1
055420
6
SCREW HHC M12-1.75 X 25 G10.9
2
051769
6
WASHER LOCK M12
3
046526
8
WASHER LOCK M10
022237
8
WASHER LOCK 3/8
4
052647
8
SCREW SHC M10-1.5 X 25 G12.9
043097
8
SCREW SHC 3/8-16 X 1 G8.8 NZ
5
020604
2
FLEX PLATE-11-1/2 SAE
0A3852
3
PLATE FLEX GM
097514
3
PLATE FLEX SAE 3.0L GM
0A8240
3
FLEX PLATE SAE10 (6.8L FORD)
6
055173
6
SCREW HHC M8-1.25 X 20 G10.9
7
022129
6
WASHER LOCK M8-5/16
8
082130C
1
ASSEMBLY MAG PICKUP 54"
082130D
1
ASSEMBLY MAG PICKUP 72"
0D2244M
1
ASSY MAG PICKUP 3/8-24 MALE (6.8L FORD)
9 *
0E2747
1
FAN S.A.E. ALTERNATOR
0C4286
1
ASSEMBLY FAN W/PRESS DISC 10.75 X 3
(5.7L GM & 6.8L FORD)
10
0A2601
1
SCREW HHC M16-2 X 45 G8.8
11
0A2602
1
WASHER FLAT .688 ID X 3.25 OD
12
0A1138
1
KEY SQ 3/8 X 2-1/2 STEEL
13
021941
1
COUPLER 390 SAE
14
020804B
1
ROTOR 390 25KW 1/3P BRUSHLESS
020806B
1
ROTOR 390 35KW 1/3P BRUSHLESS
020807B
1
ROTOR 390 35KW 1/3P BRUSHLESS
020808B
1
ROTOR 390 40KW 1/3P BRUSHLESS
020809B
1
ROTOR 390 50KW 1P BRUSHLESS
020810B
1
ROTOR 390 60KW 1P BRUSHLESS
020811B
1
ROTOR 390 35KW 1/3P BRUSHLESS
020812B
1
ROTOR 390 40KW 1/3P BRUSHLESS
020813B
1
ROTOR 390 50KW 1P BRUSHLESS
020814B
1
ROTOR 390 60KW 1P BRUSHLESS
020815B
1
ROTOR 390 80KW 1P BRUSHLESS
020816B
1
ROTOR 390 100KW 1P BRUSHLESS
020817B
1
ROTOR 390 125KW 1P BRUSHLESS
020804D
1
ROTOR 390 25KW BR BRUSHLESS
020806D
1
ROTOR 390 35KW BR BRUSHLESS
020807D
1
ROTOR 390 35KW BR BRUSHLESS
020808D
1
ROTOR 390 40KW BR BRUSHLESS
020809D
1
ROTOR 390 50KW BR BRUSHLESS
020810D
1
ROTOR 390 60KW BR BRUSHLESS
020811D
1
ROTOR 390 35KW BR BRUSHLESS
020812D
1
ROTOR 390 40KW BR BRUSHLESS
020813D
1
ROTOR 390 50KW BR BRUSHLESS
020814D
1
ROTOR 390 60KW BR BRUSHLESS
020815D
1
ROTOR 390 80KW BR BRUSHLESS
020816D
1
ROTOR 390 100KW BR BRUSHLESS
020817D
1
ROTOR 390 125KW BR BRUSHLESS
020809G
1
ROTOR 390 50KW 3P LV BRUSHLESS
020813G
1
ROTOR 390 50KW 3P LV BRUSHLESS
020814G
1
ROTOR 390 60KW 3P LV BRUSHLESS
020815G
1
ROTOR 390 80KW 3P LV BRUSHLESS
15
052624
1
BEARING BALL 6212 SEALED
16
0A5580
4
SCREW HHC M14-2 X 140 G8.8
17
0A1633
4
WASHER 390 SAE ALT
18
020715B
1
STATOR 390 25AP1 SAE
020716B
1
STATOR 390 35AP1 SAE
020728B
1
STATOR 390 35AP2 SAE
020729B
1
STATOR 390 40AP2 SAE
020730B
1
STATOR 390 50AP2 SAE
020731B
1
STATOR 390 60AP2 SAE
020717B
1
STATOR 390 35AP3 SAE
020718B
1
STATOR 390 40AP3 SAE
020719B
1
STATOR 390 50AP3 SAE
020720B
1
STATOR 390 60AP3 SAE
020721B
1
STATOR 390 80AP3 SAE
020722B
1
STATOR 390 100AP3 SAE
020732B
1
STATOR 390 125AP4 SAE
020715D
1
STATOR 390 25KB1 SAE
020716D
1
STATOR 390 35KB1 SAE
020728D
1
STATOR 390 35KB2 SAE
020729D
1
STATOR 390 40KB2 SAE
020730D
1
STATOR 390 50KB2 SAE
020731D
1
STATOR 390 60KB2 SAE
020717D
1
STATOR 390 35KB3 SAE
020718D
1
STATOR 390 40KB3 SAE
020719D
1
STATOR 390 50KB3 SAE
020720D
1
STATOR 390 60KB3 SAE
020721D
1
STATOR 390 80KB3 SAE
020722D
1
STATOR 390 100KB3 SAE
020732D
1
STATOR 390 125KB4 SAE
020715G
1
STATOR 390 25DB1 SAE
020716G
1
STATOR 390 35DB1 SAE
020728G
1
STATOR 390 35DB2 SAE
020729G
1
STATOR 390 40DB2 SAE
020730G
1
STATOR 390 50DB2 SAE
020717G
1
STATOR 390 35DB3 SAE
020718G
1
STATOR 390 40DB3 SAE
020719G
1
STATOR 390 50DB3 SAE
020720G
1
STATOR 390 60DB3 SAE
020721G
1
STATOR 390 80DB3 SAE
19
022131
12
WASHER FLAT M10-3/8 ZINC
20
046526
12
WASHER LOCK M10
21
057642
12
SCREW HHC M10-1.5 X 40 G10.9
22
068113
1
CARRIER REAR BEARING 15"
23
068115
1
PANEL LOWER 15"
091065
1
PANEL LOWER 390MM
24
043123
4
WASHER LOCK M14
25
051779
4
NUT HEX M14-2.0 G8 YEL CHR
26
052259
2
WASHER FLAT M12
27
051769
3
WASHER LOCK M12
28
068406
3
SCREW HHC M12-1.75 X 60 G10.9
29
070274
1
KEY SQ 3/8 X 2-3/4 STEEL
30
087271
1
ASSEMBLY EXCITER 1.25" STK
087272
1
ASSEMBLY EXCITER 2.00" STK
31
068404
1
EXCITER FIELD 1.25 STK
068405
1
EXCITER FIELD 15" 2" LG
32
092950
1
COLLAR SLIP FIT 390MM
35
090063
1
DIODE BRIDGE SUPPORT 15"
36
090152
1
ASSEMBLY BRIDGE RECTIFIER
37
023365
2
WASHER SHAKEPROOF INT #8
38
033143
2
SCREW HHM #8-32 X 7/8
39
090064
1
CAP END ROTOR 390MM
40
083485
2
PLATE NUT
41
031980
2
TIE WRAP UL 14.6 X .14 NATL
45
083549
1
SLEEVE RUBBER
46
022392
2
PIN DOWEL 1/2 X 1-1/4
47
0A4089
1
ASSEMBLY SCROLL 390 SAE
48
0A2437
2
SCREW SWAGE 1/4-20 X 5/8 Z/YC
49
022473
2
WASHER FLAT 1/4 ZINC
50
056326
1
TRIM VINYL BLACK 1/8 GP (8.4')
