- Page 1 Sofa-WallBed | Assembly Manual Inova LLC 2 Van Buren Blvd. Guilderland Center, NY 1208585...
- Page 2 Sofa-WallBed...
- Page 3 Quick Start Guide Sofa-WallBed | Assembly Manual...
-
Page 4: Helpful Information
Quick Start Guide HELPFUL INFORMATION • Prior to opening your shipment,check and • A large,contractor’s garbage bag is included in confirm the room is completely ready to The Hardware Box for trash removal Receive the furniture • All parts are labeled for easy identification (see “Room Readiness Checklist”... - Page 5 Quick Start Guide ROOM READINESS the Bed will be installed. By removing the other cushioning material to prevent parts baseboard,it will allow for a tighter fit from being scratched. CHECKLIST against the wall (custom units may already • Locate the mattress that will be used with •...
-
Page 6: Tools Needed
Quick Start Guide H-115 Euro Screw, 18mm TOOLS NEEDED: HARDWARE LIST: H-491 Machine Screw, 3/4” Electric Power Drill Bolts: Nuts: #2 Phillips Bit H-068 Panel Bolts, 2” H-086 Flange Nuts, 5/16” #3 Phillips Bit (provided) H-112 Flange Head Bolts, 5/16” x 2” H-767 Nylock Nuts, 5/6”... - Page 7 How It Works Sofa-WallBed | Assembly Manual...
- Page 8 How It Works HOW IT MOVES UP TO LOWER THE SOFA-WALLBED: Handles are located on the outside of the AND DOWN: Bed Cabinet (on the bed platform) for use to The mechanisms that allow the Sofa- lower the Bed. WallBed to move up and down are spring- loaded and located inside face of each pier.
- Page 9 How It Works HOW TO ADJUST TENSION: STEPS FOR ADJUSTMENT: To adjust the tension of the Sofa-WallBed: To adjust the number of springs,you will need to temporarily “walk” the cabinet and sofa forward until it is around two feet from the wall. The factory has installed the proper number of springs based on our estimated weight of typical mattresses.
- Page 10 Sofa-WallBed: Hardware Overview The illustrations drawn are general representations of your products hardware H-016 H-019 H-068 H-231a H-120 H-107 H-162 H-508 H-087 H-738 H-231b H-783 H-086 H-417 H-085 H-115 H-491 H-073 H-233 H-062 H-244 H-461 H-934 H-065 H-285a H-067 H-003 H-285b H-235 H-011...
- Page 11 Step 1: Prepare the Right Pier The illustrations drawn are general representations of your product’s parts and hardware A. Lay the Right Pier on the floor as shown (padding or carpet is suggested to be underneath the pier to avoid scratching). B.
- Page 12 Step 2: Prepare the Cabinet Back and Cabinet Top The illustrations drawn are general representations of your product’s parts and hardware A. Attach the Shelf to the Cabinet Back using the provided H-065 panel screws and 4mm hex driver. B. Attach the Valance to the Cab Top/Sub Top assembly using the provided H-065 panel screws and insert the H-003 dowels into both ends of the sub top. Shelf H-065 Cabinet Back...
- Page 13 Step 3: Cabinet Back and Cabinet Top to Right Pier The illustrations drawn are general representations of your product’s parts and hardware A. Lay the Right Pier on its side if it is not already (padding or carpet is suggested to be underneath the pier to avoid scratching). B.
- Page 14 Step 4: Prepare The Left Pier The illustrations drawn are general representations of your product’s parts and hardware A. Lay the Left Pier on the floor as shown (padding or carpet is suggested to be underneath the pier to avoid scratching). B.
-
Page 15: Two Person Lift
Step 5: Assemble The Bed Cabinet TWO PERSON LIFT! The illustrations drawn are general representations of your product’s parts and hardware A. With another person, lift and flip the Left Pier with one person at the top end and the other at the bottom end. ( the hardware previously installed is facing toward the floor now). B. - Page 16 Step 6: Assemble The Base Plate The illustrations drawn are general representations of your product’s parts and hardware A. Arrange the Base Plate Assembly parts as shown, then insert the H-003 Dowels and H-062 double end pins into their corresponding holes and tighten the H-004 cam locks. B.
- Page 17 TWO PERSON LIFT! Step 7: Attach the Base Pad Assembly to the Bed Cabinet The illustrations drawn are general representations of your product’s parts and hardware A. Place the assembled Base Pad on the ground (close to the area where you want the bed to be once completed but away from the wall). B.
- Page 18 Step 8: Attach the Arms The illustrations drawn are general representations of your product’s parts and hardware A. Place the Left and Right Arms as shown on the Base Pad B. Align the holes in the back of the Arm and the front of the Pier then bolt them together using a H-068 panel bolt. Complete this step on both Arms. C.
- Page 19 Step 9: Install the Headboard The illustrations drawn are general representations of your product’s parts and hardware A. Screw the H-231b button fix connectors to the Shelf as shown using the H-115 euro screws provided. B. Attach the H-231a 90deg snap connectors to the Headboard as shown using H-087 screws. C.
- Page 20 Anti-Tip Strap Attachment The illustrations drawn are general representations of your product’s parts and hardware A. Move the Bed Cabinet against the wall into its final position in the room. B. Locate the Studs in the wall. Attach the H-508 cable and bracket assembly to the studs, just above the Bed Cabinet top using H-016 drywall screws. C.
- Page 21 Step 10: Install the Mechanisms The illustrations drawn are general representations of your product’s parts and hardware A. Attach the Left Mechanism to the Left Pier as shown using the H-417 low head cap screws provided. DO NOT fully tighten the screw at the top/front corner of the mechanism and use the H-067 washer with this bolt.
- Page 22 Step 11: Head Rail, Foot Rail and Side Rails The illustrations drawn are general representations of your product’s parts and hardware A. Attach the M-19 head/foot angle brackets to the Head Rail and Foot Rail using the H-073 euro screws provided and the H-933 pozi drive bit. Then, attach the M-224 side angles to the Left and Right Side Rails using the remaining H-073 euro screws.
- Page 23 Step 12: Assemble Bed Platform The illustrations drawn are general representations of your product’s parts and hardware A. Place the Left and Right Bed Panels on the ground with the hardware facing up (padding or carpet is suggested to be underneath the Bed Panels to avoid scratching). B.
- Page 24 Step 13: Mechanize The Bed Platform The illustrations drawn are general representations of your product’s parts and hardware A. Insert the H-738 bolts into hole #1 on the Left and Right Side Rails. Then attach the H-086 nuts to the ends of bolts, but DO NOT fully tighten. Insert the H-739 low head cap screw into hole #3 on the Left and Right Side Rails.
- Page 25 TWO PERSON LIFT! Step 14: Install the Bed Platform The illustrations drawn are general representations of your product’s parts and hardware A. Lift the Bed Platform assembly as shown, then align the bolts in hole one on both Side Rails with the slot on both Spring Mechanisms as shown and tighten the bolt B.
- Page 26 Step 15: Attach the Back Cushions The illustrations drawn are general representations of your product’s parts and hardware A. Attach the Back Cushion to the Bed Platform using H-491 machine screws, starting with the second hole from the bottom of the slide. Ensure 3 machine screws per slide are utilized. B.
- Page 27 Step 16: Install the Seat Deck The illustrations drawn are general representations of your product’s parts and hardware A. Angle the Seat Deck Front Slider to be under the ledge of both arms as shown. B. Then move the Slider toward the front to parallel the seat with the spreader. C.
- Page 28 Step 17: Attach the Skirt The illustrations drawn are general representations of your product’s parts and hardware A. Engage the rear supports and prepare to attach the Skirt by opening the Bed to a 45 degree angle. You will hear a slight knocking sound- that is the rear supports engaging. B.
- Page 29 Step 18: Secure Mechanism Covers The illustrations drawn are general representations of your product’s parts and hardware A. Open the Bed fully and place the Left Mechanism Cover over the Left Mechanism and the Right Mechanism Cover for the Right Mechanism. B.
- Page 30 Step 19: Seat Cushions The illustrations drawn are general representations of your product’s parts and hardware A. Put the Seat Cushions on the seat deck, make sure they are facing Velcro to Velcro...
