5.1ch Home Theater System
HT-SR600
AV Receiver (HT-R340)
Front Speakers (SKF-350F L/R)
Center Speaker (SKC-350C)
Surround Speakers (SKM-350S L/R)
Subwoofer (SKW-350)
Instruction Manual
Thank you for purchasing an Onkyo 5.1ch Home
Theater System. Please read this manual thoroughly
before making connections and plugging in the unit.
Following the instructions in this manual will enable
you to obtain optimum performance and listening
enjoyment from your new 5.1ch Home Theater Sys-
tem.
Please retain this manual for future reference.
Contents
Introduction ..................................... 2
Connection .................................... 19
Turning On & First Time Setup..... 34
Basic Operation
Playing your AV components ....... 36
Using the Tuner............................ 38
Enjoying the Listening Modes ..... 46
Advanced Operation ..................... 48
Troubleshooting ............................ 55
Specifications................................ 58
E
n

Advertisement

Table of Contents
loading

Summary of Contents for Onkyo HT-SR600

  • Page 1 Center Speaker (SKC-350C) Surround Speakers (SKM-350S L/R) Subwoofer (SKW-350) Instruction Manual Thank you for purchasing an Onkyo 5.1ch Home Theater System. Please read this manual thoroughly before making connections and plugging in the unit. Following the instructions in this manual will enable you to obtain optimum performance and listening enjoyment from your new 5.1ch Home Theater Sys-...
  • Page 2: Important Safety Instructions

    WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPARATUS TO RAIN OR MOISTURE. CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING QUALIFIED PERSONNEL.
  • Page 3: Precautions

    5. Never Touch this Unit with Wet Hands—Never handle this unit or its power cord while your hands are wet or damp. If water or any other liquid gets inside this unit, have it checked by your Onkyo dealer. 6. Handling Notes •...
  • Page 4: Speaker Precautions

    We, ONKYO EUROPE ELECTRONICS GmbH LIEGNITZERSTRASSE 6, 82194 GROEBENZELL, GERMANY declare in own responsibility, that the ONKYO product described in this instruction manual is in compliance with the corresponding technical standards such as EN60065, EN55013, EN55020 and EN61000-3-2, -3-3. GROEBENZELL, GERMANY...
  • Page 5: Table Of Contents

    “Dolby”, “Pro Logic” and the double-D symbol are regis- tered trademarks of Dolby Laboratories. *2. “DTS” and “Neo:6” are trademarks of Digital Theater Sys- tems, Inc. *3. OptiResponse, and OR-EQ are trademarks of Onkyo Cor- poration. Contents Introduction Important Safety Instructions...2 Precautions ...3...
  • Page 6: Package Contents

    Package Contents Make sure you have the following items: HT-R340 HT-R340 Remote controller & two batteries (AA/R6) (American type shown) Indoor FM antenna (Connector type varies from country to country.) AM loop antenna Power-plug adapter Only supplied in certain countries. Use this adapter if your AC outlet does not match with the plug on the AV receiver’s power cord.
  • Page 7: Before Using The Av Receiver

    Before Using the AV receiver Setting the Voltage Selector (on some models) Some models have a voltage selector switch for compat- ibility with power systems around the world. Before you plug in this model, make sure that the voltage selector is set to the correct voltage for your area.
  • Page 8: Front & Rear Panels

    Front & Rear Panels Front Panel North American and Asian Models STANDBY/ON STANDBY A SPEAKERS B TONE PHONES MULTl CH European Models STANDBY/ON STANDBY A SPEAKERS B TONE PHONES MULTl CH For detailed information, see the pages in parentheses. STANDBY/ON button (34) This button is used to set the AV receiver to On or Standby.
  • Page 9 Front & Rear Panels—Continued MEMORY button (39) This button is used when storing or deleting radio presets. TUNING MODE button (38) This button is used to select the Auto or Manual tun- ing mode. Arrow/TUNING/PRESET & ENTER buttons (48, 50–53) When the AM or FM input source is selected, the TUNING [ ] buttons are used to tune the...
  • Page 10: Rear Panel

    (RCA) between the AV receiver and the other component, even if they are connected digitally. Note: can only be used with Onkyo components. CD IN These analog inputs can be used to connect a CD player with analog outputs.
  • Page 11: Speaker Package

    Speaker Package Front, Center, Surround, & Subwoofer speakers (SKF-350F, SKC-350C, SKM-350S, SKW-350) ■ Rear SKF-350F SKC-350C Speaker terminals These push terminals are for connecting the speaker to the HT-R340 with the supplied speaker cables. The supplied speaker cables are color-coded for easy identification.
  • Page 12: Remote Controller

    In RECEIVER/TAPE mode, you can control the AV receiver and an Onkyo cassette recorder connected via ■ DVD, CD, MD, CDR & HDD Modes With these modes, you can control an Onkyo DVD player and CD/MD/CDR/HDD player/recorder. Use the REMOTE MODE buttons to select a mode.
  • Page 13 This button is used to turn on the OptiResponse Equalizer, which optimizes performance when the HT-R340 is used with the speakers included in the HTP-350 Home Theater Speaker Package. When the OptiResponse Equalizer is on, you can enjoy a powerful sound with movies or music even at low...
  • Page 14: Dvd Mode

    Remote Controller—Continued DVD Mode To select your DVD player as the input source, press: RECEIVER To set the remote controller to DVD mode, press the [DVD] REMOTE MODE button. ON/STANDBY REMOTE MODE RECEIVER TAPE INPUT SELECTOR MULTI CH TAPE TUNER + 10 -- / --- DIMMER...
  • Page 15 Remote Controller—Continued CD Mode To select your CD player as the input source, press: RECEIVER To set the remote controller to CD mode, press the [CD] REMOTE MODE button. ON/STANDBY REMOTE MODE RECEIVER TAPE INPUT SELECTOR MULTI CH TAPE TUNER + 10 -- / --- DIMMER...
  • Page 16 Remote Controller—Continued MD, & CDR Mode To select your MiniDisc or CD recorder as the input source, press: RECEIVER TAPE * You must change the Input Display (see page 35). To set the remote controller to MD or CDR mode, press the [MD] or [CDR] REMOTE MODE button.
  • Page 17 Remote Controller—Continued HDD Mode To select your HDD component as the input source, press: RECEIVER TAPE * You must change the Input Display (see page 35). To set the remote controller to HDD mode, press the [HDD] REMOTE MODE button. ON/STANDBY REMOTE MODE RECEIVER...
  • Page 18 To select your Cassette deck as the input source, press: RECEIVER TAPE mode is used to control an Onkyo cassette recorder connected to the AV receiver via To set the remote controller to TAPE mode, press the [RECEIVER] REMOTE MODE button.
  • Page 19: Enjoying Home Theater

    Front left and right speakers (SKF-350F L/R) These output the overall sound. Their role in a home theater is to provide a solid anchor for the sound image. They should be positioned facing the listener at about ear level, and equally spaced from the TV.
  • Page 20: Connecting Your Speakers

    Connecting Your Speakers Speaker Connection Precautions Read the following before connecting your speakers: • You can connect speakers with an impedance of 6 ohms or higher. If you use speakers with a lower impedance, and use the amplifier at high volume lev- els for a long period of time, the built-in protection circuit may be activated.
  • Page 21: Wall Mounting

    Connecting Your Speakers—Continued Wall Mounting The speakers can easily be wall mounted by using the keyhole slots. To prevent the speaker from vibrating against the wall, attach two of the supplied thick rubber stoppers to the rear of each speaker. To mount the front or surround speakers vertically, use the keyhole slot shown to hang each speaker on a screw that’s securely screwed into the wall.
  • Page 22: Connecting Antenna

    Connecting Antenna This section explains how to connect the supplied indoor FM antenna and AM loop antenna, and how to connect commercially available outdoor FM and AM antennas. The AV receiver won’t pick up any radio signals without any antenna connected, so you must connect the antenna to use the tuner.
  • Page 23: Connecting An Outdoor Fm Antenna

    Connecting Antenna—Continued Connecting an Outdoor FM Antenna If you cannot achieve good reception with the supplied indoor FM antenna, try a commercially available out- door FM antenna instead. Notes: • Outdoor FM antennas work best outside, but usable results can sometimes be obtained when installed in an attic or loft.
  • Page 24: Connecting Your Components

    Connecting Your Components About AV Connections • Before making any AV connections, read the manuals supplied with your other AV components. • Don’t connect the power cord until you’ve completed and double-checked all AV connections. Optical Digital Jacks The AV receiver’s optical digital jack has shutter-type cover that open when an optical plug is inserted and close when it’s removed.
  • Page 25: Which Connections Should I Use

    Connecting Your Components—Continued Connecting Both Audio & Video By connecting both the audio and video outputs of your DVD player and other AV components to the AV receiver, you can select both the audio and video simultaneously simply by selecting the appropriate input source on the AV receiver. : Signal Flow Video Audio...
  • Page 26: Connecting A Dvd Player

    Connecting Your Components—Continued Connecting a DVD Player Step 1: Video Connection (DVD Player to AV Receiver to TV) If your TV has component video input jacks, connect your DVD player to the AV receiver’s COMPONENT VIDEO DVD IN jacks. And connect the AV receiver’s COMPONENT VIDEO OUT jacks to your TV. This will provide better picture quality than connection If your TV doesn’t have component video input jacks, connect your DVD player to the AV receiver’s DVD IN VIDEO jack.
  • Page 27 Connecting Your Components—Continued Step 2: Audio Connection If your DVD player has a coaxial digital audio output jack, connect it to the AV receiver’s DIGITAL IN COAX- IAL jack. You can enjoy Dolby and DTS listening modes with this connection. If your DVD player has an optical digital audio output jack instead of coaxial one, connect it to the AV receiver’s DIGITAL IN OPTICAL 1 or 2 jack, and set the DIGITAL INPUT assignment to OPT1 or OPT 2 (see page 35).
  • Page 28: Connecting A Vcr

    Connecting Your Components—Continued Connecting a VCR Connecting a VCR for Playback Step 1: Video Connection (VCR to AV Receiver to TV) Connect your VCR’s video output jack to the AV receiver’s VIDEO 1 IN jack and connect the AV receiver’s MONITOR OUT jack to your TV’s video input jack.
  • Page 29 Connecting Your Components—Continued Connecting a VCR for Recording Step 1: Video Connection Connect the AV receiver’s VIDEO 1 OUT jack to your VCR’s video input jack. Step 2: Audio Connection Connect the AV receiver’s VIDEO 1 OUT L/R jacks to your VCR’s audio input jacks. HT-R340 Connecting a Camcorder, Games Console, or Other Device Step 1: Video Connection...
  • Page 30: Connecting A Satellite, Cable, Set-Top Box, Or Other Video Source

    Connecting Your Components—Continued Connecting a Satellite, Cable, Set-top Box, or Other Video Source Step 1: Video Connection Connect your set-top box’s video output jack to the AV receiver’s VIDEO 2 IN jack and connect the AV receiver’s MONITOR OUT jack to your TV’s video input jack. If your VCR and TV have component video jacks, connect your set-top box’s component video output to the AV receiver’s COMPONENT VIDEO VIDEO 2 IN jacks, and connect the AV receiver’s COMPONENT VIDEO OUT jacks to your TV’s component video in jacks.
  • Page 31: Connecting A Cd Player Or Turntable

    Connecting Your Components—Continued Connecting a CD Player or Turntable ■ CD Player or Turntable with Built-in Phono Preamp Connect your CD player’s analog audio output jacks, or your turntable with built-in phono preamp’s audio output jacks to the AV receiver’s CD IN L/R jacks. With connection player or turntable.
  • Page 32: Connecting A Cassette, Cdr, Minidisc, Or Dat Recorder

    Connecting Your Components—Continued Connecting an HDD-compatible Component (Audio Only) As of this printing, the Onkyo Remote Interactive Dock is the only HDD-compatible component available. Connect your HDD-compatible component’s analog audio output jacks to the AV receiver’s VIDEO 3 IN L/R jacks or TAPE IN L/R jacks.
  • Page 33: Remote Control

    Connecting Your Components—Continued Connecting Onkyo Components Step 1: Make sure that each Onkyo component is connected to the AV receiver with an analog audio cable. Step 2: Make the connection. Step 3: If you’re using an MD, CDR, or HDD component, change the Input Display (see page 35).
  • Page 34: Turning On

    ■ Have you connected a component to a digital audio input? If you have, see “Assigning Digital Inputs to Input Sources” on page 35. ■ Have you connected an Onkyo MD recorder, CD recorder, or next generation HDD-compatible component? If you have, see “Changing the Input Display” on page 35.
  • Page 35: First Time Setup

    VIDEO 3 Note: HDD can be selected for the TAPE input selector or VIDEO 3 input selector, but not both at the same time. -capable Onkyo MiniDisc to work properly, you must change this TUNING / PRESET MASTER VOLUME ENTER...
  • Page 36: Basic Av Receiver Operation

    To adjust the volume, use the MASTER VOLUME control, or the remote controller’s [VOL] button. The AV receiver is designed for home theater enjoyment and has a wide volume range for precise adjustment. Note: The maximum master volume level is affected by the subwoofer volume level.
  • Page 37: Playing Your Av Components

    Playing Your AV Components—Continued Using the Multichannel Input ON/STANDBY REMOTE MODE RECEIVER RECEIVER TAPE INPUT SELECTOR MULTI CH MULTI CH TAPE TUNER + 10 --/--- DIMMER SLEEP DISC ALBUM The multichannel input is for connecting a component with individual 5.1-channel analog audio output jacks, such as a DVD player or MPEG decoder.
  • Page 38: Using The Tuner

    Using the Tuner Listening to the Radio STANDBY/ON STANDBY A SPEAKERS B TONE STEREO LISTENING MODE DISPLAY DIGITAL INPUT PHONES MULTl CH VIDEO 1/VCR VIDEO 2 VIDEO 3 With the built-in tuner, you can enjoy AM and FM radio stations. You can store your favorite stations as presets for quick selection.
  • Page 39: Using The Tuner

    Using the Tuner—Continued Presetting Radio Stations 2, 4 TUNING / PRESET STANDBY/ON STANDBY RETURN A SPEAKERS B TONE STEREO LISTENING MODE DISPLAY DIGITAL INPUT RT/PTY/TP MEMORY TUNING MODE CLEAR PHONES MULTl CH VIDEO 1/VCR VIDEO 2 VIDEO 3 TAPE TUNER You can store up to 30 of your favorite radio stations as presets.
  • Page 40 Using the Tuner—Continued Using RDS (European models only) RDS only works with European models and only in areas where RDS broadcasts are available. When tuned into an RDS station, the RDS indicator appears. RDS indicator ■ What is RDS? RDS stands for Radio Data System and is a method of transmitting data in FM radio signals.
  • Page 41 Using the Tuner—Continued Displaying Radio Text (RT) TUNING / PRESET STANDBY/ON STANDBY RETURN A SPEAKERS B TONE STEREO LISTENING MODE DISPLAY DIGITAL INPUT RT/PTY/TP MEMORY TUNING MODE CLEAR PHONES MULTl CH VIDEO 1/VCR VIDEO 2 VIDEO 3 TAPE TUNER When tuned to an RDS station that’s broadcasting RT text information, that information can be displayed.
  • Page 42: Common Functions

    Common Functions This chapter explains functions that can be used with any input source. TONE, –, + STANDBY/ON STANDBY A SPEAKERS B TONE STEREO LISTENING MODE DISPLAY DIGITAL INPUT PHONES MULTl CH VIDEO 1/VCR VIDEO 2 VIDEO 3 PHONES DIMMER Using Headphones You can connect a pair of stereo headphones (1/4-inch phone plug) to the AV receiver’s PHONES jack for pri-...
  • Page 43: Using The Sleep Timer

    10 minutes. OR-EQ Using the OptiResponse Equalizer When using the HT-R340 with the speakers included in the HTP-350 Home Theater Speaker Package, by turning on the OptiResponse equalizer, you can enjoy a powerful sound with movies or music. Remote...
  • Page 44: Adjusting Speaker Levels

    Common Functions—Continued ON/STANDBY REMOTE MODE RECEIVER TAPE INPUT SELECTOR MULTI CH TAPE TUNER + 10 -- / --- DIMMER SLEEP DISC ALBUM TOP MENU SP A / B MUTING ENTER PLAYLIST PLAYLIST RETURN LISTENING MODE STEREO SURROUND AUDIO SUBTITLE RANDOM REPEAT TEST TONE CH SEL...
  • Page 45: Recording

    Recording This chapter explains how to record the selected input source to an AV component with recording capability, and how to record audio and video from two different sources. Recording the Input Source You can record only to AV components that are con- nected to the TAPE OUT or VIDEO 1 OUT jacks.
  • Page 46: Using The Listening Modes

    Multich PLII Movie/Music/Game Neo:6 Cinema Neo:6 Music Dolby D Mono Movie Orchestra Onkyo Unplugged Original Studio-Mix TV Logic All Ch Stereo Full Mono *1. In the Direct listening modes, PCM signals at 32 kHz, 44.1 kHz, and 48 kHz are processed at 64 kHz, 88.2 kHz, and 96 kHz respectively.
  • Page 47: About The Listening Modes

    field that cannot be produced with conven- tional stereo. Use this mode with stereo material such as music CDs. Onkyo Original DSP Modes Mono Movie This mode is suitable for use with old movies and other mono sound sources. The center speaker outputs the...
  • Page 48: Adjusting The Listening Modes

    Adjusting the Listening Modes ON/STANDBY REMOTE MODE RECEIVER TAPE INPUT SELECTOR MULTI CH TAPE TUNER + 10 --/--- DIMMER SLEEP DISC ALBUM TOP MENU SP A / B ENTER ENTER PLAYLIST RETURN RETURN LISTENING MODE STEREO SURROUND AUDIO SUBTITLE RANDOM LEVEL - TEST TONE CH SEL...
  • Page 49: Using The Late Night Function

    Adjusting the Listening Modes—Continued PLII Music Mode Settings These settings apply to only 2-channel (stereo) sources. ■ Panorama With this function, you can broaden the width of the front stereo image when using the Pro Logic II Music listening mode. On: Panorama function on.
  • Page 50: Advanced Setup

    Advanced Setup Advanced Speaker Settings ON/STANDBY REMOTE MODE RECEIVER TAPE INPUT SELECTOR MULTI CH TAPE TUNER + 10 --/--- DIMMER SLEEP DISC ALBUM TOP MENU SP A / B ENTER ENTER PLAYLIST RETURN RETURN LISTENING MODE STEREO SURROUND AUDIO SUBTITLE RANDOM LEVEL - TEST TONE...
  • Page 51 Advanced Setup—Continued Speaker Levels With this function, you can adjust the volume of each speaker so that all speakers can be heard equally at the listening position. The speaker levels cannot be adjusted while a pair of headphones is connected, speaker set B is on, or the AV receiver is muted.
  • Page 52 Advanced Setup—Continued Speaker Configuration, Crossover Frequency, and Double Bass settings only need to be changed if you’re not using the speakers in this package. These settings cannot be changed while head- phones are connected, speaker set B is on, or the multichannel DVD input is being used.
  • Page 53 Advanced Setup—Continued Crossover Frequency This setting only applies to the speakers that you speci- fied as Small in the “Speaker Configuration” on page 52. To get the best bass performance from your speaker sys- tem, you need to set the crossover frequency according to the size and frequency response of your speakers.
  • Page 54: Digital Input Signal Formats

    Advanced Setup—Continued Digital Input Signal Formats The following table shows the display indicators for each supported digital signal format. Format Display Dolby Digital Normally, the AV receiver detects the signal format auto- matically. However, if you experience either of the fol- lowing issues when playing PCM or DTS material, you can manually set the signal format to PCM or DTS: •...
  • Page 55: Troubleshooting

    If you can’t resolve the issue yourself, try resetting the AV receiver before contacting your Onkyo dealer. To reset the AV receiver to its factory defaults, turn it on and, while holding down the [VIDEO 1] button, press the [STANDBY/ON] button.
  • Page 56: Troubleshooting

    Input Display to MD, CDR, or HDD (see page 35). • To control an Onkyo component that’s connected via , point the remote controller at the AV receiver.
  • Page 57 five seconds, and then plug it back in again. Onkyo is not responsible for damages (such as CD rental fees) due to unsuccessful recordings caused by the unit’s malfunction. Before you record important data, make sure that the material will be recorded cor- rectly.
  • Page 58: Specifications

    Specifications Amplifier Section Rated Output Power North American (FTC): (FL, FR, C, SL, SR) 95 watts minimum continuous power per channel, 8 ohm loads, 2 channels driven at 1 kHz, with a maximum total harmonic distortion of 0.7% (Subwoofer) 105 watts minimum continuous power per channel, 8 ohm loads, 1 channel driven at 80 kHz, with a maximum total harmonic distortion of 0.7%...
  • Page 59 Specifications—Continued 5.1ch Home Theater Speaker Package ■ Passive Subwoofer (SKW-350) Type: Bass-reflex type Passive Subwoofer 6 Ω Impedance: Maximum input power: 130 W Output sound pressure level: 84 dB/m/w Frequency response: 30 Hz–150 Hz Cabinet capacity: 0.85 cubic feet (24 L) ×...
