This section contains information on the most common error codes which can appear on the
touch screen. A step-by-step procedure is provided to prevent this error.
6.1

X-axis error! Overflow or Overcurrent!

Cause:
The drum motor cannot move to the required position. This is a fatal error. It can only
be solved by turning the power off and then on again. This error is usually caused by a
media crash in the machine.
Action:
1. Remove the crashed media and restart the machine. Should this happen rather
frequently, the cause can be :
• knife depth or pressure is not well set.
• bad tracking because an unstabilized media type is used.
• bad tracking because the humidity is too high or too low.
• bad tracking because an unapproved type of media is used.
• the media hits something on the floor while cutting.
• the media shows already different tracks, so that the media does not
know which track to follow.
2. Lower the speed of the media.
3. Check whether the drive drum turns smoothly (first turn the power off and place
the cam rollers in the up-position).
4. If the error in the x-axis happens at start-up, check the x-axis motor, the encoder
connectors and the cables.
5. Replace the X-motor encoder.
6. Replace the PCB.
6.2

Y-axis error! Overflow or overcurrent!

Cause:
The motor driving the machine head cannot move to the position wanted. This is a
fatal error. It can only be solved by turning the power off and then on again. This
error is usually caused by a media crash.
Action:

Error codes

6 Error codes
6-1
