has been designed for seating three (3) average adults. To prevent injury and damage to this unit, PROHIBIT jumping on it.
• This product is designed for home use and not intended for commercial use.
• Children under the age of 5, small infants and babies must not sleep on this product for safety reasons.
• Recommended # of people needed for assembly: 1 (however it is always better to have an extra hand). Estimated assembly time is 10 minutes.
• THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
SD - 5/14/2013
2008517
Metro Sofa Sleeper
DO NOT RETURN PRODUCT TO THE
STORE
STOP
Individual stores do not stock parts.
If a part is missing or damaged, call our
toll-free customer service line. We will
gladly ship your replacement parts FREE
of charge.
1-800-267-1739
Need Parts or Assistance?
or access our website
www.dhpfurniture.com
For prompt, reliable service; please have your instruction
manual ready.
Date of Purchase
___ / ___ / ___
Lot Number
_________
B34200851701 - 015219-AN
Red
Advertisement
Table of Contents
Related Manuals for DHP 2008517
Summary of Contents for DHP 2008517
- Page 1 2008517 Metro Sofa Sleeper Weight Limit: 600 lbs / 272 kgs DO NOT RETURN PRODUCT TO THE STORE STOP Individual stores do not stock parts. If a part is missing or damaged, call our toll-free customer service line. We will gladly ship your replacement parts FREE of charge.
-
Page 2: Helpful Hints
Warranty Information DHP warrants this product to be free from defects in material and workmanship and agrees to remedy any such defect. This warranty covers one year from the date of original purchase. This is solely limited to the repair or replacement of defective parts and no assembly labor is included. - Page 3 3/15 B34200851701...
- Page 4 PARTS LEGS T607610 SEAT T607600 CUSHIONS T607640 RIGHT ARM LEFT ARM T607630 T607620 4/15 B34200851701...
- Page 5 PARTS WASHERS HEX KEY BOLT 5/16 " X 3 9/16" T3201098-00 BLISTER PACK HARDWARE NOTE: Please do not completely tighten any screws until the entire assembly is complete. Once assembly is complete, please be sure tighten all hardware. 5/15 B34200851701...
- Page 6 Take out four LEGS (B), two CUSHIONS (E), LEFT ARM (C) & RIGHT ARM (D) contained in the storage of the SEAT (A), as shown below. & 6/15 B34200851701...
- Page 7 Attach the LEGS (B) to the SEAT (A) , as shown below. NOTE: Please remove the protective cap on the tip of thread before assembling . 7/15 B34200851701...
- Page 8 Attach the ARMS (C & D) to the SEAT (A) with the BOLTS(1) & WASHERS (2), as shown below. 8/15 B34200851701...
- Page 9 To convert from sofa position to bed position: Pull the backrest in direction of the arrow as far as possible and then release, as show below. 9/15 B34200851701...
- Page 10 Al registrar tu producto con nosotros entrarás automáticamente a nuestro concurso trimestral con la oportunidad de ganar premios increíbles. Beneficios: Con tan sólo tomarte unos minutos en registrar tu producto y mejorar tu experiencia con DHP puedes obtener: ● Información exclusiva sobre nuevos productos ●...
- Page 11 PÁGINA 04 A)ASIENTO----- ---------------T607600 ------ CANTIDAD: 1 B)PATAS ---------------------- T607610 ------ CANTIDAD: 4 C)BRAZO IZQUIERDO ------ T607620 ------ CANTIDAD: 1 D)BRAZO DERECHO -------- T607630 ------ CANTIDAD: 1 E)COJINES ------------------- T607640 ------ CANTIDAD: 2 PÁGINA 05 1)PERNO 5/16 " X 3 9/16" ------------------ CANTIDAD: 8 2)LAVADORA ----------------------------------- CANTIDAD: 8 3)LLAVE DE TUERCA HEXAGONAL 5mm -- CANTIDAD: 1 EMBALAJE BLISTER: -------- T3201098-00...
-
Page 12: Consejos Útiles
Información de Garantía DHP garantiza que este producto está libre de defectos materiales y de mano de obra aceptando corregir cualquier defecto. Esta garantía es válida por un año a partir de la fecha de compra original de este artículo. Esta garantía está limitada a la reparación o reemplazo de piezas defectuosas, más no a la mano de obra incurrida en el ensamblaje de este artículo. - Page 13 à l'information à jour sur les tendances, les nouveaux produits, les concours et les promotions des informations DHP. Merci d'avoir acheté un produit de DHP. Nous espérons que cela donnera de nombreuses années de service.
- Page 14 PAGE 04 A) SIÈGE - - -------------- T607600 - QUANTITÉ : 1 B) JAMBE - --------------- T607610 - QUANTITÉ : 4 C) BRAS GAUCHE - ----- T607620 - QUANTITÉ : 1 D) BRAS DROIT - ------- T607630 - QUANTITÉ : 1 E) COUSSINS -----------T607640 -- QUANTITÉ...
-
Page 15: Avant De Commencer L'assemblage
Informations sur la garantie DHP garantit que ce produit est exempt de tout vice de matériau et de fabrication et s'engage à remédier à un tel défaut. Cette garantie couvre un an à compter de la date d'achat originale. Cela se limite uniquement à la réparation ou au remplacement des pièces défectueuses. Aucun travail de montage n'est inclus.
