3X Series
NTSC Model #
EV-2726-N3GQ
EV-2726-N3WQ
EV-2726-NVGQ
EV-2726-NVWQ
Note: Model numbers that end with "Q" or that have a round green "Q" sticker signify RoHS-compliant products.
On-Screen Display Manual
PAL Model #
EV-2726-P3GQ
EV-2726-P3WQ
EV-2726-PVGQ
EV-2726-PVWQ
Vandal Rollerball Camera
Lens
Resolution
3.6mm
700 TV lines
3.6mm
700 TV lines
4~9mm
700 TV lines
4~9mm
700 TV lines
# of
Housing
IR LEDs
24
Gray
24
White
36
Gray
36
White
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for ENFORCER EV-2726-N3GQ
Summary of Contents for ENFORCER EV-2726-N3GQ
- Page 1 3X Series Vandal Rollerball Camera On-Screen Display Manual # of NTSC Model # PAL Model # Lens Resolution Housing IR LEDs EV-2726-N3GQ EV-2726-P3GQ 3.6mm 700 TV lines Gray EV-2726-N3WQ EV-2726-P3WQ 3.6mm 700 TV lines White EV-2726-NVGQ EV-2726-PVGQ 4~9mm 700 TV lines...
-
Page 2: Table Of Contents
ENFORCER 3X Series Vandal Rollerball Camera Table of Contents: Programmable Features……………… Picture Adjustment……………………………… How to Use the OSD Controller...…… Wide Dynamic Range (WDR)..……………..…. Main Setup Menu……………………… Highlight/Back Light Compensation Menu Diagram.………………………… (HLC/BLC)………………………………………. Lens….……………………………..Privacy..………………………………..………… Exposure………………………..……… Motion Detection….…………………………….. White Balance…………………….…… Camera Setup…..………………………………. -
Page 3: How To Use The Osd Controller
ENFORCER 3X Series Vandal Rollerball Camera How to Use the OSD Controller: 1. Press down on the joystick to open the on-screen display (OSD) menu. 2. Use the joystick to navigate the OSD menu. 3. To select an item, press down on the joystick. -
Page 4: Menu Diagram
ENFORCER 3X Series Vandal Rollerball Camera Menu Diagram : SETUP MENU SETTING SETTING OPTIONS MANUAL Set for fixed lens camera LENS MODE: AUTO / OPEN / CLOSE (see page 6) SPEED: 0~255 Level Adjustable High Luminance: MODE: SHUT + AUTO IRIS / AUTO IRIS... - Page 5 ENFORCER 3X Series Vandal Rollerball Camera Menu Diagram Continued: SETUP MENU SETTING SETTING OPTIONS MIRROR OFF / V-FLIP / H-FLIP / HV-FLIP CONTRAST 0~63 Level Adjustable SHARPNESS 0~15 Level Adjustable PICT ADJUST 0~100 Level Adjustable (see page 10) R-GAIN 0~255 Level Adjustable...
-
Page 6: Lens
ENFORCER 3X Series Vandal Rollerball Camera Lens: This function is used to select the camera’s lens operation. Select LENS on the Main Setup Menu screen. Select the desired lens operation by moving the joystick to the right or left. Select RETURN to return to the Main Setup Menu screen. -
Page 7: White Balance
ENFORCER 3X Series Vandal Rollerball Camera Exposure, continued MANUAL: The camera is in fixed shutter mode. MODE: Select shutter mode. (SHUT, SLOW, or WDR + SHUT) SHUTTER: Select shutter speed. Adjustable range: 1/60, 1/100, 1/250, 1/500, 1/1000, 1/2000, 1/4000, or 1/10000 sec... -
Page 8: Day/Night Mode
ENFORCER 3X Series Vandal Rollerball Camera White Balance, continued ATW (Automatic Tracking White Balance): When the image color temperature changes, it will automatically adjust the white balance color temperature range from 1,800°K~10,500°K. (Ex. A fluorescent lamp or outdoors) SPEED: Set the ATW speed. - Page 9 ENFORCER 3X Series Vandal Rollerball Camera Day/Night Mode, continued AUTO: The camera image will switch to color in normal conditions and the image colors will be suppressed when ambient light is low. BURST: Enable noise color synchronization. (ON or OFF) ...
-
Page 10: Picture Adjustment
ENFORCER 3X Series Vandal Rollerball Camera Picture Adjustment: This function is used to set the camera’s picture setting and DNR settings. Select PICT ADJUST on the Main Setup Menu screen. Select the desired picture setting by moving the joystick to the right or left. -
Page 11: Wide Dynamic Range (Wdr)
ENFORCER 3X Series Vandal Rollerball Camera Wide Dynamic Range (WDR): This function is used to provide clear images even under intense back light conditions. Select WDR on the Main Setup Menu screen. Select the desired WDR setting by moving the joystick to the right or left. -
Page 12: Highlight/Back Light Compensation
ENFORCER 3X Series Vandal Rollerball Camera High Light / Back Light Compensation (HLC/BLC): This function is used to control the light level to overcome strong back light conditions. Select HLC/BLC on the Main Setup Menu screen. Select the desired HLC/BLC mode by moving the joystick to the right or left. -
Page 13: Privacy
ENFORCER 3X Series Vandal Rollerball Camera Privacy: This function is used to distort or block out a certain portion of the image for privacy reasons. Select PRIVACY on the Main Setup Menu screen. Select the desired privacy masking by moving the joystick to the right or left. -
Page 14: Motion Detection
ENFORCER 3X Series Vandal Rollerball Camera Motion Detection: This function is used to detect moving objects on-screen. Select MOTION DET on the Main Setup Menu screen. Select the desired motion detection mode by moving the joystick to the right or left. -
Page 15: Camera Setup
ENFORCER 3X Series Vandal Rollerball Camera Camera Setup: This function is used to adjust the camera ID, zoom and language settings. Select CAMERA SETUP on the Main Setup Menu screen. Select the desired camera setup function by moving the joystick to the right or left. -
Page 16: Troubleshooting
ENFORCER 3X Series Vandal Rollerball Camera Troubleshooting: Check that the camera is powered up. Check that the power supply’s polarity is correct. The screen is blank. Check that the monitor is powered up. Check that the video cable connecting the camera to the monitor is connected properly.
