2.2 J5 Connector Panel: JTAG Ports

The unpopulated connector panel J5 on the PCAN-RS-232 converter's circuit board
provides an access option to the JTAG ports of the LPC2194/01 microcontroller (μC)
for hardware debugging.
Gain access to the unpopulated J5 connector panel:
Risk of short circuit! Soldering on the PCAN-RS-232 may only be
performed by qualified electrical engineering personnel.
Attention! Electrostatic discharge (ESD) can damage or destroy
components on the card. Take precautions to avoid ESD.
1. Disconnect the PCAN-RS-232 from the power supply.
2. Unscrew the two screws.
3. Remove the housing cover.
4. Remove the circuit board.
