Grand GT36-12 Manual

Grand high speed trimmer

Advertisement

Quick Links

用户手册
MANUAL
MODEL & DEVICES
GT36-12 GT261-12
无刷吸风直驱感应式自动微油双(单)头手提剪线机
BRUSHLESS DIRECT DRIVE & SUCTION INDUCTION AUTO SLIGHTLY OILING
DOUBLE(SINGLE) HEAD PORTABLED THREAD TRIMMER
GRAND HIGH SPEED TRIMMER SERIES

Advertisement

loading
Need help?

Need help?

Do you have a question about the GT36-12 and is the answer not in the manual?

Questions and answers

Summary of Contents for Grand GT36-12

  • Page 1 用户手册 MANUAL MODEL & DEVICES GT36-12 GT261-12 无刷吸风直驱感应式自动微油双(单)头手提剪线机 BRUSHLESS DIRECT DRIVE & SUCTION INDUCTION AUTO SLIGHTLY OILING DOUBLE(SINGLE) HEAD PORTABLED THREAD TRIMMER GRAND HIGH SPEED TRIMMER SERIES...
  • Page 2 GT36-12 组装示意图 3、 GT36-12 Clipper motor, box and suction line acessory (7) GT36-12 电 机 、 吸 线 及 内 箱 组 件 图 4、 GT36-12 Clipper motor, box and suction line list (8) GT36-12 电 机 、 吸 线 及 内 箱 清 单...
  • Page 3 1、Application instruction 剪 线 机 使 用 说 明 This serial product is one of necessary equipment specialized in garment industry, with its substitution for traditional manual clipper process and integration in clipper and thread-sucking process, as well as no any thread end remained, all these products are assumed to keep up all finished clothes and working environment quite clear and tidy to improve operation efficiency and mitigate worker's labor strength This serial product features into high efficiency, smaller body, lower noise, lower electrical consumption,...
  • Page 4 ◆ Description of operation 操作使用方法 1. Move the blade head along with the trail of thread ends from left to right, whilst the thread ends are sucked into the teeth of blade and cut off. 刀 头顺成衣的线迹方向 平 行移 动即可 达 到剪 线 目的。 2.
  • Page 5 配 合太松则需更换摆 块,同时检 查摆块 在轴向上 有 无间隙 ,如间隙过大需重新调整。 6. No use sewing machine oil or WD-40 instead of grand special thread trimmer oil since these kinds of oil shall shorten the life of blade, however, grand lubricant is one of composite oil with quiet fine, higher specification value, easier solubility to water and mobile viscosity, also beneficial for improvement for blade life.
  • Page 6 2、If not enough suction force exists in suction motor whilst use, first check up if air speed adjustment knob is at appropriate position, then check up plastic barrel and barrel cover is at better cover position, finally check up if the barrel is too filled with thread end and if dustproof cover accumulated too much thread end or dust.
  • Page 7 ◆ (GT36-12/GT36-BL ) Suction motor maintenance ( GT36-12/GT36-BL )直流吸风马达使用说明 1、Suction motor has been to high pressure resistance before factory shipment, which is durable to 1200V and with thermal protection device. Once temperature exceeds 120℃, the motor shall be automatic shutdown, and restart it after temperature lowers to normal one, such operation become more safe and reliable.
  • Page 8 、 GT36-12 General assembly drawing GT36-12 组 装 示 意 图 ◆Assembly instruction 安 装 说 明 Pc 1 Installation of support arm 脚 轮的 安装 1. Install the four casters on the corresponding positions at the bottom of the box.
  • Page 9 3、GT36-12 Clipper motor, box and suction line acessory GT36-12 电 机 、吸线及 内 箱 组件图 13 14 15 16 17...
  • Page 10 4、 Clipper motor, box and suction line list GT36-12 电 机 、吸 线 及内 箱清单 GT36-12 序 号 型 号 名 称 数 量 备 注 Description Part No Ref.No RemarkS 合页与钢化门固定片 Hinge plate GT26-11-00 前 门 组 件 GT36-12HB-02 Front door component 十字沉头螺钉...
  • Page 11 5、Clipper blade accessory 刀头组件图...
  • Page 12 6、Clipper blade accessory assembly list 刀头组件清单 序 号 型 号 名 称 数 量 备 注 Description Ref.No Part No RemarkS 手 把 侧 盖A Hand side cover A stjx-03A 手 把 侧 盖B Hand side cover B stjx-03B 挡 风 片 STJX-05 Blinker 喷...
  • Page 14 美 国 百 川 公 司 , GRAND INT L ENTERPRI SE U.S.A IN C. FACTORY : GRAND PRECISION INDUSTRIAL LTD. NO. 136,Qiwan Roard North, East District, Zhongshan City, Guangdong Province, China Tel: 86-760-88414888 Fax: 86-88414668 Http://www.usa-grand.com E-mail: info@usa-grand.com...

This manual is also suitable for:

Gt261-12
