Summary of Contents for Sunbeam Luna
- Page 1 Sunbeam Luna Installation manual Steel roof Landscape December 2022 | Version 1.0 | This is the English translation of the original Dutch installation manual supporting sustainability...
- Page 2 General Description of the user This document is intended for the installer. Sunbeam Luna should only be installed by a trained installer who has fully read and understood the contents of this manual. Intended use and reasonably foreseeable misuse This type of Sunbeam Luna is suitable for mounting on trapezoidal steel roofs, corrugated steel roofs and pitched even roofs (bitumen, PVC, EPDM, TPO).
- Page 3 Preparation Recommended tools Socket bit 5/16" or 8 mm Electric screwdriver Phillips screwdriver Chalk line reel Chalk Tape measure Socket bit 3/8" or 10 mm Setting the sizing tool COMMENT For large installations, it is recommended to use several sizing tools. 1.
- Page 4 6. Screw on the next mounting profile. COMMENT All clamps in the Luna system are inserted clockwise into the mounting profile, and removed counter- clockwise. 7. Repeat steps 4 to 6 to install the remaining rows of mounting profiles.
- Page 5 Placing the panels 12. In the next row of mounting profiles, place a mid clamp and slide it against the first row of installed panels. 1. Position the first panel against the two end clamps at the corner 3/8” of the field. 5-9 Nm 2.
- Page 6 The national regulations in the country of installation must be observed at all times. Make sure you are aware of the safety measures prescribed by Sunbeam or the country of installation. If in doubt, consult your safety officer. Ensure safety or health hazards are shared with the employer, supervisor and executive worker for their information.
