- Page 1 MANUAL MODEL & DEVICES GRAND HIGH SPEED TRIMMER SERIES...
- Page 2 C o n t e n t s 目 录 1、 Application instruction （1） 剪 线 机 使 用 说 明 1)Clipper blade maintenance （2~3） 剪 线 刀 的 保 养 2)Vacuumsuction motor maintenance （4） 真空马达使用说明 2、 General assembly drawing （5）...
- Page 3 1、Application instruction 剪 线 机 使 用 说 明 This serial product is one of necessary equipment specialized in garment industry, with its substitution for traditional manual clipper process and integration in clipper and thread-sucking process, as well as no any thread end remained, all these products are assumed to keep up all finished clothes and working environment quite clear and tidy to improve operation efficiency and mitigate worker's labor strength This serial product features into high efficiency, smaller body, lower noise, lower electrical consumption,...
- Page 4 ◆ Description of operation 操作使用方法 1. Move the blade head along with the trail of thread ends from left to right, whilst the thread ends are sucked into the teeth of blade and cut off. 刀头顺成衣的 线迹方向平行移动即可达到剪线目的。 2. In the light of laborer's habit, he/she can casually adjust the balancer to change the gap between blade head and operator so as to mitigate worker's labor strength.
- Page 5 配 合太 松则需更换摆块，同时检 查摆块 在轴向上 有 无间 隙 ，如间隙 过 大需 重新调整。 6. No use sewing machine oil or WD-40 instead of grand special thread trimmer oil since these kinds of oil shall shorten the life of blade, however, grand lubricant is one of composite oil with quiet fine, higher specification value, easier solubility to water and mobile viscosity, also beneficial for improvement for blade life.
- Page 6 Accessory: 附件图 Tools 辅助工 具 Oil box 油 盒...
- Page 7 2、 General assembly drawing 组 装 示 意 图...
- Page 8 3、Suction assembly and suction accessory 无刷 吸线 组 件图 10-9 10-7 10-5 10-4 10-3 10-2 10-1 10-10 10-0 10-5 10-6 10-8 10-9 10-11 序 号 型 号 名 称 数 量 备 注 Description Part No Ref.No RemarkS 马达罩 GHT33-123-01 Motor cover 胶...
- Page 9 4、Clipper blade accessory and assembly 刀头组件图 序 号 型 号 名 称 数 量 备 注 Description Ref.No Part No RemarkS 刀 头 座 GHT33-121-01 Blade head base 风 量 调 整 片 Wing guard 181-11 风 量 调 整 片 螺 丝 Wing guard screw M3X6 感...
- Page 10 5、Pedestal and Control box accessory assembly 底座 及 控制 盒组件 图(一)
- Page 11 序 号 型 号 名 称 数 量 备 注 Description Ref.No Part No RemarkS 刀头固定柱与电机安装板焊接组件 T20E-BL-08 Welding assembly 安装底板与M6焊接螺母焊接组件 Welding assembly T20E-BL-09 软 轴 Flexible shaft T20E-BL-07 内 六 角 紧 定螺 丝 M3*3 Screw 防 松 螺 母 φ9-4.2X5 空...
- Page 12 美 国 百 川 公 司 ， GRAND INT L ENTERPRI SE U.S.A IN C. FACTORY : GRAND PRECISION INDUSTRIAL LTD. NO. 136，Qiwan Roard North, East District, Zhongshan City, Guangdong Province, China Tel: 86-760-88414888 Fax: 86-88414668 Http://www.usa-grand.com E-mail: info@usa-grand.com...
