EST Install and User Guide
Appearance of the product may vary.
Manufacturer reserves the right to change specifications or designs without notice.
0 of 29
1. Introduction--------------------------------------
2. Install your Thermostat-------------------------
3. Setup-----------------------------------------------
3.1 Time setting--------------------------------------
3.2 Working mode----------------------------------
3.3 Setup Wi-Fi----------------------------------------
3.4 Schedule set-------------------------------------
3.5 User setup-----------------------------------------
3.6 Factory set----------------------------------------
3.7 Clean screen------------------------------
3.8 Reset--------------------------------------------
4. Warranty ---------------------------------------
5. Regulatory info.---------------------------------
ECOER INC.
3
5
7
7
8
10
13
16
19
28
28
29
29
07 2022
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Ecoer EST01
Summary of Contents for Ecoer EST01
-
Page 1: Table Of Contents
EST Install and User Guide ECOER INC. 0 of 29 EST01 Wi-Fi Programmable Thermostat Install and User Guide 1. Introduction-------------------------------------- 2. Install your Thermostat------------------------- 3. Setup----------------------------------------------- 3.1 Time setting-------------------------------------- 3.2 Working mode---------------------------------- 3.3 Setup Wi-Fi---------------------------------------- 3.4 Schedule set------------------------------------- 3.5 User setup----------------------------------------- 3.6 Factory set----------------------------------------... - Page 2 EST Install and User Guide ECOER INC. 1 of 29 Manufacturer reserves the right to change specifications or designs without notice. 07 2022...
- Page 3 ELECTRICAL HAZARD Can cause electrical shock or equipment damage. Disconnect power before beginning installation. EQUIPMENT DAMAGE HAZARD Compressor protection is bypassed for Ecoer condensing units. To prevent equipment damage, set compressor protection accordingly for other brand condensing units. MERCURY NOTICE If this product is replacing a control that contains mercury in a sealed tube, do not place the old control in the trash.
-
Page 4: Est01 Wi-Fi Programmable Thermostat
EST Install and User Guide 3 of 29 ECOER INC. 1. Introduction Parts in the packaging box Screws and anchors Install and User Guide EST01 Wi-Fi Thermostat Mounting System Stickers Power supply AC 24V Temp. Setting range 50°F to 90°F... - Page 5 EST Install and User Guide ECOER INC. 4 of 29 Thermostat Layout Desired temperature Indoor humidity Mode Adjust temperature Working status Menu (ON/AUTO/CIRC) (Back button) Schedule Indoor temperature * Wake/Away/Home/Sleep * The screen will wake up by touching the indoor temperature area Mode: Select system mode OFF, COOL, AUTO, HEAT and EM HEAT.
-
Page 6: Install Your Thermostat
Look at the wires going out of the wall and take a photo for reference. Label each wire going into your old thermostat with the provided stickers. The EST01 Wi-Fi thermostat • Does not work for 120-240V systems. • Does not work with millivolt systems. - Page 7 EST Install and User Guide 6 of 29 ECOER INC. Wiring Terminals in Mounting System (G2) S: Single transformer D: Double transformers RESERVED Connection to touch screen Terminal Description Common RH / RC 24 VAC power (RH and RC are already connected each other - Must Dial to S)
-
Page 8: Setup
EST Install and User Guide ECOER INC. 7 of 29 3. Setup 3.1 Time Setting Press Menu at homepage, the screen will display DATE TIME. Menu DATE TIME WORKING MODE SETUP WIFI SCHEDULE SET USER SETUP FACTORY SET CLEAN SCREEN RESET II. -
Page 9: Working Mode
HOLD: Keeps the desired temperature set all the time. SCHEDULE: Follows 7-day plan (4 time periods per day) * * To activate the scheduling, it’s required to choose AUTO at thermostat homepage or on Ecoer Home App control interface. Manufacturer reserves the right to change specifications or designs without notice. - Page 10 EST Install and User Guide ECOER INC. 9 of 29 Activate 7-day Scheduling by Ecoer Home App • Select Mode to Auto • Turn ON Schedule (i.e. Choose ‘Follow Schedule’) Manufacturer reserves the right to change specifications or designs without notice.
-
Page 11: Setup Wi-Fi
10 of 29 3.3 Setup Wi-Fi Search ‘Ecoer Home' on Google Play or App Store to install the App. Register with your phone number or email, log in App to add device. Press Menu at homepage, the screen will display DATE TIME, press Next twice to SETUP WIFI. - Page 12 (see Fig.3). Touch “Help” to trouble shoot if you fail to make it online. Fig. 1 Fig. 2 Fig. 3 * The design of Ecoer Home App may subject to change. Manufacturer reserves the right to change specifications or designs without notice. 07 2022...
- Page 13 Circulate indoor air when AC/HP stops Schedule Status • ON: Follow Schedule • OFF: Hold On * The design of Ecoer Home App may subject to change. Manufacturer reserves the right to change specifications or designs without notice. 07 2022...
-
Page 14: Schedule Set
EST Install and User Guide 13 of 29 ECOER INC. 3.4 SCHEDULE SET Press Menu at homepage, the screen displays DATE TIME. II. Press Next until you see SCHEDUL SET. Menu DATE TIME WORKING MODE SCHEDULE SET SETUP WIFI USER SETUP... - Page 15 EST Install and User Guide ECOER INC. 14 of 29 Detailed Schedule Setting at thermostat Press + or - to choose the group or the day of week. If the schedules are the same on different days, it will be more convenient to set it by group.
- Page 16 EST Install and User Guide ECOER INC. 15 of 29 Detailed Schedule Setting via ‘Ecoer Home’ App Click to enter scheduling. II. Click the period you want to set, then scroll start Time, Cool Temp. and Heat Temp. III. Touch “COMPLETE” to save your settings.
-
Page 17: User Setup
EST Install and User Guide 16 of 29 ECOER INC. 3.5 USER SETUP Press Menu at homepage, the screen will display DATE TIME, then press Next until you see USER SETUP. Menu DATE TIME WORKING MODE SCHEDULE SET SETUP WIFI... - Page 18 EST Install and User Guide ECOER INC. 17 of 29 NOTE: Press Menu during setting will exit you directly and nothing will be saved. Manufacturer reserves the right to change specifications or designs without notice. 07 2022...
- Page 19 EST Install and User Guide ECOER INC. 18 of 29 FAN CIRC Setting by Ecoer Home App NOTE: App can set FAN CIRC* when Mode is Off (i.e. AC/HP stops). * Circulate indoor air when Air Conditioner or Heat Pump stops for a long period.
-
Page 20: Factory Set
EST Install and User Guide 19 of 29 ECOER INC. 3.6 FACTORY SET (Professional only) Press Menu at homepage, the screen will display DATE TIME, then press Next until you see FACTORY SET. Menu DATE TIME WORKING MODE SCHEDULE SET... - Page 21 ESI + E series Air Handler Cool only AC only + E series Air Handler Cool only + W Remarks: ESI- Ecoer Smart Inverter condensing unit * means optional connection Manufacturer reserves the right to change specifications or designs without notice. 07 2022...
- Page 22 SW1-3 OFF: HP Ecoer Air Condtioner Other Brand Fan Coil Type 2 Cool Only + W output Ecoer variable speed air conditioner matches with gas or oil furnace. Optional SW1-3 ON: AC SW1-3 OFF: HP Ecoer Air Condtioner Other Brand Fan Coil Manufacturer reserves the right to change specifications or designs without notice.
- Page 23 Ecoer Air Condtioner Other Brand Fan Coil Type 4 Heat Only + W output Ecoer variable speed heat pump matches with furnace (G required) or boiler. Optional Ecoer Heat Pump Furnace Manufacturer reserves the right to change specifications or designs without notice.
- Page 24 EST Install and User Guide ECOER INC. 23 of 29 Type 6 1H/1C with constant indoor fan speed Ecoer variable speed heat pump (Require O Signal input) matches with fan coil. Optional Ecoer Heat Pump Other Brand Fan Coil Type 8 1H/1C with constant indoor fan speed Ecoer variable speed heat pump matches with fan coil.
- Page 25 EST Install and User Guide ECOER INC. 24 of 29 Type 9 1H/2C with two-stage fan control (G/ DH [G2]) in cooling Ecoer variable speed heat pump matches with E Series air handler Optional (G2) Ecoer Heat Pump EST01 E Series Air Handler (G2) Manufacturer reserves the right to change specifications or designs without notice.
- Page 26 EST Install and User Guide ECOER INC. 25 of 29 Type 10 2H/1C with constant indoor fan speed (Factory default) Ecoer variable speed heat pump matches with fan coil for 2 stage heating Optional (G2) Ecoer Heat Pump EST01 Other Brand Fan Coil Manufacturer reserves the right to change specifications or designs without notice.
- Page 27 ECOER INC. 26 of 29 Type 11 2H/2C - 4H/2C with two-stage fan control (G/ DH [G2]) in cooling Ecoer variable speed heat pump matches with E series air handler and electric heat (Dual-fuel). Optional (G2) Ecoer Heat Pump EST01...
- Page 28 EST Install and User Guide ECOER INC. 27 of 29 Type 12/13 Cool only with two-stage fan control (G/ DH [G2]) AC only (including Ecoer variable speed AC) matches with E Series air handler - Type 12 Optional SW1-3 ON: AC SW1-3 OFF: HP...
-
Page 29: Clean Screen
EST Install and User Guide ECOER INC. 28 of 29 3.7 Clean Screen Press Menu at homepage, the screen will display DATE TIME, then press Next until you see CLEAN SCREEN. Menu DATE TIME WORKING MODE SETUP WIFI SCHEDULE SET... -
Page 30: Warranty
This warranty does not cover removal or reinstallation costs. This warranty shall not apply if it is shown by Ecoer that the defect or malfunction was caused by damage which occurred while the product was in the possession of a consumer. - Page 31 EST Install and User Guide ECOER INC. 30 of 29 Manufacturer reserves the right to change specifications or designs without notice. 07 2022...
- Page 32 EST Install and User Guide ECOER INC. 31 of 29 ©2022 ECOER INC. 43671 Trade Center Place, Suite 100 Dulles, VA 20166 Tel: 703-348-2538 www.ecoer.com Manufacturer reserves the right to change specifications or designs without notice. 07 2022...
