用户手册
MANUAL
MODEL & DEVICES
T22C
台式剪线机
TABLE STYLE THREAD TRIMMER
T22C-BL
无刷吸风台式剪线机
BRUSHLESS SUCTION TABLE STYLE THREAD TRIMMER
GRAND HIGH SPEED TRIMMER SERIES
T22E
台式自动感应剪线机
TABLE STYLE INDUCTOR THREAD TRIMMER
T22C-SW
台式涡旋吸风剪线机
TABLE STYLE VORTEX SUCTION THREAD TRIMMER
Advertisement
Related Manuals for Grand T22C
Summary of Contents for Grand T22C
- Page 1 用户手册 MANUAL MODEL & DEVICES T22C T22E 台式剪线机 台式自动感应剪线机 TABLE STYLE THREAD TRIMMER TABLE STYLE INDUCTOR THREAD TRIMMER T22C-BL T22C-SW 无刷吸风台式剪线机 台式涡旋吸风剪线机 BRUSHLESS SUCTION TABLE STYLE THREAD TRIMMER TABLE STYLE VORTEX SUCTION THREAD TRIMMER GRAND HIGH SPEED TRIMMER SERIES...
- Page 3 （12） 6、 Clipper motor , arm accessory and assembly 剪 线 电 机与支 架 组件图及 清 单 （13） 7、 Control box accessory and assembly(T22C/GT32) 控制 盒 组件图 及 清 单(T22C/GT32) （14） 8、Control box accessory and assembly(T22E) 控制盒 组 件图及 清 单(T22E) （15）...
-
Page 4: Application Instruction
1、APPLICATION INSTRUCTION AND MAINTENANCE 使用 说 明 及 保 养 This serial product is one of necessary equipment specialized in garment industry, with its substitution for traditional manual clipperprocess and integration in clipper and thread-sucking process, as well as noany thread end remained, all these products are assumed to keep up all finished clothes and working environ mentquite clear and tidy to improve operation efficiency and mitigate worker's labor strengthc. - Page 5 6、 No use sewing machine oil or WD-40 instead of grand special thread trimmer oil since these kinds of oil shall shorten the life of blade, however, grand lubricant is one of composite oil with quiet fine, higher specification value,...
- Page 6 1、在重新安装剪线刀时，首先要确定剪线动刀尖与定刀尖的正确位置。动刀尖相对定刀尖的后退量为0.64mm， 调整时松开弹簧片固定螺丝，平行推动活动刀片即可（图1）。 2、在调节剪线刀头挡风片时，将剪线刀片安装之后，要将挡风片与剪线刀尖的距离调到大约1.28mm，如果布 料特别薄，可调到0.64mm，这样不会剪破衣服和包缝线（图2）。 3、刀尖与风量遮挡片的落差是0.5mm，即风量遮挡片应比刀尖高出0.5mm,如果风量片与刀尖平，容易剪破衣服 和剪破包缝线，但如要面对一些比较薄的衣服，或要求剪线剩余多2mm以上的，则须把风量遮挡片与刀尖的 落差调大，调整时只须松开(图3)所示A处螺丝，把整组刀头部分往下按到适当位置即可，亦可更换较厚的 挡风片。 4、遇有剪线刀片不利时，请松开刀片固定螺丝，查看动刀片刀齿间有无脏物，如积满污垢，线头入不到刀齿 应清除干净；检查弹簧片的压力，用左手拿着定刀片，右手的拇指和食指推动动刀片,感觉有3~3.5公斤的 推力为正常,如压力不够，请重新调整弹簧片压力或更换弹簧片。 5、如果刀头有特别的“嗒嗒嗒”声音，请松开刀片固定螺丝，检查摆块与动刀的配合间隙，如配合太松则需 更换摆块，同时检查摆块在轴向上有无间隙，如间隙过大需重新调整。 6、切勿用衣车线油或WD-40代替剪线机油。因为这类油会令刀片的使用寿命减低,而百川牌润滑油是十分幼 细，皂化值很高，易溶于水，运动黏度很高的合成油，能有效帮助提高刀片的使用寿命。 1/32 1/16 Remarks: 注意事项 Clipper blades to be used continuously after six months may be blunt, please go to our dealers to sharpen the blades or buy new one.
- Page 7 ◆ (GT22-01) BRUSH SUCTION MOTOR MAINTENANCE (GT22-01) 有刷吸风马达维修与保养 Suction motor has been to high pressure resistance before factory shipment, which is durable to 1200V and with thermal protection device. Once temperature exceeds 120℃, the motor shall be automatic shutdown, and restart it after temperature lowers to normal one, such operation become more safe and reliable.
- Page 8 ◆ BRUSHLESS DC SUCTION MOTOR MAINTENANCE 直流无刷吸风马达使用说明 Suction motor has been to high pressure resistance before factory shipment, which is durable to 1200V and with thermal protection device. Once temperature exceeds 120℃ , the motor shall be automatic shutdown, and restart it after temperature lowers to normal one, such operation become more safe and reliable.
- Page 9 ◆ VORTEX SUCTION MOTOR MAINTENANCE 涡旋吸风吸风使用说明 Suction motor has been to high pressure resistance before factory shipment, which is durable to 1200V and with thermal protection device. Once temperature exceeds 120℃, the motor shall be automatic shutdown, and restart it after temperature lowers to normal one, such operation become more safe and reliable.
- Page 10 2、TRIMMING MACHINE INSTALLATION SCHEMES 剪线机安装示意图 Bedplate, bracket installation PICTURE 1 (图1) 台板、 台脚 安装 (1) With two hearts M8X25mm hex screws lock pedal 用两颗M8X25mm外六角螺丝锁紧踏板 (2) With two hearts M8X25mm hex screws to fix both sides nonmartensite fixed board 用两颗M8X25mm外六角螺丝将固定板固定 好两边台架 (3) The bench, right bedplate pig from bedplate edge 10mm norms, with six star about ST5X30mm since reactive screw points willboth sides with...
- Page 11 Model No:T22 Serial No: Grand Trimmer Power:180~430W Volt:220 Hz:50 Grand International Enterprise (U.S.A) Inc. Grand Enterprise (Asia) Ltd. STOP mouths of the plastic barrel towards the three mouthsof the motor cover and push upward tightly, just move left and right。...
- Page 12 3、CLIPPER BLADE A CCESSORY AND ASSEMBLY 刀头组件图及清单 序号 型 号 名 称 数量 备 注 Description Ref.No Part No RemarkS 吸线异形管 181-12A Blade head shell 风量调整片 Wind guard 181-11 风量调整片螺丝 Wind guard screw Two flat washers M3X6 短含油轴承 Clipper head bearing 181-07-22A 软轴固定螺丝...
- Page 13 4、SUCTION ASSEMBLY AND SUCTION ACCESSORY 有刷吸风组件图及清单 序号 型 号 名 称 数量 备 注 Description Part No Ref.No RemarkS 美式插座电机线 220V/10A Wire 马达盖 XGH-06 Motor cover 桶盖 XGH-05 Container cover 胶垫 XGH-03-1 Rubber washer 吊钩 XGH-04 Hook 十字扁圆头螺丝 M5X10 Screw 马达胶垫...
- Page 14 5、SUCTION ASSEMBLY AND SUCTION ACCESSORY 无刷吸风组件图 10-9 10-7 10-5 10-4 10-3 10-2 10-1 10-10 10-0 10-5 10-6 10-8 10-9 10-11 序号 型 号 名 称 数量 备 注 Description Ref.No Part No RemarkS 马达罩 GHT33-123-01 Motor cover 胶垫 183-03-1 Rubber washer 吊钩...
- Page 15 6、CLIPPER MOTOR ARM ACCESSORY AND ASSEMBLY 剪线电机与支架组件图及清单 序号 型 号 名 称 数量 备 注 Description Ref.No Part No RemarkS 直型支撑片 Straight arm 182-09 圆型支撑片 182-08 Round arm 内六角圆柱头固定螺丝 M6X20 Screw 蝶形螺母 Nuts 长支撑杆 Long support pole 182-07 十字盘头螺丝 M6X65 Screw 法兰座...
- Page 16 7、CONTROL BOX ACCESSORY AND ASSEMBLY(T22C/GT32) 控制盒组件图及清单(T22C/GT32) O P E N A A Y D E L S T O P M A X M IN el N M od l N o: 30 W S er ia 80 ~4 er :1...
- Page 17 Electrical protective ring 6N-4 美式插座 American style socket 250V/15A 航空插座（大4芯） Aeronautic socket(big 4 cores) GX-19-4P 电容器 Capa citor 2.5uF/450V 十字圆头螺丝 M3X16 Screw 控制盒盖 T22-2 Control box cover 十字圆头螺丝 M3X6 Screw 十字沉头自功螺丝 ST4X16 Screw 感应器 GDH-(T22E) Sensors 铭牌 Name plate T22C-2...
- Page 18 9、BRUSHLESS SUCTION CONTROL BOX ACCESSORY AND ASSEMBLY 无刷吸风控制盒组件图 序号 型 号 名 称 数量 备 注 Description Ref.No Part No RemarkS 下盖 GT22-12-02-03-V1 Lower cover 前 面板 Front panel GT22-12-02-04A 指 示灯 Indicator light 184-01 注 油开 关 GT22-1 Note oil switch 电...
- Page 20 美 国 百 川 公 司 GRAND PRODUCTS(U.S.A) GROUP FACTORY : GRAND PRECISION INDUSTRIAL LTD. NO. 136，Qiwan Roard North, East District, Zhongshan City, Guangdong Province, China Tel: 86-760-88414888 Fax: 86-88414668 Http://www.usa-grand.com E-mail: info@usa-grand.com...
