The standard RJ-45 receptacle/connector
RJ-45 Connector pin assignment
Contact
Media Direct Interface Signal
1
Tx + (transmit)
2
Tx - (transmit)
3
Rx + (receive)
4
Not used
5
Not used
6
Rx - (receive)
7
Not used
8
Not used
The standard Category 3 cable, RJ-45 pin assignment
