The target curve is converted to the equivalent but with control points, shown as dots on the target curve. The curve
can then be edited as shown here:
Click and drag to move point
Click and drag curtain to change correction region
To switch between the shelving controls and the control points, use the icons located with each group on the right side
of the window:
Snapshots
You can save the current set of groups, target curves and curtain frequencies by clicking on the Take snapshot button:
https://docs.minidsp.com/product-manuals/flex-dl/print_page.html
Right-click on curve to add point
Hover mouse over point to view frequency and gain
Use shelves
Print or save - miniDSP Flex (DL)
Right-click on point to delete
Use control points
