IP 5MP 2.8~12mm
Motorized Turret
Camera with WDR
EV-N2506-NW4WQ
Installation Manual
Features
1
/
" 5MP SmartSens CMOS Sensor
•
2.7
• 30FPS@ 5MP (2880x1620)
• 2.8~12mm Motorized lens
• Tri-stream encoding:
H.265, H.264, and MJPEG
• True Wide Dynamic Range (WDR)
• Digital Noise Reduction (3DNR)
• True Day & Night function with ICR module
• ICR Sensitivity adjustment
• Corridor mode
• IP66 Weatherproof
• IR Range 147' (45m)
• Smart IRs adjust IR strength to conditions
• MicroSD slot (512GB max)
• PoE (IEEE802.3af), 12VDC
• ONVIF
®
Profile G, S, and T conformant
• Operating temperature: -40°~131°F
(-40°~55°C)
ONVIF
®
is a trademark of ONVIF, Inc
AI Functions
• Human and Vehicle Detection
• Perimeter Intrusion Detection
• Line Crossing Detection
• Stationary Object Detection
• Cross Counting
• Heat Map
• Crowd Density Detection
• Queue Length Detection
• Face Detection
For the full Web Administration manual,
download from the camera's product
page on www.seco-larm.com.
Advertisement
Table of Contents
Related Manuals for ENFORCER EV-N2506-NW4WQ
Summary of Contents for ENFORCER EV-N2506-NW4WQ
- Page 1 IP 5MP 2.8~12mm Motorized Turret Camera with WDR EV-N2506-NW4WQ Installation Manual Features AI Functions " 5MP SmartSens CMOS Sensor • Human and Vehicle Detection • • 30FPS@ 5MP (2880x1620) • Perimeter Intrusion Detection • 2.8~12mm Motorized lens • Line Crossing Detection •...
- Page 2 IP 5MP 2.8~12mm Motorized Turret Camera with WDR Parts List 1x Camera 1x Mounting Template 3x Mounting Screws 1x Hex Key 1x Manual 1x Weatherproof Connector Specifications Type Motorized turret camera Sensor " 5MP SmartSens CMOS Video encoding H.265/H.264/MJPEG Megapixels Resolution 2880x1620 Backlight...
- Page 3 IP 5MP 2.8~12mm Motorized Turret Camera with WDR Overview (Continued) Micro SD / Reset button compartment Micro SD Card slot RJ45 Ethernet Jack Reset button Top of camera DJ Jack IMPORTANT NOTES • Do not cut DC jack or RJ45 jack as warranty will be voided. •...
- Page 4 IP 5MP 2.8~12mm Motorized Turret Camera with WDR Troubleshooting • Check that the camera is powered up. • Check that the power supply’s polarity is correct. The screen is blank • Check that the monitor is powered up. • Check that the video cable connecting the camera to the monitor is connected properly.
