Summary of Contents for Summa DC4
- Page 1 USER’S MANUAL Revision 04-04-06 IMPORTANT Before you begin... Please go through the online registration at http://www.summa.be/registration.html Failure to register might delay response to your warranty and service inquiries. Summa...
- Page 3 Operation of the DC4 in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense.
- Page 4 NOTICE Summa reserves the right to modify the information contained in this User Manual at any time without prior notice. Unauthorized copying, modification, distribution or display is prohibited. All rights reserved. All inquiries, comments or suggestions concerning this and other Summa manuals should be directed to:...
-
Page 5: Table Of Contents
1.6.3 USING MEDIA TAKE-UP ROLLERS............1-18 1.6.4 UNLOADING THE MEDIA..............1-19 1.6.5 USING THE MEDIA BASKET..............1-19 1.6.6 PREPARING THE DC4 FOR LONG PRINT-OUTS ........ 1-20 1.6.6.1 INTRODUCTION.................. 1-20 1.6.6.2 PROCEDURE ..................1-20 LOADING RIBBON CASSETTES ............1-21 1.7.1 LOADING AND REMOVING THE CASSETTES ........ - Page 6 User’s Manual SECTION 2.................. 1-1 OPERATION INSTRUCTIONS ........... 2-1 2.1. THE CONTROL PANEL................2-1 2.1.1 THE LIQUID CRYSTAL DISPLAY ............2-1 2.1.2 KEY..............2-2 2.1.3 THE ARROW KEYS ..............2-2 2.1.4 KEY..................2-2 2.1.5 KEY..................2-2 2.2. MENU STRUCTURE OVERVIEW............. 2-3 2.2.1 MAIN MENU ....................
- Page 7 User’s Manual 2.2.4.8 ROOM TEMPERATURE..............2-18 2.2.4.9 COIL SETUP..................2-18 2.2.4.10 SHOW PRINTER USAGE..............2-18 2.2.4.11 COPY USER CONFIG................. 2-18 2.2.4.12 PRINT DEMO FILE ................2-18 SECTION 3.................. 2-1 GENERAL INFORMATION ..........3-1 3.1. MAINTENANCE & CLEANING ..............3-1 3.1.1 CLEANING THE DRIVE SYSTEM ............
- Page 8 PRINTING SOFTWARE ............. 5-1 5.1. SUMMA COLORCONTROL ..............5-1 5.1.1 INSTALLING HASP DRIVER FOR DONGLE........... 5-2 5.1.2 INSTALLING SUMMA COLORCONTROL ..........5-3 5.1.3 SUMMA COLORCONTROL (SCC) CONFIGURATION ......5-4 5.1.3.1 COLORCONTROL PREFERENCES............. 5-4 5.1.3.2 PROCESS PREFERENCES..............5-5 5.1.3.3 RIP PREFERENCES ................5-6 5.1.3.4 DC4 PREFERENCES ................
-
Page 9: Installation Of The Dc4
The shipping box and any other items, used for packaging, must be saved in the event the printer will need to be moved. Do not transport the DC4 without completely repackaging it in the original packaging. For safety reasons, the unpacking of a DC4 must be done with at least 2 persons. - Page 10 Slide the ramp under the stand, closest to the end with the foam suspension blocks. From this point on, two people ARE REQUIRED for safety reasons. Lift the DC4 from each side, just high enough so the foam blocks can be pulled out from underneath the DC4.
- Page 11 Position the ramps so the printer can be rolled down from the pallet. Be sure the wheels of the printer are aligned with the ramp legs. FIG 1-4 UNPACKING DC4 FINAL STAGE 4 Open the front cover and loosen the printer carriage, then remove the foam underneath the carriage, which is protecting the printhead.
-
Page 12: Accessories And Supplies
User’s Manual 1.1.1 ACCESSORIES AND SUPPLIES The DC4 is delivered with all the accessories and supplies necessary to start working immediately. Some accessories are already installed in the machine and others are in separate boxes. Please check if everything was delivered with your DC4. -
Page 13: Part Numbers For Accessories And Supplies
User’s Manual 1.1.2 PART NUMBERS FOR ACCESSORIES AND SUPPLIES The following table contains the description and the part number for DC4 accessories and printer supplies. Description Part number Picture Thermal Printhead 420-400 Drag knife (set of 5) 391-360 Slitter knife... - Page 14 User’s Manual Cyan DC3-602 DC3-601 Magenta Ribbon: Yellow DC3-600 Black DC3-604 Media core holders-set 391-510 3M vinyl printing media DC-405 TABLE 1-1 TABLE OF ACCESSORIES AND SUPPLIES General Information...
-
Page 15: Printer Parts And Locations
1.2 PRINTER PARTS AND LOCATIONS 1.2.1 FRONT SIDE DC4 FRONT VIEW 1. Control Panel and LCD: All printer activity can be initiated from the 8 key control panel. The LCD informs the user on the current status of the printer, or actions, which need to be taken. - Page 16 5. Cleaning Plate: The cleaning plate is used to clean the thermal printhead. While printing, the printhead cleans itself automatically and at regular intervals. 6. Front Wheels: The front wheels of the DC4 are equipped with locking brakes. Secure the brakes, once the DC4 is permanently installed, by pressing the locking wheel brake down with your foot.
-
Page 17: Rear Side
1.6. 3. Parallel Port: This connector (IEEE1284-B) provides a communication link between the DC4 and the host computer. It can be used as a connection with a LAN, in combination with an Ethernet to parallel converter. 4. USB port: This interface is based on the standards specified in Universal Serial Bus Specifications Revision 1.1. -
Page 18: Ideal Operating Environment
The printer should be located away from windows and doors, preferably within a clean interior room of a building. Check for the following conditions when installing the DC4: Surface must be level without vibration Operating temperature should be stable, between 15 - 27 degrees Celsius (60 to 80 degrees Fahrenheit). -
Page 19: Powering On The Dc4
User’s Manual 1.4 POWERING ON THE DC4 1.4.1 GROUNDING SAFETY WARNING An insulated ground conductor must be installed as part of the branch circuit that supplies power to the wall outlet to which the printer is connected. The ground conductor must have the same... -
Page 20: Power-On Procedure
When there is no media loaded, the DC4 will prompt the user for a media load procedure. When media is loaded, the DC4 will measure the media width and check the presence of the cassettes and estimate how much usable ribbon is remaining on the roll. -
Page 21: Connecting The Printer To A Computer
Summa Printer Control (see section 5.3.1.). When the DC4 is connected for the first time to a computer, the computer will detect it and ask for the USB drivers. The drivers are located on the CD with the manual. -
Page 22: Media Handeling
1.6 MEDIA HANDELING 1.6.1 LOADING MEDIA The DC4 is designed to work with rolls of media, not sheets. It is advised to use cotton gloves while loading the media, otherwise the surface of the media becomes contaminated by oil from fingers, and the beginning of the printout will be unusable. - Page 23 User’s Manual Place the media roll on the DC4 rollers. The right core holder guide is at a fixed position on the supply rollers bar. The left guide is adjustable. Make sure the media roll is positioned as in figure 1-8. Guide the beginning of the vinyl around the second supply roll (1).
- Page 24 After closing the front cover, the DC4 will measure the media width. If the media width has changed, then the printer will prompt the user to check if the right pinch roller is set correct.
-
Page 25: Changing Media Width
(L for 137cm - 54inch; M for 76cm - 30inch; s for 61cm – 24inch. If a job is sent to the DC4 and the loaded media width is not calibrated with the correct line feed, then the DC prompts the user with the message: WARNING: USER IS NOT CALIBRATED FOR THIS MEDIAWIDTH. -
Page 26: Using Media Take-Up Rollers
FIG 1-11 PREPARING TAKE-UP ROLL Attach the scrap media to the edge of the vinyl. Allow for some slack so the DC4 can align and park the media if necessary. If the take-up rollers are enabled, and if the DC4 is printing, then the media will be rolled up. -
Page 27: Unloading The Media
DC4, thus preventing the vinyl from collecting dust. When the DC4 is used for print and cut, then the media baskets, front and rear, MUST be used, otherwise the vinyl will pick up dust, damaging the print. -
Page 28: Preparing The Dc4 For Long Print-Outs
1.6.6 PREPARING THE DC4 FOR LONG PRINT-OUTS 1.6.6.1 INTRODUCTION The DC4 has a fixed position at the rear for the rollerguiding of the flange. It is possible that some types of vinyls are not wound up even (e.g. the core sticking out). -
Page 29: Loading Ribbon Cassettes
REMOVING A CASSETTE LOADING A CASSETTE Close the rear cover. After the media is loaded, DC4 will take the cassette and estimate the amount of ribbon in the cassette available for printing. The printer will not check the cassettes if no media is loaded ! CAUTION ! Do not insert empty cassettes, without ribbon. -
Page 30: Refilling Ribbon Cassettes
(band), carefully aligning each pixel. The ribbons are wound onto plastic cores, which are unique to the DC4 cassette and printer carriage. First, remove the protective ribbon wrapping and place the RI (ribbon identification) chip aside. - Page 31 User’s Manual 4. When closing the cassette, make sure the hinge pins (top piece) fit securely into the notched out bottom part of the cassette (2). FIG 1-19 CLOSING THE RIBBON CASSETTE 1-23 General Information...
-
Page 32: Contour Cutting Knife Installation
User’s Manual 1.8 CONTOUR CUTTING KNIFE INSTALLATION SAFETY WARNING The DC4 uses razor-sharp vinyl cutting knives. The knife blades may cause serious personal injuries if handled without proper caution. Use extreme care when operating the cutter; and when installing, removing or handling the cutter’s knife blade! To set up the knife, proceed as follows: 1. - Page 33 - Loosen the clamping screw and insert the knife holder. Press the holder down, firmly seating it. - Tighten the clamping screw. 6. Set the knife pressure as follows: • Power ON the DC4 and load a piece of media (See 1.7.). • Press the key. • Press the MENU’...
- Page 34 User’s Manual The knife depth is correctly set when the test pattern is visible on the front side of the media backing, but not on the rear side of the media backing. Increase the knife pressure using the key when the cut pattern is not visible on the front side of the media backing.
- Page 35 To prevent damage to the cutter, check the depth of the knife blade tip and the quality of the cut each time you load a different type of vinyl media into the DC4. 7. To change the knife offset, proceed as follows: •...
-
Page 37: Operation Instructions
2 OPERATION INSTRUCTIONS 2.1. THE CONTROL PANEL Figure 2-1 shows the control panel of the DC4. The main functions of the LCD and the control panel keys are explained in the following paragraphs. It is advised not to touch the control panel while the machine is printing or cutting, except for canceling the current job. -
Page 38: The And Key
2.1.4 key returns back a step in to the previous menu level. To get at the top level of the menu, press this key three times. The DC4 will also then be ready for printing. 2.1.5 key toggles the status of the clamps. This key works only when the DC4 is in a ready state. -
Page 39: Menu Structure Overview
The main menu can be entered when [MENU] is visible on the bottom line of the LCD. Pressing 3 times on the key will bring the DC4 to this state unless the machine is loading. Press the key to enter the main menu. The main menu items give access to submenus or commands. -
Page 40: Printer Menu
2.2.3. 2.2.1.2 REPRINT JOB The DC4 stores every sent job on hard disk. If the hard disk is almost full, the oldest jobs will be deleted. After pressing , press the key to scroll through the saved jobs. -
Page 41: Shut Down
It is advised to use this key when shutting down the DC4, especially for minimizing wear on the pinch rollers. If the pinch rollers are left down for a long period of time, a flat spot is created on the wheel and tracking becomes a problem and is not guaranteed any more. -
Page 42: Printer Menu
User’s Manual 2.2.2 PRINTER MENU The printer menu contains parameters and small routines to optimize the printing quality............................................... FIG 2-3 PRINTER MENU Operating Instructions... -
Page 43: Ribbon Status
User’s Manual 2.2.2.1 RIBBON STATUS The RIBBON STATUS sub-menu is used to check the status of the cassettes and their locations. Press the key to enter the sub menu. Now the status of each cassette and location can be checked. Press the to scroll through the different locations. -
Page 44: Print Speed
The DOT OVERLAP sub-menu is used to activate or deactivate the dot overlap. When the DC4 prints the next pass of an image, the last dot on the edge of the previous pass is reprinted. Dot overlap can be set to ON, OFF or HALF by pressing key. -
Page 45: Scratchguard
If white, gold or silver is chosen as OptiTrac color, then the DC4 will raise the head between the left and right OptiTrac mark if the color is not used. With all other colors, it will keep the head down. -
Page 46: Calibrate Print & Cut
Weed out the large rectangle, and then search in each set for the small square where the printed lines are not visible. Now insert the values, which correspond to those squares into the DC4 via the control panel. -
Page 47: Head Alignment Test
The head alignment test is used to check if the carriage is aligned (mounted) correctly on the DC4. This test should only be performed after a head or a carriage change. Fig 2-10 shows the pattern that is printed using this test. -
Page 48: Cutter Menu
User’s Manual 2.2.3 CUTTER MENU The cutter menu contains parameters and small routines to optimize the cutting quality..............FIG 2-11 CUTTER MENU 2.2.3.1 KNIFE PRESSURE The KNIFE PRESSURE parameter is used to set the cutting pressure of the knife. Press the arrow keys until the desired pressure is displayed on the LCD, then press... -
Page 49: Knife Offset
User’s Manual 2.2.3.2 KNIFE OFFSET The KNIFE OFFSET parameter is used to set the distance between the knife blade tip and the center axis of rotation. The default knife offset value is .45 mm. Press the arrow key until the desired knife offset is displayed on the LCD and press to confirm. -
Page 50: Din Test
User’s Manual 2.2.3.5 DIN TEST The DIN TEST CUT performs an electrical and mechanical test of the cutter, in order to check the cut quality, but also provides the user with feedback on knife setting, knife pressure, knife offset and cutting depth. This test cut is always a DIN A4 portrait/A-size image. -
Page 51: Setup Menu
User’s Manual 2.2.4 SETUP MENU The setup menu contains parameters, tests and info on the DC4 that are not often used................................FIG 2-12 SETUP MENU 2-15 Operating Instructions... -
Page 52: Take-Up Roll
Calibrate media is used to optimize the parameters of the OptiTrac sensor. Press the to perform the calibration. The DC4 prints out the pattern below and then cuts out a rectangle. Then it measure the reflection values of media and Optitrack color. -
Page 53: Calibrate Print & Cut
Then it will search the edges of the two outer rectangles. If the vinyl is not appropriate for the test, then the DC4 will give a message. Then the test has to redone with a vinyl which has a high contrast between the media and the backing color. -
Page 54: Room Temperature
2.2.4.12 PRINT DEMO FILE On the hard disk of the DC4 there are two demo files. A print and cut file of 800mm by 380mm and a color chart. Pres the key to enter the menu. Then with the key choose the demo file. -
Page 55: Section 3
They will, however, collect dust and lint, which may affect the performance of the DC4. Keep the DC4 as clean as possible by keeping the front cover always closed. When necessary, clean the unit with a soft cloth dampened with isopropyl alcohol or mild detergent. -
Page 56: Cleaning The Sensor
To clean the sensor area, proceed as follows: 1. The front sensor is located on the DC4’ s left side, right next to the pinch roller. The rear sensor is located in the neighborhood of the rear clamp (see figure below). -
Page 57: Cleaning Pad
3.1.3 CLEANING PAD Located on the left side of the DC4 is a printhead cleaning pad. The printer cleans the head periodically on this pad. It is possible that after a while some dust will accumulate on this pad. Therefore it is advised to clean this pad from time to time. -
Page 58: Cleaning The Printhead
Do not clean the printhead above the printing surface. To clean the printhead, proceed as follows: 1. Power off the DC4. Open up the rear cover and take out the cassette. 2. Use a lint free cloth, or gauze, moistened with isopropyl alcohol. -
Page 59: Cleaning The Printing Surface
2. Cut a piece of vinyl, the size of the printing surface (1 x 0.14m) and stick it onto the printing surface. 3. Power on the DC4 and load the media. Print out a rectangle full width and height, consisting out of two colors app 20% coverage. -
Page 60: Operating Voltage
The fuse is at the back, next to the power inlet. The fuse rating is a 4.0A Slo-Blo, for all voltage ratings. SAFETY WARNING efore changing the fuse be sure to completely disconnect the DC4. NOTE Always make sure that you are using the correct fuse rating. -
Page 61: Section 4
This section describes the communication interfaces between your DC4 and the host computer. A Parallel and USB connection is available with DC4. When both ports are connected at the same time, only the port that receives the data first will stay active, and this will deactivate the other port. -
Page 62: Usb Interface Notes
User’s Manual 4.1.2 USB INTERFACE NOTES The DC4 has a built–in USB interface and is based on the standards, specified in Universal Serial Bus Specifications Revision 1.1 The recommend cable length is 5 meters (16 ft.) or less. The adaptable connector type is USB Series “B”... -
Page 63: Section 5
ColorControl is a Windows based program that processes Postscript files (“EPS”, “PS”, “EPSF” and “PDF” files). ColorControl provides the RIP (Raster Image Processor) to enable the operator to output vector and raster images to the DC4. Included functions are: Print to DC4: A high-speed image rasterizer that processes postscript files using a postscript level 3 interpreter. -
Page 64: Installing Hasp Driver For Dongle
User’s Manual 5.1.1 INSTALLING HASP DRIVER FOR DONGLE 1. Insert the CD into the computer. 2. The CD should start automatically. If the installation does not begin automatically, launch the routine manually from the “Run” command line in the Windows Start menu. Type “D:\autostart.exe” (where D is the DVD/CD-ROM drive). -
Page 65: Installing Summa Colorcontrol
Windows Start menu. Type “D:\autostart.exe” (where D is the DVD/CD-ROM drive). FIG 5-3 START CD MANUALLY 3. Start up screen. FIG 5-4 INSTALLATION OF SUMMA COLORCONTROL 4. Click on “Setup Color Control “. 5. Then follow the instructions on the screen. The ColorControl installation procedure is self-explanatory. Printing Software... -
Page 66: Summa Colorcontrol (Scc) Configuration
User’s Manual 5.1.3 SUMMA COLORCONTROL (SCC) CONFIGURATION The software is now ready to use, but the operator might wish to adjust certain preferences. Launch ColorControl. 5.1.3.1 COLORCONTROL PREFERENCES FIF 5-5 COLORCONTROL PREFERENCES 1. Temp directory: Indicates where SCC writes temporary files during processing. -
Page 67: Process Preferences
User’s Manual 5.1.3.2 PROCESS PREFERENCES FIG 5-6 PROCESS PREFERENCES 1. Units: sets the units of measurement for pixel resolution, page size and rulers within the preview menu. 2. Drag ‘n’ Drop RIP: identifies the printer being used. Printing Software... -
Page 68: Rip Preferences
User’s Manual 5.1.3.3 RIP PREFERENCES FIG 5-7 RIP PREFERENCES 1. Lib directory: where SCC’s library files reside. The default is “C:\Program Files\SummaCC\lib\psrip3”. If during an installation the files are stored elsewhere, then change this setting appropriately. If the settings are incorrect, SCC will give a fatal error when ripping. -
Page 69: Dc4 Preferences
1. Destination printer: select the interface port, most commonly used is the USB port. 2. Check if printer type is set to Summa DC4. This is important for maximum printing width and tile size. 3. RIP output directory: specify the directory where ripped files will be stored. -
Page 70: Reprint Preferences
User’s Manual 5.1.3.5 REPRINT PREFERENCES FIG 5-9 REPRINT PREFERENCES Reprint directory: select to use the RIP output directory or choose another location to store ripped files. Printing Software... -
Page 71: How To Rip And Print
User’s Manual 5.1.4 HOW TO RIP AND PRINT To begin, enter the menu and click on . In the subsequent dialog boxes, browse to the file that needs to be printed and click on the button. The print dialog box will appear, there are 5 tabs. 5.1.4.1 GENERAL TAB FIG 5-10... -
Page 72: Color Tab
User’s Manual 5.1.4.2 COLOR TAB FIG 5-12 COLOR TAB 1. Colorspace: select 3 color (CMY), 4 color (CMYK), Monochrome (Grey scale) or spot color only. Printing in 4 colors is chosen to deepen shadows and to provide a true black. Printing in 3 colors reduces the cost of the output. (See fig below –... -
Page 73: Screening Tab
Do not confuse this term ‘dots per mm’ (dpmm or dpi). Dpmm is the resolution of the printer. The head of a DC4 has a fixed resolution of 12 dpmm (304 dpi). The number of shades depends on the relation between dpmm and lpmm (lpi and dpi). - Page 74 User’s Manual 4. Angle: To get various shades to reproduce an image, the RIP uses a process called screening. Screening breaks an image down into series of dots. Each screen is set to a certain angle. Thus creating intersecting rows that form a pattern as dot shapes, know as rosettes.
- Page 75 Ellipse is the recommended default shape. Rhomboid, Double Dot and other shapes are can be chosen for special effects, but are not generally recommended. Summa cannot guarantee print quality using any shape other than Ellipse. Tips: For difficult colors, use Rhomboid 0.8 to 1.1 lines /mm (20 to 30 lines/inch)
-
Page 76: Layout Tab
There is also the option to print out each tile separately. If the weed box option is chosen, then the DC4 cuts a border around the print out.. If there is print and cut information, in the file, then SCC will automatically cut a border around the design. -
Page 77: Advanced Tab
2. Job name (optional): specify the name the printer will use in the printer’s queue. 3. Space after job: set the required distance between subsequent jobs, This value is ignored by the DC4. 4. Use compression: compresses raw printer data to reduce the time it takes to transfer the data. - Page 78 NO IMPROVED CMYK TO CMY 7. Use High resolution mode is an option to print in high resolution. When this mode is used, then the DC4 prints with a resolution of 304x608 dpi which results in higher color contrast and scharper images.
- Page 79 User’s Manual FIG 5-22 PRIMER DOT FIG 5-23 VISION PRINT 5-17 Printing Software...
-
Page 80: How To Rip,View And Print
User’s Manual 5.1.5 HOW TO RIP,VIEW AND PRINT Follow next procedure to RIP, View and print. Enter the menu and click on In the print dialogue box choose Set the rest of the printing preferences as explained in previous section. Click on Enter the menu and click on... -
Page 81: Palette Installer
User’s Manual 5.2. PALETTE INSTALLER This program installs a custom ColorControl spot color palette for Adobe Illustrator, CorelDraw or Macromedia Freehand. The spot colors in this palette have unique names, which ColorControl can recognize. 5.2.1 LAUNCHING PALETTE INSTALLER 1. Insert the CD into the computer. 2. -
Page 82: Summa Printer Control
The Summa Printer Control program basically has the same functions as the control panel. It is up to the user to decide which way he will work most efficiently. The users who will work with the Summa Printer Control program will notice that it is a very powerful and practical tool. -
Page 83: Summa Printer Control Menus
With the file menu, configuration settings can be save on the computer and loaded from its hard disk. The options are only highlighted if a connection between the DC4 and the computer has been established. The last item in this menu will exit the program. -
Page 84: Configuration Menu
These parameters can be changed and saved on the computer hard disk, and also in DC4’s memory. 5.3.2.5 TESTS MENU The test menu is used for starting internal DC4 tests, updating the DC4 firmware and to check how many prints the printhead has printed. -
Page 85: Action List
2.2. When a parameter is changed, then the parameter and the value are displayed in bold on the computer and the cancel and apply button are highlighted. Click on ‘apply’ to send the new value to the DC4. FIG 5-29 CONFIGURATION SETTINGS 5.3.3.2... -
Page 86: Info
User’s Manual 5.3.3.3 INFO FIG 5-31 INFO Info gives the operator the most important parameters at a glance. The printed media area can be set to zero with the eraser tool right next to it. 5.3.3.4 USERS FIG 5-32 INFO With this the operator can change the active user and also change the user name. -
Page 87: Section 6
6 OPOS 6.1 INTRODUCTION The DC4 has an accurate Optical Positioning System. This can be used when it is impossible to contour-cut right after the printing. For instance when the design has to be laminated and then cut afterwards. OPOS is based on the principle of registrating black or cyan printed squares around the design. - Page 88 Make sure that the origin marker is situated at the right side and above all contours that need to be cut. • Remember the marker size, its value will have to send in a later step of the procedure to the DC4. OPOS...
- Page 89 The exact distance is the distance from the lower left corner of one marker to the lower left corner of the marker just underneath • Remember the Y-distance, this value will have to be sent to the DC4 in a later stadium. 5. Print the design.
- Page 90 User’s Manual • Print the markers and the design on the DC4. Make sure not to scale the design any more. • When printing make sure not to rotate the design any more and leave at least 30cm after the design.
-
Page 91: Setting The Parameters And Loading To Cut
Look for ‘LOAD OPOS MARKERS’ in the cutter menu and press ’ENTER’. • The DC4 will prompt the user to put the knife tip above the first marker. If all previous steps were followed, then this means that the first marker is in the lower left corner of the design that was just loaded in the DC4. -
Page 92: Cutting The Contour
WinPlot also send the OPOS parameters automatically to the DC4. Just click on the OPOS cut icon and the parameters will be send to the DC4 and the special load will be activated (the machine will ask the user to put the knife tip above the first OPOS marker.
