- Page 1 Sunbeam Luna Installation manual Steel roof Portrait December 2022 | Version 1.0 | This is the English translation of the original Dutch installation manual supporting sustainability...
- Page 2 General Description of the user This document is intended for the installer. Sunbeam Luna should only be installed by a trained installer who has fully read and understood the contents of this manual. Intended use and reasonably foreseeable misuse This type of Sunbeam Luna is suitable for mounting on trapezoidal steel roofs, corrugated steel roofs and pitched even roofs (bitumen, PVC, EPDM, TPO).
- Page 3 Preparation Recommended tools Socket bit 5/16" or 8 mm Electric screwdriver Phillips screwdriver Chalk line reel Chalk Tape measure Socket bit 3/8" or 10 mm Marking the installation area 1. Using a tension line or chalk line, mark the outer contours of the field. 2.
- Page 4 Portrait system installation Installing the mounting profiles 5/16” 3-4 Nm 3. Place an end clamp in the first and last column of the mounting profiles in line with the marked panel ends. 1. Align the mounting profile with the marked profile positions. 2.
- Page 5 4. Slide the 2 mid clamps against the panel. 12. Connect the panel cables to the return cable of the other row of panels. 13. Clamp the panel cables into the cable clamps. 5. Position the second panel between the mid clamps. 6.
- Page 6 The national regulations in the country of installation must be observed at all times. Make sure you are aware of the safety measures prescribed by Sunbeam or the country of installation. If in doubt, consult your safety officer. Ensure safety or health hazards are shared with the employer, supervisor and executive worker for their information.
