See dimension below
SW27
B1 4-pin Angular
Connector Model
4
Electrical Connection
4.1 Transmitter electrical connection diagram see below
50
27
M20×1.5
4× 3EQS
16
26
MPM4706
27
SW27
M20×1.5
B2 Cable outlet
model
MPM4736
3
27
SW27
M20×1.5
B3 7-pin Aviation
plug model
