SHOP REBUILD AND
SERVICE PARTS MANUAL
DANA ELECTRIC TRANSAXLE
STARTING MODEL YEAR: 2008
610987
6
5
9
1 1
1 6
1 5
1 3
7
8
1 8
1 - I N C L U D E S I T E M S 3 - 1 6
1 7
1 9
3
1 0
4

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EZGO 610987 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Textron EZGO 610987

  • Page 1 610987 1 - I N C L U D E S I T E M S 3 - 1 6 SHOP REBUILD AND SERVICE PARTS MANUAL DANA ELECTRIC TRANSAXLE STARTING MODEL YEAR: 2008...
  • Page 3 E-Z-GO Division of Textron is not liable for errors in this manual or for incidental or consequential damages that result from the use of the material in this manual. CUSTOMER SERVICE DEPARTMENT IN USA PHONE: 1-800-241-5855, FAX: 1-800-448-8124 OUTSIDE USA PHONE: 010-1-706-798-4311, FAX: 010-1-706-771-4609 E-Z-GO DIVISION OF TEXTRON, INC., 1451 MARVIN GRIFFIN RD., AUGUSTA, GA 30906-3852 U.S.A.
  • Page 4 NOTES Notes: Page ii Dana Electric Transaxle Shop Rebuild and Parts Manual...
  • Page 5 INTRODUCTION Read all of each section before attempting any procedure. Pay particular attention to all Warnings, Cautions, and Notes. HOW TO USE THIS MANUAL WARNINGS, CAUTIONS, AND NOTES Throughout this manual, the following WARNINGS, This manual is designed to suit the needs of mechanics CAUTIONS, and NOTES are used.
  • Page 6 INTRODUCTION Read all of each section before attempting any procedure. Pay particular attention to all Warnings, Cautions, and Notes. the hot exhaust system. Never work on an engine that is hot. Never work around or operate a vehicle in Before working on vehicle, remove all jewel- an environment that does not ventilate ry (watch, rings, necklaces, etc.).
