Summary of Contents for Boneco Four Seasons FS200
- Page 1 FS200 MANUAL Read and save these instructions...
- Page 2 INSTRUCTIONS FOR USE...
-
Page 3: Table Of Contents
TABLE OF CONTENTS Technical data Product features Product overview Assembly and use Preparing for operation Reset heater Using the Four Seasons ™ Replacing the filter Replacement filter – FS200F Cleaning and maintenance Cleaning the humidifier wick frame Cleaning the water tank Storage Trouble shooting... -
Page 4: Technical Data
TECHNICAL DATA Technical data* Type designation FS200 Power consumption 2000 W Power supply voltage 220 – 240V ~ 50Hz Capacity of Humidification 347 g/h Volume of air flow 136 m / h at high setting Dimensions 230 x 260 x 650 mm 5.2 kg Weight * Subject to change... -
Page 5: Product Features
WELCOME PRODUCT FEATURES Congratulations on your purchase of the Four Seasons ™ • Durable, washable cloth wick combination “heater” / “humidifier” / “air purifier” / • LED low water level indicator light “fan”! This amazing product combines all the benefits •... -
Page 6: Product Overview
PRODUCT OVERVIEW Control panel 10. Refill light 2. Humidifier water sensor 11. Heater + Humidifier 3. Humidifier wick frame 12. Humidifier + Fan 4. Wick frame release tab 13. Heater only 5. Water tank 14. Function knob 6. Cover frame 15. -
Page 7: Assembly And Use
ASSEMBLY AND USE PREPARING FOR OPERATION RESET HEATER Unplug the Four Seasons unit prior to filling the This heater is equipped with a temperature limiting ™ tank with water. thermostat. If the unit should sense an overheat condition, the element will stop heating. It can Open the packing box and take out the Four Sea- only resume operation when user manual reset sons... -
Page 8: Using The Four Seasons
USING THE FOUR SEASONS ™ Plug the unit into an electrical outlet and press the power button to turn on your Four Seasons unit. ™ 2. Turn the mode knob to select the desired function. You may choose to use either the heater, the humidi- fier, or the heater and humidifier together. -
Page 9: Replacing The Filter
REPLACING THE FILTER REPLACEMENT FILTER – FS200F Release Tab Make sure the unit is turned off and unplugged. To remove the cover frame, press the release tab and pull the frame outwards (see Figure 3A/B). 2. Remove the filter by pulling the filter out from the unit (see Figure 4). -
Page 10: Cleaning And Maintenance
CLEANING AND MAINTENANCE CLEANING THE HUMIDIFIER WICK FRAME Always unplug the Four Seasons unit prior to ™ cleaning or other maintenance. Remove the humidifier wick frame as explained in the “Assembly and use” section of this manual. 2. With the humidifier wick frame lying in front of you, gently bend each side of the wick frame to release the bottom roller (see Figure 5). -
Page 11: Cleaning The Water Tank
CLEANING THE WATER TANK Remove the humidifier wick frame as shown previ- ously. 2. Remove the water tank as demonstrated earlier in this manual. Clean the tank with water and mild detergent. 3. Rinse thoroughly with clean water before reinstall- ing. -
Page 12: Trouble Shooting
TROUBLE SHOOTING If you are having problems with your Four Seasons ™ My Four Seasons unit will not operate ™ please refer to the following suggestions. Suggestions Make sure the power button is pressed and in the down position. Make sure the unit is plugged into a functioning power outlet. Verify the wick frame and the inlet grill are properly installed.
