Summary of Contents for Fanimation Pedestal FP900

  • Page 1 The Pedestal ™ Floor Fan Net Weight 45 lbs. Model No. FP900 OWNER’S MANUAL READ AND SAVE THESE INSTRUCTIONS...
  • Page 2: Table Of Contents

    Fanimation. 7. Fanimation reserves the right to modify or discontinue any product at any time and may substitute any part under this warranty. 8. Under no circumstances may a fan be returned without prior authorization from Fanimation. The receipt of purchase must ac- company authorized returns and must be sent freight prepaid to Fanimation.
  • Page 3: Unpacking Instructions

    • Blade Mounting Hardware Bag Substitution of parts or accessories not designated • C20 Remote Control for use with this product by Fanimation could result in • SW50 Receiver Switch Cup Unit personal injury or property damage. Contact your retail •...
  • Page 4: Electrical Requirements

    Electrical Requirements Your new floor fan will require a grounded electrical supply WARNING line of 120 volts AC, 60 Hz, 15 amp circuit. The fan base must be securely anchored. To reduce the risk of fire, electrical shock, or personal injury, mount fan to floor or structural member.
  • Page 5: How To Put Your Floor Fan Together

    How to Set and Install Your SW50 Switch Cap Receiver • SW50 Receiver: 1. Carefully, slide the remote Receiver from the Switch Cap Housing, and locate the code switches on the underside of the receiver unit (Figure 3). 2. Slide code switches to the same positions as set on your transmitter (Figures 1 and 2).
  • Page 6: Mounting The Fan Blades

    Mounting the Fan Blades You will find the fan blade set packed in its own carton and the blade holders and hardware bag in the base assembly carton. The hardware bag for the blade holders consists of 10 screws. INSTALLATION NOTE Side B Do not connect fan blades until the fan is completely installed.
  • Page 7: Trouble Shooting

    Trouble Shooting WARNING For your own safety turn off power at fuse box or circuit breaker before trouble shooting your fan. Trouble Probable Cause Suggested Remedy 1. FAN WILL NOT START 1. Fuse or circuit breaker blown. 1. Check main and branch circuit fuses or circuit break- ers.
  • Page 8: Parts List

    Parts List Model #FP900 Ref. No. Description Part # Switch Cap Receiver SW50 Pedestal Flywheel Ring P905 Fan Motor Assembly FP320 Motor Support P8021-85.5 M/S, Washer Hd., 8–32 x 3½”, Black Lock Nut, Nylon Insert, 8–32 FANI1406 Socket Cap Screw, ⁄...
  • Page 9: Exploded-View Drawing

    ™ The Pedestal FP900 Exploded-View Side B Side A NOTE: The illustration shown is not to scale or its actual configuration may vary, wires partially removed for clarity. Figure 8...
  • Page 10 10983 Bennett Parkway Zionsville, IN 46077 (888) 567-2055 FAX (866) 482-5215 Outside U.S. call (317) 733-4113 Visit Our Website @ www.fanimation.com Copyright 2004 Fanimation 2004/02...
